No. S1006
OPERATING INSTRUCTION
Prior to use, please read this manual thoroughly.
Keep this manual in a convenient place for quick and easy reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the mz-24 HOTT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRAUPNER mz-24 HOTT

Summary of Contents for GRAUPNER mz-24 HOTT

  • Page 1 No. S1006 OPERATING INSTRUCTION Prior to use, please read this manual thoroughly. Keep this manual in a convenient place for quick and easy reference.

  • Page 2: Table Of Contents

    Contents 8. S.Limit • Before Use 9. S.MIX 43~45P • Introduction 10. THR.MIX 45~46P • Support and Service 11. PRO.MIX 46~50P • Openhobby A/S Center 12. Trainer 50~51P 1. Box Contents 13. PIT >> RUDD 2. Flying Safety 52~53P 14. Telemetry 3.

  • Page 3: Introduction

    Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of Graupner/SJ. This manual contains instructions for Graupner/SJ mz-24 HoTT radio system is used to airplane, helicopter and glider and safety, operation and maintenance.

  • Page 4: Specification

    6. TRANSMITTER CONTROL IDENTIFICATION 4. SPECIFICATION ANTENNA Transmitter mz-24 Receiver GR-24L S3 SWITCH Frequency band 2.4~2.4835GHz 2.4~2.4835GHz S5 SWITCH S2 SWITCH Modulation FHSS FHSS S4 SWITCH S1 SWITCH Output power 100mW Current drain approx 125mA approx 70mA POWER SWITCH Operating voltage 3.4V~6V 3.6V~8.4V NECKSTRAP LUG...

  • Page 5: Binding

    7. BINDING CAUTION We strongly recommend that you wouldn’t use throttle limit function in Helicopter type since You must bind the receiver to the transmitter before the receiver will operate. Binding throttle limit function restricts the travel amount of throttle with DV1 volume. teaches the receiver the specific code of the transmitter so that it will only connect to it’s In order to cancel throttle limit function, touch “BASE”...

  • Page 6: Warning Alarm Function For Telemetry Data

    8.WARNING ALARM FUNCTION FOR TELEMETRY DATA BACK AUTO LOAD TX VOLT RX VOLT Touch RX 05.5V This function consists of 5 different warning types so that users can easily check each of warn- 3.7V 00.0V ings from transmitter screen. When one of 5 warnings happens, the warning screen is displayed STRENGTH and voice alarm is activated.

  • Page 7: Transmitter Programming Setup

    9. TRANSMITTER PROGRAMMING SETUP 1-1. SET BASE MENU Touch and activate “MODEL NAME” icon in blue for your purpose and touch SEL icon. Select Turn on transmitter’s power and touch B icon on the main page to access to BASE menu. YES in “MODEL CHANGE”...

  • Page 8: New(New Model)

    1-2. NEW This function is use to create the new model or exchange the current model to others. There is 2 methods of Manual setting and Wizard setting. You may program the basic function sequen- Touch tially in Manual setting. Here is the example for airplane IMP.M IMP.M Touch...
  • Page 9 Touch Touch Touch “Wizard setup” is used to set the basic function of a model and the essential function of flight one Touch by one. Please refer to the example of helicopter type as below. Touch the icon of desired model you want to program Wizard setup in the model list and touch “NEW”...
  • Page 10 Touch IMP.M IMP.M Touch Touch EXP.M EXP.M Touch Touch IMP.M EXP.M Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 11: Imp.m (Imp. Model)

    Touch Touch 1-3. IMP.M (IMP. Model) It is used to copy the model memory in SD Card into the model list of transmitter. To make use of IMP.M function, you need SD Card that has the programmed model file. If you put SD Card into SD Touch Touch Card slot on the back of transmitter, “SD Card”...

  • Page 12: Exp.m (Exp Model)

    Check Check IMP.M IMP.M Touch EXP.M EXP.M Touch Touch Touch IMP.M IMP.M IMP.M Touch EXP.M EXP.M EXP.M Touch IMP.M IMP.M IMP.M EXP.M EXP.M EXP.M Touch Touch 1-4. EXP.M (EXP Model) This function is used to copy the model in transmitter into SD Card. In order to use EXP.M function, you need to plug SD Card into SD Card slot on the back of transmitter.

  • Page 13: Cpy(Model Copy)

    1-6. CPY(Model Copy) 1-5. RES(RESET) The Copy function is used to copy the programmed values of a model into the other model. It allows you to remove the selected models in model list. Refer to the example of Model 01 Touch the source model to copy, it is activated in blue.

  • Page 14: Model Type 3. E

    2. Model type It is used to reset the model type. Please note that all the value, excepting for model name, is reset when “Model type” is set again. Touch “Model type” icon on base menu page to call the model type setup page, the preset “model type”, “swash type”...

  • Page 15: Reverse

    Touch Touch 4. Reverse It is used to reverse the operation of an individual servo. Touch the “Reverse” icon in the base menu page to call the Reverse setup page. In “Reverse” page, you are able to reverse the oper- ation of a servo.

  • Page 16: Sub-Trim

    Touch Touch Touch Touch Touch Touch 5. Sub-Trim It is used to set the servo neutral position, and may be used to make fine adjustments to Touch control surface without hooking linkages and pushrods up. The trim for transmitter stick should be in center position at the first and then Sub-Trim should be set.

  • Page 17: Thr.cut

    Touch Touch 6. THR.CUT This function is used to stop the operation of engine. THR.CUT function works from below one-third position of the full movement range of throttle stick. Touch “THR.CUT” icon in the base menu page to call the “THR.CUT” setup page. When touching “INH” icon in “ACT” line, you may change the value to “OFF”.

  • Page 18: Tx Ctl

    To make use of this function, a receiver should be bound first. Bind receiver and transmitter 7. TX ctl and then touch “Set” icon in “TX OUT SET” to call “TX OUT SET” setup page. In the page, the It consists of the multiple functions for a transmitter. It includes “BIND ON/OFF”, “TX OUT SET”, different number of channel is displayed according to the bound receiver.
  • Page 19 Touch Touch Touch - RF ON/OFF It is used to turn on or off transmitter’s “RF” function. If you are not flying a model but programming transmitter only, you are able to save the battery of the transmitter by setting RF to turn off.

  • Page 20: Timer

    8. TIMER - DSC OUTPUT Timer function may be set for any desired time ,i.e. model time, date, time, etc. Two independ- It is used to set the number of channel when Trainer function is used with DSC jack. If 5 channels ent timers, TIMER1 and TIMER2, are provided for each model.
  • Page 21 Touch Touch Touch the value in “MODE” line to select “UP” or “DOWN”. Timer may be counted down or counted up with your choice. Count-up timer is to count from zero to the setup time and Count-down timer is to count from the setup time to zero. Touch After “ALARM”...
  • Page 22 Touch Touch After RESET SW is set, you may set “LAP SW” function. Touch “NULL” icon in “LAP SW” to call “select” message popup. Now, move the switch with your choice then this switch is set on/ off switch for “LAP SW” and the switch direction setup page appears. You may change ON/OFF by touching icons.
  • Page 23 Touch Touch Touch Touch Touch Touch Touch Touch “NEXT” icon on the right in Timer 1 setup page, you may call Timer 2 setup page. You are able to set Timer 2 as the same as explained above. Timer 2 don’t have the function of the flight data saving so it can calculate the time only.

  • Page 24: Failsafe

    Touch Touch Touch Touch Touch Touch Touch 9. FAILSAFE When you bind your transmitter, you are programming the receiver with failsafe defaults. If con- nection is lost between the transmitter and receiver, the receiver immediately operates in those preprogrammed default positions. The default value is “Hold”...
  • Page 25 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 26: Trim Step

    10. TRIM STEP It allows you to check all values of “Digital trim step”, “DT1”, “DT2”, ‘Digital volume”, and “Side slide”. Touch “Trim Step” icon in base menu page to call Trim Step setup page. The step values in T1, T2, T3, T4 indicate servo movement per click of trim. “4” is set by default, which means that trim will travel as much as 4 by each click of trim Touch and activate the step values and then adjust them with INC”...

  • Page 27: Servo

    Touch Touch Touch Touch Touch Touch Touch Touch 11. SERVO It is used to test a servo and check the servo movement in a graph. You are able to test the servo movement from 0.5sec to 5 sec with your choice. Touch “Servo” icon in the base page to call the servo setup page.

  • Page 28: Ch Set

    12. CH Set It is used to set the channel of a transmitter. The basic setup of the transmitter’s channel is set T:CO T:CO differently depending on 3 different types (“model type”, “wing type”, and “swash type”) and mz- Touch 24 offers AUX channel to set the switch, volume, and side lever for your purpose.

  • Page 29: Function Menu (Helicopter)

    Touch Touch Touch Touch Touch Touch FUNCTION MENU (Helicopter) 1. Q.LINK This function is used to set Q.LINK and assign all switches including sticks, switches, trim levers and trim switches as Q.LINK selection switches to cope with various flight conditions such as 3D flight.

  • Page 30: New

    1-1 NEW This function is used to create new Q.LINK. Touch the value in “Q.LINK” line to activate it in blue and touch “NEW” icon in the right to call “CTRL” and “DELAY” options. In “CTRL” setup, touch “NULL” icon to call “Select” message popup and move the switch or stick with your choice then the Hold Hold switch or stick is set to Q.LINK switch.

  • Page 31: Cpy

    Hold Hold Hold Touch ldle-up1 ldle-up2 ldle-up3 Touch 1-4 Del It is used to delete the unused Q.LINK. Touch the entry in Q.LINIK line that you want to delete to Touch activate in blue and touch “DEL” icon. Now, the selected Q.LINK entry is deleted in Q.LINK list. If Hold you touch “NEXT”...
  • Page 32 2. D/R, EXP Dual Rates and exponentials are available on all channels including aileron, elevator and rudder channels. This adjusts control rates for servos. Adjust the throws (Dual Rate) and center sensitivity (Expo) of the control’s range independently. You may assign a switch for moving between control rates for a servo channel and Dual Rates and exponentials are available on each Q.LINK as well Dual rate is a percentage of the Travel Adjust.
  • Page 33 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 34: Pit.crv

    Touch Touch Telemetry In FUNCTION page, touch “PIT.CRV” icon to call PIT.CRV setup page. You need to mark the point on graph first and then adjust the operation curve with “DEC”, “INC”, X-axis and Y-axis buttons. Touch “ST OFF” to change to “ST ON” then the throttle position line appears on graph.
  • Page 35 TRIM TRIM TRIM TRIM Touch Touch Touch Touch TRIM TRIM TRIM TRIM Touch Touch Touch TRIM TRIM TRIM TRIM Touch Touch Touch Touch TRIM TRIM TRIM TRIM Touch Touch...
  • Page 36 Q.LINK (idel-up2) TRIM TRIM TRIM Touch Touch Q.LINK (Hold) TRIM Touch Touch Telemetry If you touch OFF icon in Curve line, it is switched to ON and the operation curve is smoother. After setup, touch “TRIM” icon in the top right to call the pitch, throttle curve trim setup page. TRIM TRIM Touch...

  • Page 37: Thr.crv

    TRIM Touch +076% +076% Telemetry In FUNCTION page, touch “THR.CRV” icon to call THR.CRV setup page. You need to mark the point on graph first and then adjust the operation curve with “DEC”, “INC”, X-axis and Y-axis but- tons. Touch “ST OFF” to switch to “ST ON” then the throttle position line appears on graph. Move throttle stick and place the line at the desired position between point “L”...
  • Page 38 TRIM TRIM TRIM TRIM Touch Touch Touch :63P TRIM TRIM TRIM TRIM 63-5W Touch Touch Touch TRIM TRIM TRIM TRIM Touch Touch TRIM TRIM TRIM TRIM Touch Touch...

  • Page 39: Gyr/Gover

    TRIM Touch Touch Touch Telemetry If you touch OFF icon in Curve line, it is changed to ON and the operation curve is smoother. NORMAL MODEL NAME 1 You may set the pitch, throttle curve trim by touching “TRIM” icon in the top right. The setup TRIM Touch method is explained at PIT.CRV...
  • Page 40 Touch Touch Gyro Suppression Gyro Suppression TRIM TRIM Telemetry Gyro Gain, Governor, Governor RATE, Gyro Suppression are available in this function - Gyro Gain is used to adjust the sensitivity of gyro. “00%” is basically set and heading lock gyro is operated at over 40% of sensitivity.

  • Page 41: Thr.hold

    Touch Touch Gyro Suppression Gyro Suppression TRIM TRIM Telemetry Touch Touch Gyro Suppression TRIM Telemetry 6. THR.HOLD Touch This function is for powering down an engine or motor using a designated switch. Throttle hold has higher authority than any other flight mode. When you activate THR.HOLD, the throttle channel is driven to its programmed value.

  • Page 42: Swash

    Touch Touch Touch Telemetry Touch Touch 7. SWASH The swash function supports adjustment of the travel amount and direction of the aileron, eleva- Touch tor and pitch in Helicopter mode. Bind a helicopter to a receiver and set the travel amount and direction of the swash channels desirably Touch “SWASH”...
  • Page 43 8. S.Limt (Swash Limit) This function makes transmitter recognized the square stick travel to a circular stick travel. Even the channels of PITCH, AILE and ELEV which controls the swash plate are driven to out of circle, servos are operated in the setup circle only.
  • Page 44 (RATE) (RATE) Touch Touch Touch Telemetry Touch Touch (RATE) (RATE) Touch Touch Touch (RATE) (RATE) Touch Touch Touch Touch Touch (RATE) (RATE) Touch Touch...

  • Page 45: Thr.mix

    (RATE) Touch Touch Telemetry 10. THR.MIX THR.MIX function prevents RPM decay when PITCH, AILE and ELEV inputs are given. This mix advances the throttle position with mix control to maintain RPM. This function can be adjusted for each condition of Q.LINK and three types is available (AILE>>THRO, (RATE) (RATE) ELEV>>THRO, RUDD>>THRO)
  • Page 46 - CTL setup with a switch Touch “NULL” icon in CTL line to call “Select” message popup then move the switch with your choice then that switch is designated as on/ off switch and then the switch direction setup Touch page appears.
  • Page 47 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...
  • Page 48 Touch Touch Touch Touch Touch Touch Telemetry 11-2. Curve mixing type In the prog.mix page, touch “NEXT” icon to call the next page. Number 6~8 are used for PRO. MIX curve mixing. Touch any of them to switch to ON in ACT line. If so, mixing is available to use.
  • Page 49 - CTL setup with a stick Hoping that you would refer the explanation as explained above Touch Here, you need to set the operation value, “L” and “H” points are set by default and you need to mark 5 points between “L” and “H” on graph first and then adjust the operation curve with Touch “DEC”, “INC”, X-axis and Y-axis buttons.

  • Page 50: Trainer

    Touch Touch Touch Touch Touch Touch Touch Touch Touch 12. Trainer (Helicopter, Airplane, Gilder) mz-24 features a programmable trainer function. Two transmitters must be connected by Wireless or an optional DSC code. This function makes it possible for the instructor to choose which functions and channels are to be used for instruction.
  • Page 51 Assigned the desired channel to Pupil transmitter by touching “TEACH” icon to switch to PU- PIL and touch “NULL” icon in CTL line to call “Select” message popup. Move the switch with your choice then that switch is designated as on/ off switch, but we recommend to use S8 as the trainer switch.

  • Page 52: Pit >>Rudd

    13. PIT >>RUDD This function is used to correct the unintended movement of rudder during the flight of a helicop- ter. It is not necessary when you make use of heading lock gyro Touch “PITT >> RUDD” icon in the function page to call PIT >> RUDD setup page. You need to mark the point on graph first and then adjust the operation curve with “DEC”, “INC”, X-axis and Y-axis buttons.

  • Page 53: Telemetry

    Touch Touch Touch Touch Touch Touch Telemetry Touch 14. Telemetry It is used to perform the programming setup and check HoTT telemetry functions. Touch “Telem- etry” icon to call the Telemetry page. You may program 5 types of “RX SELECT”, “SETTING & DATA VIEW”...

  • Page 54: Setting & Data Viwe

    Touch • OUTPUT CH The receiver’s out channel is programmed in OUTPUT CH line. Touch “SET” icon to activate 14-2. SETTING & DATA VIEW the value in red and select the desired channel with INC and DEC buttons. Touch “SET” icon It is used to program or check telemetry data of a receiver and telemetry sensors.
  • Page 55 • REVERSE It is used to reverse the operation of an individual servo. Touch “SET” icon to activate “OFF” in red and touch INC and DEC buttons to switch to “ON”. Touch “SET” icon again to deactivate the value and touch INC buttons to move the cursor to “CENTER”.
  • Page 56 Touch Touch Touch Touch Touch • LIMIT -, + The function supports the adjustment of servo’s maximum travel amount for +,- direction. 150% is set by default. Since LIMIT -, + function is regulated by SERVO EPA of transmitter, you need to adjust SERVO EPA of transmitter to 150% to use 150% of LIMIT -, + Touch “SET”...
  • Page 57 Touch INC button to move the cursor to “INPUT CH” and touch “SET” icon to activate the value in red then select the channel to be connected to “OUTPUT CH” with INC and DEC buttons. Touch “SET” icon again to deactivate the value. Touch INC button to move the cursor to “MODE” Touch Touch Touch...
  • Page 58 Touch Touch Touch Touch Touch Touch Touch • DELAY It is used to set the time delay. The failsafe will delay for the setup time. Touch “SET” icon to activate the value in red and adjust the value with INC and DEC buttons. Touch “SET”...
  • Page 59 - RX FREE MIXER This function is used to correct the unintended movement of airplane during the flight by mixing master channel and slave channel. • MIXER You may decide MIXER number that you want to set. Touch “SET” icon to activate the value in red and select MIXER number with INC and DEC buttons.
  • Page 60 • MASTER CH You may set the master channel of FREE MIXER. Touch “SET” icon to activate the value in red and select the master channel number with INC and DEC buttons. Touch “SET” icon again to deactivate the value. Touch INC button to move the cursor to “SLAVE CH”...
  • Page 61 Touch Touch • TAIL TYPE You may select the appropriate tail type for the airplane that you use Touch “SET” icon to activate the value in red and select the appropriate tail type with INC and DEC buttons. Touch “SET” icon again to deactivate the value. Touch “ENT” icon on the right to access to the next page, “RX CURVE”, Touch Touch...
  • Page 62 - RX CURVE It is used to set the curve of CH2, CH3, and CH4 and 3 types of A, B, and C are selectable. > A type: Sensitive operating > B type: Normal operating > C type: smooth operating The default, B type is set and it is very similar with “EXP”...
  • Page 63 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...
  • Page 64 • ALARM VOLT It is the low voltage alarm setup for receiver power battery. Transmitter sounds an alarm throughout telemetry technology when the battery of receiver reaches the low voltage limit. Touch “SET” icon to activate the value in red and adjust the value with INC and DEC buttons. Touch “SET”...
  • Page 65 Touch Touch - CH OUT TYPE It is used to set the type of receiver’s signal output and it consists of ONCE, SAME, SUMO 12, SUMI, and SUMD HD12. > ONCE: This type is applied to the analog servo. “20msec” is automatically set to PERIOD in RX SERVO setup >...

  • Page 66: Sensor Select

    14-4. RF STATUS VIEW It shows RF status between transmitter and receiver throughout telemetry function Touch “>>” icon in RF STATUS VIEW line then the indication to show the RF connection status is displayed by graph. Touch Touch 14-3. SENSOR SELECT This function is used to program telemetry sensor that is connected to HoTT receiver.
  • Page 67 - TRIG You may designate the transmitter control for the voice options of transmitter, receiver and sensor. The next voice option is came in turn whenever the control is on/off Touch To set TRIGGER, touch “NULL” icon to call the “Select” message popup. Move the switch or volume with your choice then that switch or volume is designated as on/ off key and then the key direction setup page appears.
  • Page 68 - TRANSMITTER - VARIO You may designate the transmitter control for the voice options of Vario module. You may select the Voice options to use or not to use. 6 Voice options, TX VOLT, MODEL TIME, BATT TIME, TIMER1, TIMER2, and CURRENT TIME, are available Touch “NULL”...
  • Page 69 Touch Touch Touch - ELEC MOD You may decide the Voice options of ELEC MOD to use or not to use. 22 Voice options, C1L, Touch C2L, C3L, C4L, C5L, C6L, C7L, C1H, C2H, C3H, C4H, C5H, C6H, C7H, BV1, BV2, BT1, BT2, ALT, CUR, POW, CAP, are available.
  • Page 70 - VARIO MOD You may decide the Voice options of VARIO MOD to use or not to use. 3 Voice options, ALTI- TUD, MAX ALT and MIN ALT, are available. Touch “>>” icon to call the VARIO MOD setup page. All the functions are marked with red dot by default in the page.

  • Page 71: Display Setup For Telemetry Sensor

    Touch Touch Touch 14-6. DISPLAY SETUP FOR TELEMETRY SENSOR Touch All telemetry indication of the sensors are displayed at the receiver telemetry page. Connect option sensors to receiver and access to the sensor select setup page by course of page transfer. Touch “OFF”...

  • Page 72: Function Menu (Airplane, Gilder)

    FUNCTION MENU (Airplane, Gilder) Touch 1. Q.LINK This function is used to set Q.LINK and assign all switches including sticks, switches, trim levers and trim switches as Q.LINK selection switches to cope with various flight conditions such as 3D flight. Since the adjusted value is activated by moving the switch and you can cope with special tasks with switch, it makes you operating the flight much easier.

  • Page 73: Nam

    Touch Touch 1-2 NAM It is used when to revise the name of “Q.LINK”. Touch the target value in “Q.LINK” to activate in blue. Now touch “NAM” icon to call NAM setup page. In the page, enter the desired name using the keypad.

  • Page 74: Cpy

    Touch Touch Touch Touch Touch 1-4 DEL It is used to delete the unused Q.LINK. Touch the entry in Q.LINIK line that you want to delete to 1-3 CPY activate in blue and touch “DEL” icon. Now, the selected Q.LINK entry is deleted in Q.LINK list mz-24 supports copying the preset Q.LINK setup data into another Q.LINK.
  • Page 75 1-5 NEXT If you touch “NEXT” icon, you may call the next page Touch Touch Touch 2. D/R, EXP Dual Rates and exponentials are available on all channels including aileron, elevator and Touch rudder channels. This adjusts control rates for servos. Adjust the throws (Dual Rate) and center sensitivity (Expo) of the control’s range independently.
  • Page 76 After “D/R”, “EXP” setup, perform CTL setup. It is used to assign the switch to D/R, EXP function Touch “NULL” icon in CTL line to call “Select” message popup and move the switch that you want to use then that switch is set on/ off switch and the switch direction setup page appears. You may select ON or OFF by touching icons.

  • Page 77: Wing Mix

    3. Wing MIX Wing MIX consists of various mixing functions which are essential to fly. There are three types mix, RUDD>>AILE”, “AILE>>RUDD”, and “RUDD>>ELEV” In FUNCTION page, touch “Wing MIX” icon to call “Wing MIX” setup page. Touch “INH” icon in “ACT”...
  • Page 78 (RATE) (RATE) Touch Touch Touch Touch (RATE) (RATE) Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 79: Thr.crv

    In FUNCTION page, touch “THR.CRV” icon to call THR.CRV setup page. You need to mark the point on graph first and then adjust the operation curve with “DEC”, “INC”, X-axis and Y-axis buttons. Touch “ST OFF” to switch to “ST ON” then the throttle position line appears on graph.
  • Page 80 Touch Touch Touch Touch Touch Touch Touch Touch Touch Telemetry...

  • Page 81: Prog.mix

    5. Idle LOW It is used to lower the idle speed of the engine temporarily when airplane lands In FUNCTION page, touch “Idle LOW” icon to call “Idle LOW” setup page and touch and switch “INH” in ACT line to “ON” then Idle LOW function is activated. Touch “ON” in CTL line to call “Select”...
  • Page 82 6-1. Liner mixing type In FUNCTION page, touch “Prog.MIX” icon to call the prog.mix page. Touch “INH” icon in ACT line to switch to “ON” and touch “NONE” in MST line to call the mixing channel setup page. Touch and activate “NONE”...
  • Page 83 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...
  • Page 84 6-2. Curve mixing type In the prog.mix page, touch “NEXT” icon to call the next page and touch “INH” icon in the Touch cross line of NO7 and ACT to switch to “ON”. Touch “NONE” in MST line to access the channel selection page and touch and activate “NONE”...
  • Page 85 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 86: Snap Roll

    Touch Touch 7. Snap roll It is used to select the switch and adjust the value of AILE, ELEV, RUDD channels for the snap roll function. Four snap roll directions can be set for your convenience. In function page, touch “Snap roll” icon to call the snap roll setup page. Touch “INH” icon in ACT line to switch to ON.

  • Page 87: Aile Diff

    Touch Touch Telemetry Touch 8. Aile diff This function decreases the amount an aileron moves down without affecting the amount the other aileron moves up. This can decrease adverse yaw (right or left movement of the aircraft nose) tendencies during roll maneuvers. Touch “Aile diff”...

  • Page 88: Flap Mix

    9. Flap MIX It consists of 4 mixing types, “FLAP”, ”AILE>>FLAP”, “ELEV>>FLAP”, and “FLAP>>ELEV”. All of 4 mixing types are closely related with Q.LINK setup and the different values can be set to each individual Q.Link for 4 mixing types 9-1.
  • Page 89 Touch OFFSET OFFSET Touch Touch Touch Touch OFFSET OFFSET Touch Touch Touch Touch Touch OFFSET OFFSET Touch Touch Touch Touch OFFSET Telemetry...

  • Page 90: Aile >> Flap

    Touch Touch 9-2. AILE >> FLAP This mixing allows the entire trailing edge of the wing (aileron and flap) to operate as ailerons. When active, as aileron is applied the flaps also move so that the airplane rolls faster. In FLAP MIX page, touch “INH”...

  • Page 91: Elev >> Flap

    Touch Touch Touch Touch Touch 9-3. ELEV >> FLAP This mixing creates more lift of airplane, allowing a tighter turn. The entire trailing edge of the wing (aileron and flap) operates as flaps when elevator is applied. Touch INH icon in ACT line to switch to “ON”...

  • Page 92: Flap >> Elev

    Touch Touch Touch Touch Touch 9-4. FLAP >> ELEV This mixer is used to set elevator (pitch-trim) compensation when a flap command is given. This typically enables you to adjust the model’s airspeed automatically when flaps are lowered. In FLAP MIX page, touch “INH” icon in ACT line to switch to “ON” then FLAP >> ELEV function is activated.

  • Page 93: Flap Sett (Airplane, Gilder)

    Touch Touch Touch Touch Touch Touch Touch Touch Touch 10. Flap sett (Airplane, Gilder) This mixing allows that the aileron, flap and elevator setups are applied at the same time by operating a switch. It can be also applied to Camber mix, Launch mode and Speed mode. Touch “Flap sett”...
  • Page 94 When the key is moved to the direction of ON, the function is operated. Touch “BACK” icon to the previous page. Now, you may set the operation value. Touch and activate the values in blue and adjust them with “INC” and “DEC” buttons. FLAP and ELEV can be programmed in the same way after accessing the next page.

  • Page 95: Airbrake (Airplane)

    11. Airbrake (Airplane) This mixing is used when the airplane is need to land or descent vertically. Airbrake can be set by AILE, FLAP and ELEV. Touch “Airbrake” icon in the function setup page to call the airbrake setup page. The first Touch page is AILE setup and you may access to FLAP, ELEV and AIRBRAKE DELAY setup page Touch...
  • Page 96 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 97: Butterfly (Gilder)

    Touch “ST OFF” to change to “ST ON” then the throttle position line appears on graph. Move throttle stick and place the line at the desired position between point “L” and “H” then touch Touch “ENT” icon on the bottom right. Now the new point is marked in graph. You can mark five points between point “L”...
  • Page 98 Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch Touch...

  • Page 99: System(Helicopter, Airplane, Gilder)

    Touch Touch Touch SYSTEM (Helicopter, Airplane, Gilder) 1. ST mode There are 4 fundamental options for assigning the four control functions (aileron, elevator, rudder and throttle/brake flap) for a winged aircraft model to the two sticks. Just which of these options is Etc.Set chosen depends on the individual preferences of the individual model pilot.

  • Page 100: Etc.set

    Etc.Set Touch Touch Power on Melody Touch Speaker Volume Touch Power on Melody Power on Melody Touch Touch Speaker Volume Speaker Volume Touch Etc.Set Power on Melody Power on Melody Speaker Volume Speaker Volume Touch Touch 3. Etc. set It is used to select the battery type and set battery warning voltage, Power on melody and 4.5V 4.5V Speaker volume.

  • Page 101: Display

    4.5V 4.5V Power on Melody Power on Melody Touch Touch Touch Logo color Speaker Volume Speaker Volume Logo color DEFAULT DEFAULT Glaring sun Glaring sun Touch Touch Etc.Set 4.5V Power on Melody Touch Logo color Logo color Speaker Volume DEFAULT DEFAULT Touch Glaring sun...
  • Page 102 Touch Etc.Set Touch Logo color Logo color BLUE BLUE Touch Glaring sun Glaring sun Touch Etc.Set Touch Touch 5. Stick Cali It is used to calibrate the stick’s neutral position Touch “Stick Cali” icon in the system menu page to call “Stick Cali’ page. The right stick and the left stick of transmitter are calibrated in turn and the stick position is indicated on VERTI, HORIZ with percentage Touch...

  • Page 103: Firmware Update

    Touch Touch Etc.Set Etc.Set Touch FIRMWARE UPDATE Touch For more information on the latest firmware and the related software, please refer to the Touch download menu on our website www.openhobby.com, www.graupner-sj.com NOTICE: The optional USB adapter is needed to update.

  • Page 104: Safety Approval

    - Contains FCC ID: SNL-36204410 - FCC 47 CFR PART 15B • KC Information Product(s) : Graupner/SJ HoTT GR-24L(12 channels) Receiver - FCC ID : ZKZ-33512 Product(s) : Graupner /SJ mz-24 Transmitter - FCC 47 CFR PART 15C - KCC인증번호: KCC-RRM-sjr-16005200, KCC-CRM-sjr-36204410...
  • Page 105 Product(s) : Graupner/SJ HoTT GR-24L(12 channels) Receiver KCC인증번호: KCC-CRM-sjr-16003210 - 방송통신위원회고시 제2013-01호 - 방송통신위원회고시 제2012-102호 “신고하지 아니하고 개설할 수 있는 무선기기” • Caution - This equipment’s aerial must be at least 20 cm from any person when the system is in use. We therefore do not recommend using the equipment at a closer range than 20cm.
  • Page 106 No. S1006...
