33583
Empfänger GR-24 PRO 3xG+3A+3M+Vario
DEUTSCH Seite 2
INhAltsVERzEIchNIs:
1.
hinweise ..................................................................................................................... 02
2.
Funktionen ................................................................................................................. 04
2.1. Binding ......................................................................................................................... 04
2.1.1Binding mehrerer Empfänger ...................................................................................... 04
2.2. Fail-Safe Funktion ........................................................................................................ 04
2.3 Reichweitentest............................................................................................05
2.4 Einbau ins Modell (Fläche).............................................................................................05
2.5 Einbau ins Modell (Heli).................................................................................................05
3.
Empfänger .................................................................................................................. 06
3.1. Anschluss .................................................................................................................... 06
3.2. Empfänger Einstellmenü .............................................................................................. 07
3.3. Freie Mischer ............................................................................................................... 08
3.4 Zuordnen der Kreiselachsen.............................................................................................10
4.
Programmierung der Gyro Einstellungen ............................................................... 12
4.1. Programmierung der PID Regelung ............................................................................ 12
4.2. Faktor programmieren ................................................................................................. 13
4.2.1Programmieren bei Sendern mit Proportionalgebern ...................................................13
4.2.2Programmieren ohne Proportionalgeber........................................................................14
4.3 Initialisierung des Kreisels.............................................................................................14
5.
Firmwareupdate ......................................................................................................... 16
6.
Konformitätserklärung / Garantie /Herstellererklärung / Entsorgungshinweise ........... 50
GRAUPNER/SJ GmbH – Postfach 1242 – 73230 Kirchheim/Teck – www.graupner.de
Bedienungsanleitung
Operating Instructions
Notice d'utilisation
ENGLISH page 18
Revision: Januar 2013
Manual V1.0
FRANÇAIS page 34
Advertisement
Table of Contents
Related Manuals for GRAUPNER HOTT GR-24 PRO
Summary of Contents for GRAUPNER HOTT GR-24 PRO
- Page 1 4.2. Faktor programmieren ....................13 4.2.1Programmieren bei Sendern mit Proportionalgebern ...........13 4.2.2Programmieren ohne Proportionalgeber................14 4.3 Initialisierung des Kreisels.....................14 Firmwareupdate ......................16 Konformitätserklärung / Garantie /Herstellererklärung / Entsorgungshinweise ... 50 Manual V1.0 Revision: Januar 2013 GRAUPNER/SJ GmbH – Postfach 1242 – 73230 Kirchheim/Teck – www.graupner.de...
-
Page 2: Table Of Contents
Programming PID correction................29 4.2. Programming the factors..................30 4.2.1 Programming, transmitter with proportional controls..........30 4.2.2 Programming, transmitter without proportional controls........31 Initialising the gyro....................31 Firmware update.....................33 Conformity declaration / Guarantee / Manufacturer’s declaration / Disposal..50 Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4... - Page 3 Not suitable for children under fourteen years. This receiver is not a toy! The receiver is also equipped with a telemetry function which is only available in combination with a Graupner/SJ HoTT 2.4 system. If you do not own a Graupner/SJ HoTT 2.4 system, the receiver will not work.
- Page 4 Note! Ensure that all your hott components are loaded with the current version of the software at all times. Note! safety is no accident, and radio-controlled models are not playthings! Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
-
Page 5: Functions
2. Functions 2.1. Binding The Graupner/SJ HoTT 2.4 receiver must be “bound” to “its” Graupner/SJ HoTT 2.4 RF module (transmitter) before a radio link can be created between them; this process is known as “binding”. Binding is only necessary once for each combination of receiver / RF module, so the binding procedure described below only needs to be repeated if you add more receivers. -
Page 6: Range-Checking
2.3 Range-checking The range of your Graupner/SJ HoTT 2.4 system can be checked as described in the following instructions. We recommend that you ask a friend to help you with the procedure. Ideally the receiver should already be bound to the transmitter. Install it in the model in its final position. -
Page 7: Installation In The Model (Heli)
(-) is brown, the positive (+) red and the signal orange. The servo sockets of Graupner/SJ HoTT 2.4 receivers are numbered sequentially. The socket for channel 8 can also be programmed to deliver a (digital) sum signal (see section 3.2: Receiver set-up). - Page 8 “Height”. Note: the model’s actual height is adopted as zero when the receiver is switched on; the indicated height is therefore the altitude relative to the launch point. Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
-
Page 9: Free Mixers
“TRAVEL+” lines. Select “0” if you do not require the mixer. Mixer ratio (tRAVEl-/+): in these two lines you can define the mixer ratio in relation to the source channel (FROM CHANNEL); the value is set separately for both directions. Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4... - Page 10 (channel 6 for the second elevator servo) RX FREE MIXER < > >MISCHER: MASTER CH: SLAVE CH: >TRIM: >TRAVEL-: +100% TRAVEL+: +100% Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
-
Page 11: Assigning The Gyro Axes
The only option is to re-install it in the model by turning it round physically. However, if your model is fitted with programmable servos (e.g. Graupner DES, HVS or HBS types - see the instructions for the update program ‘Firmware_Upgrade_grStudio - then it is possible to reverse the direction of rotation at the servo itself. - Page 12 You must not fly the model before doing this: crash hazard! ElEVAtOR Model movement Control surface response (seen from the tail) RUDDER Model movement Control surface response (seen from the tail) AIlERON Model movement Control surface response (seen from the tail) Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
-
Page 13: Programming The Gyro Settings
D factor. However, if you select a lower setting for the P factor, then you may be able to set a higher D factor value before the onset of control surface oscillation. The gyro effect can be optimised by fine- tuning the D factor. Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4... -
Page 14: Programming The Factors
• It may be sensible or easier to activate the gyro for one axis only at first, and then to establish the optimum setting for that axis, rather than for several axes simultaneously. Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2.4... -
Page 15: Programming, Transmitter Without Proportional Controls
Gyro suppression reduces the stabilising action progressively as the transmitter controls are deflected away from centre; at +/- 100% the gyro is completely disabled. Your model is now ready to fly .. ! Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4... -
Page 16: Firmware Update
5. Firmware update - graupner gr-24pro 3xg+3a+3m+Vario - 33583 hott receiVer Firmware updates are loaded into the receiver via the Channel 5 output, using a PC running Windows XP, Vista or 7. You will also need the separately available USB interface, Order No. 7168.6 and the adapter lead, Order No. - Page 17 The progress bar shows the transfer proceeding normally. The receiver LED is off during this period, then flashes as soon as the file transfer is complete. Please refer to the detailed update instructions in the Download area for the corresponding item at http://www.graupner.de. Manual Receiver GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
-
Page 18: Conformity Declaration / Guarantee / Manufacturer's Declaration / Disposal
Measures for the efficient use of the radio frequency spectrum § 3 (2) (Article 3 (2)) Kirchheim, 17. April 2013 Ralf Helbing, Geschäftsführer Ralf Helbing, Managing Director Graupner/ SJ GmbH Henriettenstraße 96 D-73230 Kirchheim/Teck Germany Tel: 07021/722-0 Fax: 07021/722-188 EMail: info@graupner.de GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4... - Page 19 Sollten sich Mängel an Material oder Verarbeitung an einem von uns in der Bundesrepublik Deutschland vertriebenen, durch einen Verbraucher (§ 13 BGB) erworbenen Gegenstand zeigen, übernehmen wir, die Fa. Graupner GmbH & Co KG, Kirch- heim/Teck im nachstehenden Umfang die Mängelbeseitigung für den Gegenstand.
- Page 20 If material defects or manufacturing faults should arise in a product distributed by us in the Federal Republic of Germany and purchased by a consumer (§ 13 BGB), we, Graupner/SJ GmbH, D-73230 Kirchheim/Teck, Germany, acknowledge the obligation to correct those defects within the limitations described below.
- Page 21 Si une pièce, que nous avons mise sur le marché allemand, devait présenter un défaut ou un vice caché, matériel ou autre (conformément au § 13 BGB), nous, Sté Graupner/SJ GmbH, Kirchheim/Teck, nous nous engageons à la remplacer dans le cadre ci-dessous.
- Page 22 Pour adresses des points de service situés en dehors de Kirchheim/Teck, Germany guarantees this product for a l'Allemagne s'il vous plaît se référer à www.graupner.de/fr/. period of 24 months from date of purchase. The guarantee applies only to such material or operational defects witch are present at the time of purchase of the product.
- Page 23 In the case of RC models electronic components such as servos, receiver or speed controller must be removed from the product, and taken separately to the appropriate collection point for electrical waste. If you don’t know the location of your nearest disposal centre, please enquire at your local council office. GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
- Page 24 Sur des modèles RC, tous les éléments électroniques, tels que les servos, récepteurs ou variateurs doivent être démonté et recyclé séparément. Renseignez-vous auprès de votre commune pour connaître les centres de collecte et de tri compétents. GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
- Page 25 FCC Information Graupner/SJ GR-12+3xG+3A+3M+Vario HoTT #33583 FCC ID: SNL-16005800 FCC Radiation Exposure Statement FCC Statement This equipment complies with FCC radiation This device complies with Part 15C of the FCC exposure limits set forth for un uncontrolled Rules. Operation is subject to the following two envirionment.
- Page 26 Notizen GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
- Page 27 Notizen GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
- Page 28 Notizen GR-24PRO 3xG+3A+3M+Vario Graupner HoTT 2. 4...
- Page 29 Graupner/SJ GmbH Henriettenstraße 96 D-73230 Kirchheim/Teck Germany www.graupner.de Änderungen sowie Liefermöglichkeiten vorbehalten. Lieferung durch den Fachhandel. Bezugsquellen werden nachgewiesen. Für Druckfehler kann keine Haftung übernommen werden. Specifications and availability subject to change. Supplied through specialist model shops only. We will gladly inform you of your nearest supplier.
