Sip Settings - Furuno FELCOM 250 Operator's Manual

3.5.3

SIP settings

This section describes SIP server settings. Do the procedure if it is necessary to enter
SIP settings.
1. In the [Settings] menu, press 3 to select [SIP] to show the [SIP] menu.
2. Press one of keys 1 -5 depending on your objective.
1: Set SIP client.
2: Set SIP proxy server.
3: Set SIP server port number.
4: Set SIP server authentication interval.
5: Set RTP port.
3. Set SIP by referring to the descriptions in the table.
Menu
Client set.*1
Proxy server *2
S/L port
Expire time
RTP port
*1: To change both extension number and SIP password at the [Client set.] menu, you
must also change a setting of the Web software at the SIP server. (See page 6-7.) The
telephone functions cannot be used if the settings for SIP client and SIP server are
different.
*2: The IP address of the SIP proxy server must be the same as the IP address of the
communication unit in order to use the telephone function.
Item
Phone number Enter extension number (1000 - 9999).
Password Enter SIP password. Up to a maximum of eight
alphanumeric characters (upper case alphabet
only) can be used. This password is for identi-
fication at the SIP server.
Nickname Enter a nickname (maximum of 50 alphabet).
The nickname appears on the display of the
called extension handset.
IP address Enter the IP address of the SIP proxy server.
(IP address for communication unit)
Server port Enter server port number (0 - 65535).
Local port Enter local port number (0 - 65535).
- Enter expiration time (1800 - 7200 (sec.)).
RTP port 1 Enter RTP port 1 (1024 - 9998, even number
only). Set different from RTP port 2.
RTP port 2 Enter RTP port 2 (1024 - 9998, even number
only). Set different from RTP port 1.
3. SETTINGS FOR HANDSET
Description
3-17
