Golf 2004 ➤ , Golf Plus 2005 ➤
Maintenance - Edition 11.2009
All data required are shown on display -1-.
– Press button -arrow- to continue procedure.
→
Visual check:
– Follow instructions on display.
– Perform visual check.
– If visual check is OK press "OK" button. -arrow-.
Note
When "not OK" button is pressed, a check will be carried out.
Connecting diagnostic connector:
• Ignition is switched off.
The visual check is displayed with the prompt to connect the di‐
agnostic connector -arrow A- and to check the "MI lamp"
-arrow B-.
– Follow instructions on display.
– Connect diagnostic cable connector to EOBD connection.
Visual check of MI lamp with ignition switched off:
– Switch on ignition.
– Perform visual check of "MI lamp".
175
5. Exhaust emissions test
