Pin Row C
C38 PCI_C/BE2#
C39 PCI_AD17
C40 PCI_AD19
C41 GND (FIXED)
C42 PCI_AD21
C43 PCI_AD23
C44 PCI_C/BE3#
C45 PCI_AD25
C46 PCI_AD27
C47 PCI_AD29
C48 PCI_AD31
C49 PCI_IRQA#
C50 PCI_IRQB#
C51 GND (FIXED)
C52 PEG_RX0+
C53 PEG_RX0-
C54 TYPE0#
C55 PEG_RX1+
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-B915.
Copyright © 2008 congatec AG
Pin Row D Pin Row C
D38 PCI_AD18 C93 GND
D39 PCI_AD20 C94 PEG_RX13+
D40 PCI_AD22 C95 PEG_RX13-
D41 GND (FIXED) C96 GND
D42 PCI_AD24 C97 RSVD
D43 PCI_AD26 C98 PEG_RX14+
D44 PCI_AD28 C99 PEG_RX14-
D45 PCI_AD30 C100 GND (FIXED)
D46 PCI_IRQC# C101 PEG_RX15+
D47 PCI_IRQD# C102 PEG_RX15-
D48 PCI_CLKRUN# C103 GND
D49 PCI_M66EN (*) C104 VCC_12V
D50 PCI_CLK C105 VCC_12V
D51 GND (FIXED) C106 VCC_12V
D52 PEG_TX0+ C107 VCC_12V
D53 PEG_TX0- C108 VCC_12V
D54 PEG_LANE_RV# C109 VCC_12V
D55 PEG_TX1+ C110 GND (FIXED)
Pin Row D
D93 GND
D94 PEG_TX13+
D95 PEG_TX13-
D96 GND
D97 PEG_ENABLE#
D98 PEG_TX14+
D99 PEG_TX14-
D100 GND (FIXED)
D101 PEG_TX15+
D102 PEG_TX15-
D103 GND
D104 VCC_12V
D105 VCC_12V
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND (FIXED)
