8.4

PCI Configuration Space Map

Table 31 PCI Configuration Space Map
Bus Number Device Number
(hex) (hex)
00h 00h
00h 01h
00h 02h
00h 02h
00h 1Bh
00h (see Note) 1Ch
00h (see Note) 1Ch
00h (see Note) 1Ch
00h (see Note) 1Ch
00h 1Dh
00h 1Dh
00h 1Dh
00h 1Dh
00h 1Dh
00h 1Eh
00h 1Eh
00h 1Fh
00h 1Fh
00h 1Fh
00h 1Fh
01h (see Note) 00h
02h (see Note) 00h
03h (see Note) 00h
04h (see Note) 00h
07h (see Note) 04h
07h (see Note) 05h
07h (see Note) 06h
07h (see Note) 07h
Note
The given bus numbers only apply if all PCI Express Ports are enabled in the BIOS setup. If for example PCI Express Port 2 is disabled then
PCI Express Port 3 will be assigned bus number 3 instead of bus number 4, Port 4 will be assigned bus number 4 and the standard PCI slots will
be assigned bus number 6. Furthermore, the respective PCI Express Root Port is hidden if the corresponding PCI Express Port is disabled.
Copyright © 2008 congatec AG
Function Number PCI Interrupt Description
(hex) Routing
00h N.A. Host Bridge
00h Internal PCI Express Graphics Root Port
00h Internal VGA Graphics
01h N.A. VGA Graphics
00h Internal Intel High Definition Audio Controller (Azalia)
00h Internal PCI Express Root Port 0
01h Internal PCI Express Root Port 1
02h Internal PCI Express Root Port 2
03h Internal PCI Express Root Port 3
00h Internal UHCI Host Controller 0
01h Internal UHCI Host Controller 1
02h Internal UHCI Host Controller 2
03h Internal UHCI Host Controller 3
07h Internal EHCI Host Controller
00h Internal PCI to PCI Bridge
02h Internal AC97 Audio Controller
00h N.A. PCI to LPC Bridge
01h Internal Parallel ATA Controller in enhanced mode
02h Internal Serial ATA Controller in enhanced mode / Parallel ATA and Serial ATA as combined IDE Controller in
compatible mode
03h Internal SMBus Host Controller
xxh Internal PCI Express Port 0
xxh Internal PCI Express Port 1
xxh Internal PCI Express Port 2
xxh Internal Onboard Gigabit LAN Controller
xxh INTA-INTD PCI Bus Slot 1
xxh INTA-INTD PCI Bus Slot 2
xxh INTA-INTD PCI Bus Slot 3
xxh INTA-INTD PCI Bus Slot 4
B915m10 61/92
