9.4.6

I/O Interface Configuration Submenu

Feature
Onboard Audio Controller
Onboard Ethernet Controller
►SIO Winbond W83627
Configuration
►SIO SMSC SCH3114
Configuration
9.4.6.1

SIO Winbond W83627 Configuration

Feature
Serial Port 1/2
Configuration
Serial Port 2 Mode
IR Duplex Mode
IR I/O Pin Select
Parallel Port Address
Parallel Port Mode
EPP Version
Parallel Port DMA
Copyright © 2008 congatec AG
Options Description
Azalia Configure onboard audio controller for AC'97 or Azalia (Intel High Definition Audio) mode.
AC97 Note: Azalia mode requires an external Azalia codec.
Disabled
Enabled Enable or disable the onboard Ethernet controller.
Disabled
sub menu Opens sub menu.
Note: This setup node is only available if an external Winbond W83627 Super I/O has been implemented on the carrier board.
sub menu Opens sub menu.
Note: This setup node is only available if an external SMSC SCH3114 Super I/O has been implemented on the carrier board.
Options Description
Disabled Specifies the I/O base address and IRQ of serial port 1/2.
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Normal Specifies the mode for serial port 2.
IrDA
ASK IR
Full Duplex Select IRDA full or half duplex function.
Half Duplex
SINB/SOUTB Select receiver and transmit pins for IRDA mode.
IRRX/RTX
Disabled Specifies the I/O base address used by the parallel port.
378
278
3BC
Normal Specifies the parallel port mode.
Bi-directional
ECP
EPP
ECP&EPP
1.9 Specifies the EPP version.
1.7
DMA0 Specifies the DMA channel for parallel port in ECP mode.
DMA1
DMA3
