9.4.9.1

USB Mass Storage Device Configuration Submenu

Feature
Emulation Type
9.4.10

Keyboard/Mouse Configuration Submenu

Feature
Bootup Num-Lock
Typematic Rate
PS/2 Mouse Support
Copyright © 2008 congatec AG
Options Description
Auto Every USB MSD that is enumerated by the BIOS will have an emulation type setup option. This option specifies the type of
Floppy emulation the BIOS has to provide for the device.
Forced FDD Note: The device's formatted type and the emulation type provided by the BIOS must match for the device to boot properly.
Hard Disk Select AUTO to let the BIOS auto detect the current formatted media.
CDROM If Floppy is selected then the device will be emulated as a floppy drive.
Forced FDD allows a hard disk image to be connected as a floppy image. Works only for drives formatted with FAT12, FAT16 or
FAT32.
Hard Disk allows the device to be emulated as hard disk.
CDROM assumes the CD-ROM is formatted as bootable media, specified by the 'El Torito' Format Specification.
Options Description
Off Specifies the power-on state of the Num-lock feature on the numeric keypad of the keyboard.
On
Slow Specifies the rate at which the computer repeats a key that is held down.
Fast Slow sets a rate of under 8 times per second.
Fast sets a rate of over 20 times per second.
Disabled Configure PS/2 mouse support.
Enabled Note: PS/2 support for mouse or keyboard is only available if a Winbond W83627 Super I/O or a SMSC SCH3114 Super I/O
Auto has been implemented on the carrier board.
