9.7

Power Setup

Select the Power tab from the setup menu to enter the Power Management setup screen.
Feature
Power Management / APM
Suspend Timeout
Video Power Down Mode
Hard Disk Power Down Mode
<Device>
Resume On Ring
Resume On PME
Resume On RTC Alarm
RTC Alarm Date (Days)
System Time
Power Button Mode
9.7.1

Exit Menu

Select the Exit tab from the setup menu to enter the Exit setup screen.
You can display an Exit screen option by highlighting it using the <Arrow> keys.
Feature
Save Changes and Exit
Discard Changes and Exit
Discard Changes
Load CMOS Defaults
Copyright © 2008 congatec AG
Options Description
Disabled Set this option to allow or prevent chipset power management and APM (Advanced Power Management).
Enabled
Disabled Specifies the length of time of inactivity the system waits before it enters suspend mode.
1- 60 Min
Disabled Specifies the power state that the video subsystem enters when the BIOS places it in a power saving state after the
Standby specified period of display inactivity has expired.
Suspend
Disabled Specifies the power state that the hard disk drives enter after the specified period of hard drive inactivity has expired.
Standby
Suspend
Ignore Determines whether the device activity is monitored by the power management timer or not.
Monitor
Disabled Disable / enable RI signal (= GPE2 on pin 89 of X4 connector) to generate a wake event.
Enabled If enabled wake is possible from all power down states including S5 (Soft Off).
Disabled Disable / enable PCI PME to generate a wake event.
Enabled If enabled wake is possible from all power down states including S5 (Soft Off).
Disabled Disable / enable RTC to generate a wake event.
Enabled If enabled wake is possible from all power down states including S5 (Soft Off).
Everyday, 01....31 Select the day of the month when the event should be generated.
Hour:Minute:Second Select the system time when the event should be generated.
On/Off Specifies if the system enters suspend or soft off mode when the power button is pressed.
Suspend
Description
Exit setup and reboot so the new system configuration parameters can take effect.
Exit setup without saving any changes made in the BIOS setup program.
Discard changes without exiting setup. The option values presented when the computer was turned on are used.
Load the CMOS defaults of all the setup options.
B915m10 88/92
