901 Spa Cabana Gazebo Assembly
Bar Stool
The final step in the assembly of your Cabana Gazebo is the
assembly of your bar stools).
1.
Attach the bar stool legs to the support brace using the
provided 2 1/2" screws. There will be a total of 12 screws.
2.
Place the bar stool seat on a flat surface (make sure that
the finish side is on the ground). Attach the leg assembly
using four 2 1/2" screws.
Page 22
A
Bar stool legs
1. Attach sides to legs.
B
2. Attach seat to leg assembly.
C
2008 Gazebo Owner's Manual
Bar stool
support brace
Bar stool
seat
LTR20081011, Rev. A
