  • Page 2: Table Of Contents

    Pre-Delivery and Installation Checklist ... 1 Planning the Best Location... 2 Portable Spa Site Preparation ... 4 In-Ground Spa Site Preparation ... 4 Getting the Spa Into Your Yard ... 6 Electrical Requirements ... 8 Electrical Requirements – US and Canada ...8 Electrical Installation -- Europe ...

  • Page 3: Pre-Delivery And Installation Checklist

    Pre-Delivery and Installation Most cities and counties require permits for exterior construction and elec- trical circuits. In addition, some communities have codes requiring resi- dential barriers such as fencing and/or self-closing gates on property to prevent unsupervised access to the property by children under the age of 5.

  • Page 4: Planning The Best Location

    Planning the Best Location Safety first Do not place your spa within 10 feet (3 m) of overhead power lines. Make sure the spa is positioned so that access to the equipment compart- ment and all side panels will not be blocked. Be certain that your installa- tion will meet all city and local safety codes and requirements.
  • Page 5 Allow for service access Many people choose to install a decorative structure around their spa. If you are installing your spa with any type of structure on the outside, such as a gazebo, remember to allow access for service. It is always best to design special installations so that the spa can still be accessed.

  • Page 6: Portable Spa Site Preparation

    Portable Spa Site Preparation Your spa needs a solid and level foundation. The area that it sits on must be able to support the weight of the spa, with water and the occupants who use it. If the foundation is inadequate, it may shift or settle after the spa is in place, causing stress that could DAMAGE YOUR SPA SHELL AND FINISH.
  • Page 7 • The spa must be properly back-filled with wet sand, underneath and on all four sides. • The final architecture must include permanent ground coverage within a 10 feet radius of the spa. • Never place any spa in a sealed area. Water must be able either to be absorbed into the surrounding area or channeled away.

  • Page 8: Getting The Spa Into Your Yard

    Getting the Spa Into Your Yard Check the Dimensions of Your New Spa The specification chart on page 26 lists your spa’s model and its dimen- sion as it sits on the delivery cart. During delivery, the spa must remain on the delivery cart at all times.
  • Page 9 LTR20091024, Rev. A...

  • Page 10: Electrical Requirements

    Electrical Requirements Electrical Requirements – US and Canada 240 Volt Electrical Installation All 240V spas must be permanently connected (hardwired) to the power supply. These instructions describe the only acceptable electrical wiring procedure. Spas wired in any other way will void your warranty and may result in serious injury.
  • Page 11 Spa Model All 240V spas (except 6300 control boxes re- quiring high amperage - see below) Spas with the 6300 control box (when high amperage is selected on circuit board) SEE CONFIGURATION INSTRUCTIONS ON NEXT PAGE. F2400 spa with one 5.5 kW heater F2400 and FP2500 spas with two 5.5 kW heaters...

  • Page 12: Testing The Gfci Breaker

    Testing the GFCI Breaker Test the GFCI breaker prior to first use and periodically when the spa is powered. To test the GFCI breaker follow these instructions (spa should be operating): Press the TEST button on the GFCI. The GFCI will trip and the spa will shut off.

  • Page 13: Gfci Wiring Diagram

    GFCI Wiring Diagram LTR20091024, Rev. A...

  • Page 14: Volt Electrical Installation

    120 Volt Electrical Installation Always follow applicable local, state and federal codes and guidelines. Use only a dedicated electrical line with a 20-amp breaker. Cord-and-plug connections may not use a cord lon- ger than 15 ft (4.6 m) and must be plugged into a dedicated 20-amp GFCI connection.

  • Page 15: Electrical Installation -- Europe

    Electrical Installation -- Europe 230 Volt Electrical Installation All 230V spas must be permanently connected (hardwired) to the power supply. These instructions describe the only acceptable electrical wiring procedure. Spas wired in any other way will void your warranty and may result in serious injury.
  • Page 16 Spa Model All 230V spas (except 6205 control boxes re- quiring high amperage - see below) Spas with the 6300 control box (when high amperage is selected on circuit board) SEE CONFIGURATION INSTRUCTIONS ON NEXT PAGE. F2400 spas with one 5.5 kW heater FP2500 spa with one 5.5 kW heater and...

  • Page 17: Rcd Wiring Diagram

    RCD Wiring Diagram LTR20091024, Rev. A...

  • Page 18: Installing The In-Ground Shell

    Installing the In-Ground Shell LTR20091024, Rev. A...

  • Page 19: Equipment Pack Plumbing Connections (In-Ground Spas)

    Equipment Pack Plumbing Connections (In-Ground Spas) The example shown below is typical for a system with two pumps with external heater and external filter. Designer Spa Specifications DIJ401 and DIJ405: Equipment pack weight = 250 lbs. DIJ407: Equipment pack weight = 300 lbs. 2.5 HP heat pump 4 HP swim pump Note: Equipment pack cannot ex-...
  • Page 20 LTR20091024, Rev. A...

  • Page 21: In-Ground Plumbing Connections

    In-Ground Plumbing Connections IMPORTANT! Always check local codes prior to any in-ground spa instal- lation. Once the spa and equipment are properly located, you will want to lay out the plumbing run. Trenches should be deep and wide enough to allow all pipes to be buried below the frost line and should be in as straight a line from the spa to the equipment as possible.
  • Page 22 NOTE: Once complete, water test the plumbing run for at least three days prior to covering any plumbing trenches and back-filling spa cavity completely. NOTE: Some local inspectors require pressure testing the plumbing lines. Although the spa is pressure tested at the factory, local inspectors may insist on pressure testing the plumbing run between the spa and equip- ment pack.

  • Page 23: Electrical And Electronic Connection

    Air Venturi: 1/2” line that is plumbed 18” above the spa’s water level. Topside Control Panel and Temp Sensor: 1” line that connects to the bot- tom of the control box located on the equipment pack. Electrical and Electronic Connection Remote Equipment Topside Control Panel The next few steps to complete the installation should be performed along with installation of the temperature sensor and 12V spa light wiring (if ap-...
  • Page 24 NOTE: Circuit board programming will not allow spa operation without both the temperature and high limit sensors being properly connected to the circuit board. Once topside panel operation is verified. Turn off power, disconnect the extension loom from the circuit board and GENTLY route through conduit to complete installation.
  • Page 25 Light niche and any metallic items in a 5’ (152 cm) radius must be properly bonded with #8 AWG grounding wire. Connect rigid conduit to the 3/4” hub located at the back of the light niche and run to a water resistant junction box (or for 12 volt models to a low voltage transformer) no further than 25’...
  • Page 26 LTR20091024, Rev. A...

  • Page 27: Pouring The In-Ground Spa Deck

    Pouring the In-Ground Spa Deck It is recommended that all electrical hook ups and all plumbing be com- pleted before pouring the concrete. Make certain all electrical inspections on lights, bonding and all other electrical work have been completed and checked off by the local inspectors prior to proceeding with your concrete or finish work.

  • Page 28: Spa Technical Specifications

    Spa Technical Specifications All sizes on this chart represent outside dimensions. Due to our continu- ous improvements, specifications, size and pricing are subject to change without prior notice. Avalon Series Model Width A515 84" A526 84" A534 84" A726B 84” A726L 84”...
  • Page 29 Classic Series Model Width CL-25 64” CP-36 84” CT-36 84” CP-50 84” CT-50 84” CT-64 84” CP-65 84” CV-35 93” CA-65 93” CA-36 93” CBA-36 93” CD-46 93” CM-47 93” CA-50 93” CBA-50 93” CBA-64 93” CN-50 93” CN-65 93” CE-57 93”...
  • Page 30 Family II Series Model Width F515R 78" F518S 43” F520B 54" F730B 84" F730L 84" F732B 84" F732L 84" F745B 84" F745L 84" F748L 84" F830B 93" F830L 93" F845B 93" F845L 93" F848L 93" F864L 93" Escape Series Model Width EIII732B 84"...
  • Page 31 Ultimate Fitness and Fitness Pro Series Model Width F854 93” F1257 96” FP1455 96” FP1755 96” F2400 96” FP2500 96” FP4700 96” Victory Extreme Series Model Width VX-901 72” VX-624B 76” VX-724L 78” VX-726B 84” VX-726L 84” VX-740L 84” VX-834B 93”...

  • Page 32: East Ninth Street Pomona, Ca

    LMS Customer Service Department 1462 East Ninth Street Pomona, CA 91766 Toll Free: 1-800-CAL-SPAS Fax: 1-909-629-3890 www.calspas.com LTR20091024, Rev. A 12/15/08...
