Go Power! GP-SW3000, GP-SW2000, GP-SW1000and GP-SW600
10. Configuring your GP-SW3000, GP-SW2000, GP-SW1000,
and GP-SW600
10.1 Configuring the Dip Switches
GP-SW3000, GP-SW2000, and GP-SW1000
For a typical North American system, set the Frequency to 60 Hz.
For more information on power saving, please see 5.10 and 5.11 sections
Switches are located on the front panel. Power saving is enabled and adjusted through dip
switches S1, S2, and S3 on the front of the inverter. To disable power saving, leave dip
switches S1, S2 and S3 in the OFF or 0 position
Power Saving
Disable
> 7 W
> 15 W
> 20 W
> 28 W
> 35 W
> 42 W
> 50 W
GP-SW1000, GP-SW2000, and GP-SW3000
S4 Freq. (Hz)
0 50
1 60

10.2 Other Dip Switches (Professional Installer Only)

The default voltage setting for the GP-SW600, GP-SW1000, GP-SW2000, and
GP-SW3000 is 115 V AC, however all these inverters may be configured for other
voltages by a professional installer via the two red dip switches located close to the AC
connection inside each unit. The unit must be restarted in order for any changes to take
effect.
SW1
Off
On
Off
On
S1 S2
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
SW2
Off
Off
On
On
Owner's Manual
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
GP-SW600
Dip Switch Freq. (Hz)
Up 50
Down 60
VAC
100
110
115
120
