Go Power GP-SW3000 Owner's Manual page 12

Go Power! GP-SW3000, GP-SW2000, GP-SW1000and GP-SW600
3.2.2 Rear view (GP-SW1000)
b) Remote port
a) Chassis ground
Operation of the inverter without a proper ground connection may result
in an electrical safety hazard.
a. Chassis Ground:
Ground to vehicle chassis using # 8 AWG wire.
b. Remote Port:
An optional remote is available from Go-Power.
c. Ventilation port:
Do not obstruct, allow at least one inch for airflow.
d. Battery terminals:
Connect to 12 V battery or other 12 V power source. [+] is positive and [-] is negative.
Reverse polarity connection will blow the internal fuse and may damage inverter
permanently.
c) Ventilation port
d) Battery terminals
Owner's Manual
12
