Go Power! GP-SW3000, GP-SW2000, GP-SW1000and GP-SW600
5. Install inverter fuse (not included) in positive lead. Fuse should be located within 12" of
battery. Ensure all connections are tight and secure. (See Section 4.3)
6. Connect the cable from the positive terminal of inverter to the positive terminal of the
battery. Make a secure connection.
7. Set the power switch to the ON position. Check the indicators on the front panel of the
inverter. The Input Level LED should be green or yellow, depending on the voltage of
the power source. If it is not, check your battery bank and the connections to the
inverter.
8. Set the power inverter switch to the OFF position. The indicator lights may blink and
the internal alarm may sound momentarily. This is normal. Plug the test load into the
AC receptacle on the front panel of the inverter. Leave the test load switch OFF.
(For the Hard Wire option, please see Section 4.3).
9. Set the power inverter switch to the ON position and turn the test load on; the inverter
should supply power to the load. If you plan to measure the output voltage of the
inverter, a true rms meter must be used for accurate readings.
The GFCI outlet and the Hard Wire terminal of the GP-SW3000 are
rated for 20 amps or 2200 watts each. Do not exceed a combined load
of 20 amps or 2200 watts for either the GFCI outlet or the Hard Wire
terminal. Do Not jumper the GFCI outlet or the Hard Wire terminal
together.
4.3 Hard Wire (GP-SW3000 and GP-SW2000
Ensure the inverter is turned off if connecting the Hard Wire option.
The GP-SW3000 and GP-SW2000 AC output may be hard wired into the inverter.
Remove the four screws that surround the AC outlet and strain relief clamp to reveal a
two-connection terminal strip. Feed a user-supplied power cable through the strain relief
clamp, tighten the clamp, and make the connections.
The Black or HOT wire output is labeled "L" and the white or NEUTRAL wire output is
labeled "N". The Green or GROUND wire connection is labeled "FG" or with the standard
ground symbol and is located to the right of the terminal strip. The National Electrical Code
recommends no less than #12 gauge wire for this application. Seek professional
assistance if you are unfamiliar with electrical wiring.

4.4 Cables

Install the inverter fuse into the positive lead. Fuse should be located
within 12" of battery. Ensure all connections are tight and secure.
GP-SW600-12V: Please use 8 ft or less of #6 Cable with a 70 Amp fuse.
GP-SW600-24V: Please use 8 ft or less of #8 Cable with a 70 Amp fuse.
A GP-DC Kit 2 suitable for both 12 and 24 V applications is available from Go Power Inc.
(please use the included GP-SW600 crimp lugs for this application).
