- Page 1 Go Power! Manual GP-SW3000 Inverter GP-SW2000 Inverter GP-SW1000 Inverter GP-SW600 Inverter Go Power! Electric Inc. PO Box 6033 Victoria, BC V8P 5L4 Tel: 866-247-6527 Fax: 866-607-6527 Email: info@gpelectric.com...
-
Page 2: Table Of Contents
4. INSTALLATION ................11 5. OPERATION ................13 6. OPERATING LIMITS..............15 7. TROUBLESHOOTING ..............15 8. MAINTENANCE ................16 9. WARRANTY.................16 10. CONFIGURING YOUR GP-SW3000, GP-SW2000, GP-SW1000, AND GP-SW600................17 Go Power! Electric Inc. PO Box 6033 Victoria, BC V8P 5L4 Toll Free Tel: 866-247-6527... -
Page 3: Introduction
Inverter Owner’s Manual 1. Introduction The Go Power! Sine Wave series models are used in a wide range of applications including remote homes, RVs, sailboats, and powerboats. It will operate most televisions and VCRs, personal computers, small appliances, and tools such as drills, sanders, grinders, mixers and blenders. - Page 4 Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 2.2 GP-SW2000 W Inverter Model GP-SW2000 – 12 V GP-SW2000 – 24 V Continuous output power 2000 W Surge rating 4000 W Output waveform Sine Wave <3% THD Output Voltage ± 3% 115 VAC RMS Output Frequency ±...
- Page 5 Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 2.4 GP-SW600 W Inverter Model No. GP-SW600 – 12 V GP-SW600 – 24 V Continuous Output Power 600 W Surge Rating 860 W Output Waveform Sine Wave <3% THD Output Voltage ± 3% 115 VAC RMS Output Frequency ±...
-
Page 6: Name And Main Function
Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3. Name and main function 3.1 Front view: GP-SW3000 and GP-SW2000 a) On /Off b) Ventilation c) Input Level d) Load Level i) AC Outlet e) Status Level f) Frequency... - Page 7 Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.2 Front view: GP-SW1000 a. ON /OFF Switch h. AC Outlet g. Load Level f. Input b. Ventilation Ports c. Frequency d. Power Save e. Status a) ON / OFF switch: Power ON/OFF switch, leave in the OFF position during installation.
- Page 8 Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.3 Front view: GP-SW600 g. AC Outlet a. ON /OFF Switch f. Input Level e. Frequency d. Fault c. Load Level b. Ventilation Ports a) ON / OFF switch: Power ON/OFF switch, leave in the OFF position during installation.
- Page 9 Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.4 Rear view: GP-SW3000 and GP-SW2000 a) Ventilation b) Remote Port d) Battery Terminals c) Chassis Ground a) Ventilation port: Do not obstruct, allow at least one inch for airflow.
- Page 10 Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual DC INPUT 10.5–15VDC POS(+) NEG(-) REVERSE POLARITY WILL DAMAGE UNIT c. Chassis Ground Lug d. Battery Terminals a) Remote Port: An optional remote is available from Go-Power Electric Inc. b) Ventilation port: Warning! Do not obstruct, allow at least one inch for airflow.
-
Page 11: Installation
Go Power! GP-SW3000, GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.6 Rear view: GP-SW600 a. Ventilation Port c. Chassis Ground Lug b. Battery Terminals a) Ventilation port: Warning! Do not obstruct, allow at least one inch for airflow. Operation of the... - Page 12 Warning! The GFCI outlet and the Hard Wire terminal of the GP-SW3000 are rated for 20 amps or 2200 watts each. Do not exceed a combined load of 20 amps or 2200 watts for either the GFCI outlet or the Hard Wire teminal.
-
Page 13: Operation
GP-SW600-24V: Please use 8 ft or less of #8 Cable with a 70 Amp fuse. fuse into the A GP-DC Kit 2 suitable for both 12 and 24 volt applications is available from Go Power Inc. positive lead. (please use the included GP-SW600 crimp lugs for this application). - Page 14 5.8 Over Temp Indicator (OTP) During over temp, the fault light (GP-SW600) or status light (GP-SW1000, GP-SW2000 and GP-SW3000) will continually flash red twice every other second, five double beeps will sound and the AC output will disconnect. 5.9 Maximum Load / Overload Indicator (OLP) During maximum load, the GP-SW600, GP-SW1000 and GP-SW2000 Load Level LED will flash red twice per second and five single beeps will sound every eight seconds.
-
Page 15: Operating Limits
5.12 Remote The GP-SW1000, GP-SW2000 and GP-SW3000 are available with an optional remote. The remote will turn the inverter on and off and indicate normal operation or any faults that have caused the inverter to shut down. -
Page 16: Maintenance
We warrant this product against defects in materials and workmanship for a period of two years from the date of purchase and will repair or replace any defective Go Power! Inverter when directly returned, postage prepaid, to manufacturer. This warranty will be... -
Page 17: Configuring Your Gp-Sw3000, Gp-Sw2000, Gp-Sw1000, And Gp-Sw600
Repair or replacement is your sole remedy and Go Power! shall not be liable for damages, whether direct, incidental, special or consequential, even if caused by negligence or other fault.
