Go Power! Manual
GP-SW2000 Inverter
GP-SW1000 Inverter
GP-SW600 Inverter
Go Power! Electric Inc.
PO Box 6033
Victoria, BC V8P 5L4
Tel: 866-247-6527
Fax: 866-607-6527
Email: info@gpelectric.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-SW2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Go Power GP-SW2000

Summary of Contents for Go Power GP-SW2000

  • Page 1 Go Power! Manual GP-SW2000 Inverter GP-SW1000 Inverter GP-SW600 Inverter Go Power! Electric Inc. PO Box 6033 Victoria, BC V8P 5L4 Tel: 866-247-6527 Fax: 866-607-6527 Email: info@gpelectric.com...

  • Page 2: Table Of Contents

    Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual Table of Contents INTRODUCTION ................3 SPECIFICATIONS..............3 NAME AND MAIN FUNCTION ...........5 INSTALLATION ...............10 OPERATION ................12 OPERATING LIMITS..............14 TROUBLESHOOTING .............15 MAINTENANCE ...............15 WARRANTY................16 CONFIGURING YOUR GP-SW2000, GP-SW1000 AND GP-SW600 ....................16 Go Power! Electric Inc.

  • Page 3: Introduction

    Inverter Owner’s Manual 1. Introduction The Go Power! Sine Wave series models are used in a wide range of applications including remote homes, RVs, sailboats, and powerboats. It will operate most televisions and VCRs, personal computers, small appliances, and tools such as drills, sanders, grinders, mixers and blenders.
  • Page 4 Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 2.3 GP-SW600 W inverter Model No. GP-SW600-12 GP-SW600-24 Continuous Output Power 600 W Surge Rating 860 W Input Voltage 12 V Output Frequency Adjustable 50/60Hz +/- 0.05% Efficiency 85%-92% 85%-92% No Load Current Draw 0.90 A...

  • Page 5: Name And Main Function

    Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3. Name and main function 3.1 Front view GP-SW2000: a) On /Off b) Ventilation c) Input Level d) Load Level i) AC Outlet e) Status Level f) Frequency g) Power Saving h) Strain Relief Clamp a) ON / OFF switch: Power ON/OFF switch, leave in the OFF position during installation.
  • Page 6 Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.2 Front view GP SW-1000: a. ON /OFF Switch h. AC Outlet g. Load Level f. Input b. Ventilation Ports c. Frequency d. Power Save e. Status a) ON / OFF switch: Power ON/OFF switch, leave in the OFF position during installation.
  • Page 7 Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.3 Front view GP SW-600: a. ON /OFF Switch g. AC Outlet f. Input Level e. Frequency d. Fault c. Load Level b. Ventilation Ports a) ON / OFF switch: Power ON/OFF switch, leave in the OFF position during installation.
  • Page 8 Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.4 Rear view GP-SW2000: a) Ventilation b) Remote Port d) Battery Terminals c) Chassis Ground a) Ventilation port: Warning! Do not obstruct, allow at least one inch for airflow. Operation of the...
  • Page 9 Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.5 Rear view GP SW-1000: a. Remote Port b. Ventilation Port DC INPUT 10.5–15VDC POS(+) NEG(-) REVERSE POLARITY WILL DAMAGE UNIT c. Chassis Ground Lug d. Battery Terminals a) Remote Port: An optional remote is available from Go-Power Electric Inc.

  • Page 10: Installation

    Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 3.6 Rear view GP SW-600: a. Ventilation Port c. Chassis Ground Lug b. Battery Terminals a) Ventilation port: Warning! Do not obstruct, allow at least one inch for airflow. Operation of the...
  • Page 11 GP-SW600-24V: Please use 8 ft or less of #8 Cable with a 70 Amp fuse. A GP-DC Kit 2 suitable for both 12 and 24 volt applications is available from Go Power Inc. (please use the included GP-SW600 crimp lugs for this application).

  • Page 12: Operation

    GP-SW1000-24V: Please use 10 ft or less of #6 Cable with a 70 Amp fuse. A GP-DC Kit 2 suitable for both 12 and 24 volt applications is available from Go Power Inc. GP-SW2000-12V: Please use 10 ft or less of 2/0 Cable with a 300 Amp fuse.
  • Page 13 During over voltage, the GP-SW600 and GP-SW1000 Input Level LED will continually flash red four times per second, five double beeps will sound, the fault light (GP-SW600) or status light (GP-SW1000 and GP-SW2000) will come on and the AC output will disconnect.

  • Page 14: Operating Limits

    5.12 Remote The GP-SW1000 and GP-SW2000 are available with an optional remote. The remote will turn the inverter on and off and indicate normal operation or any faults that have caused the inverter to shut down.

  • Page 15: Troubleshooting

    Go Power! GP-SW2000, GP-SW1000 and GP-SW600 Inverter Owner’s Manual 7. Troubleshooting 7.1 Common problems Television interference: Operation of the power inverter can interfere with television reception on some channels. If this situation occurs, the following steps may help to alleviate the problem: •...

  • Page 16: Warranty

    We warrant this product against defects in materials and workmanship for a period of 12 months from the date of purchase and will repair or replace any defective Go Power! Inverter when directly returned, postage prepaid, to manufacturer. This warranty will be...
