iNetVu™ Service Manual

3.2.4. Sensor Related

3.2.4.1. Sensor Error / Component Sensor Error

Cause:
i. The sensor cable is not connected properly on the Controller or Platform Side.
ii. Connectors between the internal harness and the platform components (i.e.
Compass, Inclinometer, etc.) have been disconnected
iii. The pins on the Mobile Platform's sensor connector are broken, or bent, and are
making contact with the cable
Solution:
i. Ensure that the sensor cable is properly connected
ii. Remove the azimuth, and elevation cover. Verify all trailer connectors between the
internal wiring harness and the individual components are securely fastened. The
matching connectors between the internal wiring harness, and the components
should be labeled.
iii. Verify that the pins on the Mobile Platform's sensor connector are not broken,
bent, and are making contact with the cable
Page 34 of 109
