■ "Autoimage"
■ "AutoLevel"
■ "AutoCalib"
■ "FixLevel"
■ "FixSpan"
For saving the desired start settings press Enter, whereupon the dialogue will close. Subsequently, the
respective configuration acc. to the dialogue in Fig. 144, Dialogue "Save configuration" page 65 is to be
saved.
Menu item "Video mode"
Fig. 146 Menu „Settings" - "Video mode"
In menu item "Video mode", the video output of the thermographic camera can be changed.
66
User Manual for the Thermographic System VarioCAM
®
VarioCAM hr adjusts the temperature range to the current measurement scene
(Autoimage).
®
VarioCAM hr adjusts the temperature level to the current measurement scene
(Autolevel).
®
VarioCAM hr adjusts the calibration range according to the current temperature
scene.
®
VarioCAM hr starts at the temperature level currently set in the configuration.
®
VarioCAM hr starts in the temperature range currently set in the configuration.
© InfraTec GmbH 2013
® high resolution
8. Operation
