User Manual for the Thermographic System VarioCAM
8. Operation
Via the menu item "Sav. format..", files to be saved additionally to the thermal image and their format
can be selected. For this purpose, a dialogue with four options is displayed (see Fig. 80).
The following table shows which option has which effect:
Saving format Selection 1
Vis* I = saving the visual image in IRB
Audio* I = saving the audiofiles in IRB
Screen P
a PCX file
Data* I = saving measuring definitions in IRB
The T button (tabulator) serves to toggle between the various options. Selection is made by moving the
joystick , . Regardless of the selection made, the data of the thermal image will be saved compressed
and free of loss. When selecting "I", the additionally selected files (VIS or Audio) are contained in the IRB
file. For "B", "W", "P" and "N", additional files whose contents will also be readable by other (standard)
software are generated.
Example:
1. Selecting Vis
image and voice annotation are contained in a (respectively larger) IRB file.
2. Selecting Vis
screenshot as a PCX file. The filenames relate to the one of the IRB file (AA072001.irb,
AA072001.bmp, AA0702001.pcx).
User Manual
= saving the entire current screen as
I and Audio I activates the parallel VIS recording and speech recording. The VIS
B and Screen P activates the saving of the VIS image as a BMP and of the
© InfraTec GmbH 2013
® high resolution
Selection 2
B = saving the visual image as a separate
BMP file
W = saving the audio data as a separate
WAV file
N = saving the entire current screen as a
PNG file
-
43
