User Manual for the Thermographic System VarioCAM
8. Operation
The time of starting the recording needs to be entered into the field "Start". As a preset value, the system
provides the current time when calling up the dialogue for entering the parameters for automatic saving.
Regardless of this, any desired start time between 00:00:00 and 23:59:59 can be set. Should the start
time be set before the current time, the recording will immediately start upon activating this function.
"Interval" indicates in which period (hh:mm:ss) a thermal image is to be saved. The shortest possible
interval is 0.5 s. Please note that the minimum recording period is also affected by the files to be saved
(VIS*, Sceenshot) and by the possibly selected saving modes (e.g. Premium/ResEnh*).
Should shorter interval times be required for recording a sequence of thermal images, using the internal real-
time memory* (see Menu "File" menu item "BG-memory") is recommended.
The box "Count" indicates how many thermal images are to be saved/recorded. The maximum possible
number is 99,999 images.
The box "PremiumSnap" indicates if the thermal images are to be saved in Premium mode (see Fig.
115, Menu "Settings" - "Extra") for reducing the noise in these thermal images.
The values in the various input boxes (figures) can be set by moving the joystick
 
joystick and serves to move among the positions in the input boxes. The
key) is used to jump between the various input boxes. Enter saves the sequence settings. The settings
will be dismissed and the dialogue exited if the
When serial measuring is running, the filenames of the currently saved data are displayed.
Fig. 119 Screen in "Autosave"
On-going serial measuring can be interrupted by CL.
Fig. 120 Dialogue – "Stop Autosave"
User Manual
® high resolution
C button is pressed.
© InfraTec GmbH 2013
 and . Using the
T button (acting as a tab
57
