1.2 Programmable Buttons

All ETR and 1400 Series phones have various numbers of buttons to which functions can be assigned. For some phones
additional buttons can also be added by attaching a button module to the phone.
The buttons are numbered from 01 up to 80, from left to right, starting from the bottom row upwards.
· Intercom Buttons
The first two buttons, 01 and 02, are used as Intercom 1 and Intercom 2 buttons for internal calls. This function
is automatically assigned to the buttons by the system and cannot be overridden by the system administrator or
extension user.
· Line Buttons
Buttons 03 and upwards up to the number of lines assigned to the extension are used as line appearance buttons
for external calls. These can only be programmed by a system administrator using the
Line Assignment
22
· Other Buttons
Any additional buttons can be used for the functions listed in
can be programmed by the system administrator and the extension user.
Button Types
Programmable buttons without lights
Programmable buttons with lights
Intercom buttons with lights
Total Buttons
· Default Button Programming
The default programming sets the following button programming:
Button
01, 02 Intercom 1 and Intercom 2
03 to 07 Lines 01 to 04
ETR extensions
19 Last Number Redial
20 Conference Drop
21 Voicemail Collect
This function is not available through telephone administration button programming.
It allows the extension use to access their voicemail mailbox.
22 Recall
On
PARTNER Phone Administration
IP Office PARTNER Version
functions. They cannot be overridden by the extension user.
ETR 6
ETR 6D
137
130
142
Button Programming Functions
ETR Phones
ETR 18 ETR 34D
ETR 18D
– 4 4
4 16 32
2 2 2
6 22 38
Overview: Programming Functions
Number of Lines
21
. These buttons
112
1400 Series Phones
1403 1408 1416
– –
3 8
2 2
3 8
- Issue 1b (22 February 2010)
and
–
16
2
16
