5. Orange/violet wire input
Pedal break switch's Normally rear brake light trigger negative (-) while pedal
break become positive (+) connect to orange/violet . This wire needs installation
effective function below
System use pedal break to do ignition upon on auto door lock.
System use pedal break to do anti-hijack programmed safe mode
System installation start module to do allowed or not allowed engine start.
6. Blue/Red wire: door switch trigger (+) (alarm RF Program 3
While the door open switch trigger (+) connect with the Blue/Red. If the door
closed the trigger not immediate disappear need programmed
7. Orange/White wire: trunk pin switch (-) trigger input
While trunk open switch trigger - that connect with the orange/white wire.
8. Green/Black wire: direction light (+) output at 7.5 A
Output 12V(+) by internal relay for the direction light.
9. Green/Yellow wire: direction light (+) output at 7.5 A
Output 12V(+) by internal relay for the direction light.
10. Yellow wire: for ignition (+) input
Connect to ignition switch area that shows + 12V when the ignition key is turned
to "ignition" and "start" position wire.
11. Grey wire: Siren output (+) 1.5 A (Refer to alarm RF Program 8
The main system feeds different (+) 12v of 1.5A for alert signal directly
connect with siren or use an additional relay to connect with the horn.
12. Yellow /Black wire: Active channel 1output (-) of 300ma (Refer to alarm
th
RF Program 9
Remote To active channel #1 this wire pulse output. The pulse time would be
programmed.
13. Blue/Black wire: door pin switch trigger (-) input
While the door open switch trigger (-) connect with the Blue/Black. If the door
closed the trigger not immediate disappear need programmed
14. Orange/Gray wire: hood pin switch trigger (-) input
