- Page 1 Genius Car Alarm 722 Car Alarm 2 way www.alarmasgenius.com...
- Page 2 Genius Car Alarm Dear customer, Thank you very much for your purchasing of the 2 way car alarm products we manufactured. 1. This product is designed to install on all 12V universal vehicle. The system possesses multi-functions. For your understanding about the product, read the instruction carefully to implement its features fully.
- Page 3 Genius Car Alarm car owner’s car condition. Of course, from outside call in to the machine go through the voice message guide to make command such as system arm/disarm, door lock/unlock, engine start/ shut down etc… You even can use short message (SMS) to control system.
-
Page 4: Table Of Contents
Genius Car Alarm System function guide 2-way LCD Transmitter indication······················· 5 Transmitter control quick table ··························· 7 Multi-function switch quick table ························· 8 Remote door lock/arm····································· 10 Window auto roll up········································ 10 Defective zone bypass ···································· 10 Remote door unlock/disarm ····························· 10 Dome light····················································... - Page 5 Genius Car Alarm Learn codes of the new remote transmitter ········ 21 Reminder of allowed number of remotes ··········· 22 PIN Switch test for alert L E D ·························· 22 Indicator alert L E D table ······························· 23 Hopping code transition ································· 23 Low battery indicator for transmitter ················...
-
Page 6: System Function Guide 2-Way Lcd Transmitter Indication
Genius Car Alarm 2- way LCD transmitter One way transmitter The 2-way LCD transmitter displays more the 20 different screen to provide real-time indications for feature activation and system status. The different display indication are shown below for reference www.alarmasgenius.com... - Page 7 Genius Car Alarm 1. Disarm 2. Audible arm 3. Silent arm 4. Shock trigger bypass 5. Button locked 6. Warn-away trigger 7. Shock trigger 8. Door open 9. Hood open 10. Trunk open 11. Valet mode 12. Anti-carjack 13. Ignition key on 14.
-
Page 8: Transmitter Control Quick Table
Genius Car Alarm Transmitter control quick function table The two-way and one-way remotes’ function table Indicates “Press and release” of specified button • For 2 way remote, it indicates “ Press and hold specified button” for 1 second (LCD vibrates and beeps) for level shift For one way remote, it indicates “... -
Page 9: Multi-Function Switch Quick Table
Genius Car Alarm Multi-function switch quick function table Multi-functio Function Process n switch Press 1 time System enters anti-carjack To turn on switch LED stand-by. If triggered by anti-hijack and parking door, Anti-carjack first stand-by light one time stage is initiated... - Page 10 Genius Car Alarm Multi function Function Process switch Immobilize Press 1 time active reset Disable Immobilized function switch Ignition ON Press 1 times Press 4 Reset new siren chips = Set 1 new PIN times, siren PIN code code Press 1 times siren chips...
-
Page 11: Remote Door Lock/Arm
Genius Car Alarm Remote door lock/arm (audio and mute) alert When system enters arm mode, alter LED flashes to avoid thief break in. If car under security system, door, trunk, hood, ignition, brake and shock sensor would be guarded. If system had been triggered, engine can’t start by using the key and siren chirps... -
Page 12: Security Diagnostic Report
Genius Car Alarm accessory is require refer Alarm function RF programmed 6 times). Security diagnostic report and stage disarm After the main system enters disarm if siren chirps 4 times or remote unit makes 4 buzzer sounds. This indicate the system detected some defective zones (The triggered zones will appear in the remote LCD). -
Page 13: Sensor By Pass
Genius Car Alarm Shock Sensor by pass The sensor by pass feature is the system armed the shock sensor will ineffective. The system must be in arm mode then press and release button twice. The main system shock sensor all stage becomes ineffective. -
Page 14: Auto Arm
Genius Car Alarm beeps and LCD display icon (Refer picture No.23) to notify “ nullify”. B) If “heavy impact” is weaker than “light impact”, the system does not recognize this and will nullify this process. Excert “heavy impact” again. If sensor sensitivity needs re-adjustment, follow the above procedure from step 2 to 5. -
Page 15: Remote Alarm Audible/Mute Mode
Genius Car Alarm Remote alarm audible/mute mode When remote system, the siren can be selected audible/mute mode Refer picture No.2 or 3. Ignition must be at OFF position. Press and release button 4 to select the audible or mute alert modes. -
Page 16: Remote Active Channel # 1
Genius Car Alarm Remote active channel # 1 Press and hold button for level shift ,then Press and release button 3 To active channel #1 (for example) trunk release. The parking light will flash. Refer picture No.10 (refer Alarm function RF program 9 ). - Page 17 Genius Car Alarm without opening the car door. The system will jump out of anti carjack standby mode. To trigger anti-carjack mode 2-1) Triggering of anti carjack first stage mode During anti-carjack standby mode. If the door is opened and close, the system enter anti-carjack trigger first stage mode.
-
Page 18: Stop And Go
Genius Car Alarm siren alert the engine runs chokes for 45 sec then shuts down the engine. If in this time the ignition still at ON position the parking light continuous flashes and siren alert. To disable full stage of anti-carjack mode The system have A B kind of way to turn OFF full stage of anti-carjack ( refer alarm RF programmed 5 to controlled by secure PIN code or not ). -
Page 19: Auto-Immobilized Mode
Genius Car Alarm Auto-immobilizer mode ON/OFF Under this mode feature engine start by the ignition key is disabled Press and hold button 2 for level shift ,then Press and release button 3 to select ON/OFF auto-immobilizer mode. LCD remote shows only valet ON mode if valet is selected ON. -
Page 20: Manual Disarm
Genius Car Alarm button 2 once to terminate alarm triggering The 2 press and release of button makes the main system enter unlock/disarm mode. The alert LED flashes until turn on ignition by key. Manual disarm When remote had lost or broken use manual disarm function to cancel arm mode. -
Page 21: How To Use Pin Code To Disarm The System
Genius Car Alarm How to use PIN code to disarm the system 3-1) Turn the ignition to ON position and it is necessary to open car door. 3-2) Press and release the multi function switch (X) times (X is “1”as... -
Page 22: Learn Codes Of The New Remote Transmitter
Genius Car Alarm Press multi function switch once again then siren 2 chirps to confirm into set new PIN 2 digit code (Y) time. To using remote to set first digit code refer below. 4-1) To assign PIN code digit number at “1” time. Press and release button remote unit. -
Page 23: Reminder Of Allowed Number Of Remotes
Genius Car Alarm Note The pre-memorized coding will be erased each time the learning mode is activated. Re-do the code learning in this case. Reminder of allowed number of remotes Security reason. This allows you to know how many remotes are memorized up to date. -
Page 24: Indicator Alert L E D Table
Genius Car Alarm Indicator alert L E D table Ignition at ON Different standby Ignition at OFF position LED modes position LED blinking blinking System in arm mode Immobilization active Burn on Valet mode ON Burn on Engine start... -
Page 25: Out-Of-Range Indication
Genius Car Alarm Monitoring standby indication If the LCD shows flashing antenna, the remote is monitoring the car. Refer to picture No.19 After 1 minute from the system disarm, the remote stops monitoring and its antenna disappears from LCD. -
Page 26: Other Remote Control Function
Genius Car Alarm Other Remote Control Functions The LCD remote control unit has basic features of (a) EL backlight (b) different time indication of Real time, alarm clock, count-down timer and follow the procedure as below Operation of keys... - Page 27 Genius Car Alarm Additional engine start module is required to using below function Remote engine start and shutdown for auto gear Pre-condition for to allow this features is 1-1) The car must be in neutral gear or parking mode 1-2) Hood must be closed.
-
Page 28: Remote Engine Start And Shutdown
Genius Car Alarm 3-1) While at arm mode and remote engine shutdown. The system will auto relock again For the car with the factory-installed device of auto door-unlock upon ignition.( refer start RF programmed 7 ). Remote engine start or shutdown for manual... -
Page 29: Extra Engine Running Timer
Genius Car Alarm function would be disable and ICON would be disappear. User has to re-set the function in order to turn on fixed auto-start mode again. Purpose: This can auto-start to do battery charging for car if it would be left over a long period without driving ... -
Page 30: Main System Wire Guide
Genius Car Alarm Main system wire guide Red wire: 12v (+) positive input. 1) Locate the 12v wire of the ignition switch and connect it with this. This supplies (+) 12V power with over 15 amps current , regardless of position of battery. - Page 31 Genius Car Alarm 5. Orange/violet wire input Pedal break switch’s Normally rear brake light trigger negative (-) while pedal break become positive (+) connect to orange/violet . This wire needs installation effective function below System use pedal break to do ignition upon on auto door lock.
-
Page 32: Alarm Function Rf Program
Genius Car Alarm Alarm function RF program 1. Let ignition at OFF position 2. Press multi function switch 5 times, 3. Immediately turn ignition ON. The siren sounds 5 chips & LED indicator flashes to indicate function RF programmable mode is activated. -
Page 33: Alarm Function Rf Program Table
Genius Car Alarm Alarm function RF program Default change by remote’s button table Features active M.F. mode with factory switch default □ □ □ Door unlock/lock 0.8/0.8 3.6/36 0.8 twice note output current /0.8 □ □ □ Door lock/unlock brake... -
Page 34: Alarm Function Rf Program Table Explanation
Genius Car Alarm Alarm Function RF Program Table Explanation Door lock/unlock output current time 1. Lock - 0,8sec; Unlock - 0,8sec (for electric system) 2. Lock - 3,6sec; Unlock - 3,6sec (for pneumatic system) 3. Lock - 0,8sec; Unlock - 2 pulse of 0,8sec (for 2 stage unlock cars) 4. - Page 35 Genius Car Alarm the triggered zone still exists, the system will auto by pass. Siren chips and LCD displays door open Last door close with arm and lock 1. Last door close with only arm but without lock. 2. Last door close with arm and door lock.
- Page 36 Genius Car Alarm triggered, the siren will not blurt. “Smart Siren “ mode Choose this mode to allow system in audio arm mode. The siren chips upon disarming will not chips. But into disarm if siren wills 4 chips this mean is during arm mode which zoon trigger report.
- Page 37 Genius Car Alarm in anti-carjack standby mode. OFF mode. If this mode is chosen, remote and switch-controlled anti-carjack function are disabled. www.alarmasgenius.com...
-
Page 38: Door Lock Wire Diagrams
Genius Car Alarm Door lock wire diagrams www.alarmasgenius.com... - Page 39 Genius Car Alarm www.alarmasgenius.com...
-
Page 40: Alarm Module Wiring Diagram
Genius Car Alarm Alarm module wiring diagram www.alarmasgenius.com... -
Page 41: Start Function Rf Program
Genius Car Alarm Start function RF program Let ignition at OFF position Press multi function switch times Immediately turn ignition ON. The siren sounds 6 chips & LED indicator flashes to indicate function RF programmable mode is activated. While in the active programming mode. Each press on multi function switch is followed by one siren chirp &... -
Page 42: Start Function Rf Program Table Explanation
Genius Car Alarm Below functions need engine start module Start function RF Default change by remote’s button program table Features active M.F. mode with switch factory default Extra □ engine running 1 min 3 min 6 min time Each time □... - Page 43 Genius Car Alarm Start Function RF Program Table Explanation . Extra engine running time 1. Choose this mode if the extra engine running timer is not needed. 2. From the time ignition is turned “OFF” by key, engine will keep on running for 1 min.
-
Page 44: Engine Start Module Wire Guide
Genius Car Alarm Remote start park light active If remote engine start the alarm system park light will auto flash. If remote engine start the alarm system park light will auto steady If remote engine start the alarm system park light will not active. - Page 45 Genius Car Alarm 1. Black wire: Connect this to Ground input (-) 2. Gray/black wire = This wire will detect the RPM or Oil signal input depending on the slide switch’s position . Switch No.2 select OFF position and system gray/black wire needs connected to car’s tachometer the system will depend RPM...
- Page 46 Genius Car Alarm Start engine running test switch Using this switch to test whether the remote start module is installed successful or not. If the installation is well done, by pressing this switch one time the remote start module will activate and the engine will run. The second press on this switch the engine will stop.
- Page 47 Genius Car Alarm www.alarmasgenius.com...
