Genius Car Alarm
Car Alarm Series 3 B
4 Buttons
G34 Se
(External Shock Sensor)
Version 3
26
www.geniuscaralarm.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the G34 Se and is the answer not in the manual?

Questions and answers

Summary of Contents for Genius G34 Se

  • Page 1 Genius Car Alarm Car Alarm Series 3 B 4 Buttons G34 Se (External Shock Sensor) Version 3 www.geniuscaralarm.com...
  • Page 2 Genius Car Alarm CAR ALARM GENIUS – Series 3B 4 Buttons – G34 Se (External Shock Sensor) • Module controlled using Micro-Processor • 2 Transmitters - 4 buttons with color Blue LED • 4 Learning Transmitters (Codes) • Transmission frequency 370 MHz (Anti-Scanner) •...
  • Page 3 Genius Car Alarm Introduction Thank you for purchasing our security system for your vehicle. Read well the user’s manual of the system specifically the functions of the transmitter, the valet switch and the LED indicator on the board. The Transmitter Each transmitter has a different code, the alarm system is programmed by the factory with 2 codes (2 transmitters), and you can program a maximum of 4 codes (4 transmitters).
  • Page 4 Genius Car Alarm The system pre-programmed with a routine of work with each button of the Transmitter. It works with the following configuration: a. Alarm is armed and the doors a. IGNITION IS are locked Press button 1 once b. Stop temporarily the alarm’s...
  • Page 5 Genius Car Alarm Alarm system armed by using the Transmitter. The alarm system will always be armed by using the transmitter, provided that the ignition switch is OFF and the system in not in the Valet mode. To arm the alarm system after leaving the vehicle and closing all the doors, simply press...
  • Page 6: Car Finder

    Genius Car Alarm 2. Press button 1, then press button 2 within 2 seconds, both the shock sensor and the door’s signal are cancelled. DOORS’ SIGNAL ARMING DELAY This function allows us to arm the alarm even when the dome lights are on, because the system will not recognize this signal for the programmed time, avoiding notices of open door when the alarm is armed.
  • Page 7 Genius Car Alarm ANTI-HIJACKING BY TRANSMITTER (Programmable) This function is used to immobilize the vehicle in case of emergency, pressing the buttons 1 and 2 simultaneously for 3 seconds and the anti-hijacking mode will activated by transmitter. (See Functions Programming Table) ANTI-HIJACKING BY DOORS (Programmable) With the ignition key in ON position, open driver’s door and the anti-hijacking mode by door...
  • Page 8 Genius Car Alarm *To exit Anti-hijacking mode: APPLY THE DISARMING EMERGENCY PROCEDURE AUTOMATIC ARMING This function provides us with a greater confidence in our alarm, giving us security and tranquility because of the alarm’s complete protection. With this function we can assure that the system will arm automatically in case we forget to do so.
  • Page 9 Genius Car Alarm b. The LED will light solid and the siren will chirp 5 times, confirming that the system is in Valet mode. c. If the system is in Valet mode: If we press BUTTON 1, the doors will be locked and the lights will flash once if BUTTON 2 is pressed, the doors will be unlocked and the lights will flash twice.
  • Page 10: Functions Programming

    Genius Car Alarm Triggered by Ignition ---------------------------The LED will flash once. Triggered by Opened Door ---------------------The LED will flash 3 times. Triggered by Shock Sensor----------------------The LED will flash 4 times. FUNCTIONS PROGRAMMING a. Turn the ignition key to ON position.
  • Page 11 Genius Car Alarm FABRIC RESET Witnessed Anti-carjack (Additional Transmitter) Programmed controls identifier (P.C.I.) * Example to do the Programming: a. Select the functions to be changed. (It is recommended to write down them to avoid mistakes) b. If you are going to work with 2 or 3 functions, follow these steps:...
  • Page 12 Genius Car Alarm 8. ARMING OR DISARMING WARNINGS When arming the alarm, the siren will chirp once; when disarming the alarm, the siren will chirp three times. Sometimes, the chirps may be annoying, so the system gives us the option to cancel temporarily these warning sounds.
  • Page 13 Genius Car Alarm www.geniuscaralarm.com...
  • Page 14 Genius Car Alarm www.geniuscaralarm.com...
  • Page 15 Genius Car Alarm www.geniuscaralarm.com...
  • Page 16 Genius Car Alarm www.geniuscaralarm.com...
  • Page 17 Genius Car Alarm Purchase Date: ___________________________ Invoice _____________________ BENEFICIARY Name: __________________________________ C.I.:_________________________ Vehicle’s Trademark: _______________________ Color: ___________________ Model: ____________________________ Vehicle’s Plate: ___________________________ STAMP AND SIGNATURE OF THE DISTRIBUTOR THAT INSTALLED THE SYSTEM TECHNICAL REVISION Date ___________________________________________________________ Observations____________________________________________________ Stamp: __________________________________________________________ Date ____________________________________________________________...
  • Page 18: Limited Warranty

    Genius Car Alarm LIMITED WARRANTY Every GENIUS branded alarm system is guaranteed for ( ) year(s) since the installation date considering the following conditions: 1. This warranty does not cover damage or malfunctions caused by: a. Immersion in water or liquids b.

This manual is also suitable for:

3b series
