Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 2.
Qty Reference
1 U1
1 U2
8 C1, C2, C3, C4, C13, C14,
C15, C16
5 C5, C6, C7, C10, C11
1 C8
2 C9, C12
5 C17, C18, C19, C20, C21
2 D1, D2
1 J1
1 J2
4 R1, R2, R9, R10
4 R3, R6, R12, R14
5 R4, R5, R11, R13, R24
4 R7, R8, R19, R20
2 R15, R16
1 R17
3 R18, R21, R22
1 R23
2 R25, R26

RELATED LINKS

Resource Description
ADP1053 Product Page, 3-Channel Digital Power Supply Controller
ADP-I2C-USB-Z Product Page, USB to I
Description
ADP1053 (device under test), 40-lead LFCSP
ADP3303 low dropout linear regulator
Capacitor, MLCC, 1 nF, 50 V, C0G, 0603
Capacitor, MLCC, 0.1 µF, 50 V, X7R, 0603
Capacitor, MLCC, 330 nF, 50 V, X7R, 0603
Capacitor, MLCC, 1 µF, 16 V, X7R, 0603
Capacitor, MLCC, 100 pF, 50 V, C0G, 0603
Diode, 200 mA, 70 V
40-pin connector
Connector, header, 4-pin, single, PCB 30GOLD
Resistor, 4.99 kΩ, 0.1%, 1/10 W, 0603
Resistor, 27 kΩ, 1%, 1/10 W, 0603
Resistor, 1 kΩ, 1%, 1/10 W, 0603
Resistor, 2.2 kΩ, 1%, 1/10 W, 0603
Resistor, 10 kΩ, 1%, 1/10 W, 0603
Resistor, 2 Ω, 5%, 1/10 W, 0603
Resistor, 0 Ω, 50 mΩ max, 1/10 W, 0603
Resistor, 47.5 kΩ, 1%, 1/10 W, 0603
Resistor, 200 Ω, 1%, 1/10 W, 0603
2
C Interface Connector
Rev. 0 | Page 7 of 8
Vendor Part No.
Analog Devices ADP1053ACPZ-R7
Analog Devices ADP3303ARZ-3.3
Digi-Key C1608C0G1H102J
Digi-Key C1608X7R1H104K
Digi-Key C1608X7R1H334K
Digi-Key C1608X7R1C105K
Digi-Key C1608C0G1H101J
Digi-Key BAV70WT1G
Digi-Key PPTC202LFBN-RC
Digi-Key 609-2411-ND
Digi-Key TNPW06034K99BEEA
Digi-Key ERJ-3EKF2702V
Digi-Key ERJ-3EKF1001V
Digi-Key ERJ-3EKF2201V
Digi-Key ERJ-3EKF1002V
Digi-Key ERJ-3GEYJ2R0V
Digi-Key ERJ-3GEY0R00V
Digi-Key ERJ-3EKF4752V
Digi-Key ERJ-3EKF2000V
UG-388
