Evaluation Board User Guide

HARDWARE DESCRIPTION

40-PIN CONNECTOR

The ADP1053 daughter card PCB is 28 mm × 50 mm. A
40-pin connector is soldered to the back of the daughter
card evaluation board (see Figure 2).
Figure 2. Backside of the Daughter Card
The 40-pin connector plugs directly into an existing
evaluation motherboard. A 5 V source from the USB connection
provides power to the on-board
provides the 3.3 V power to the ADP1053.
Figure 3 shows the pin assignments for the 40-pin connector on
the ADP1053 daughter card evaluation board.
TOP VIEW
(COMPONENT SIDE)
NC 1
NC 2
12V_AUX 3
FLAGOUT 4
RTD1 5
VS+_A 6
VS–_A 7
PGND_A 8
OVP_A 9
CS2–_A 10
CS2+_A 11
PGOOD_A 12
CS1_A 13
ACSNS 14
PSON_A 15
SCL 16
OUT1 17
OUT2 18
OUT3 19
OUT4 20
Figure 3. 40-Pin Connector Pin Assignments
ADP1053
ADP3303 LDO, which, in turn,
40 NC
39 AGND
38 3.3V
37 FLAGIN
36 RTD2
35 VS+_B
34 VS–_B
33 PGND_B
32 OVP_B
31 CS2–_B
30 CS2+_B
29 PGOOD_B
28 CS1_B
27 CS
26 PSON_B
25 SDA
24 OUT8
23 OUT7
22 OUT6
21 OUT5
2
USB-TO-I C DONGLE
For a complete evaluation of the ADP1053, the following items
are required:
•
ADP1053 evaluation motherboard
•
ADP1053 evaluation daughter card
•
USB-to-I 2 C dongle interface
•
Software GUI
Figure 4 shows how to use the USB-to-I
the ADP1053 daughter card to the PC.
ADP1053
DAUGHTER CARD
DONGLE
CABLE
Figure 4. Connecting the
2
The USB-to-I C dongle interface has four pins (see Table 1).
Table 1. I 2 C Connector Pin Assignment
Pin No. Evaluation Board Function
1 5 V
2 SCL (clock)
3 SDA (data)
4 Ground
Rev. 0 | Page 3 of 8
2
C dongle to connect
2
USB TO I C
USB
DONGLE
CABLE
ADP1053 Daughter Card to a PC
2
Using the USB-to-I C Dongle
UG-388
PC
