Result Codes
DataPort PCX Result Codes
Table E-1.
Numbers Word
(ATV0) (ATV1)
11 CONNECT 4800
12 CONNECT 9600
13 CONNECT 7200
14 CONNECT 12000
15 CONNECT 14400
16 CONNECT 19200
17 CONNECT 38400
18 CONNECT 57600
22 CONNECT 75TX/1200RX
23 CONNECT 1200TX/75RX
33 FAX
35 DATA
40 CARRIER 300
44 CARRIER 1200/75
45 CARRIER 75/1200
46 CARRIER 1200
47 CARRIER 2400
48 CARRIER 4800
49 CARRIER 7200
50 CARRIER 9600
51 CARRIER 12000
52 CARRIER 14400
66 COMPRESSION:CLASS5
67 COMPRESSION:V.42 BIS
69 COMPRESSION:NONE
76 PROTOCOL:NONE
+F4 +FCERROR
1
For ATX0, result code 1 or CONNECT is displayed instead.
4
Refers to DTE rate or DCE rate depending on setting of ATW n .
E-2
Issue 2
1, 4
1, 4
1, 4
1, 4
1, 4
1
1
1
July 1995
(2 of 2)
Description
Connection at 4800 bps
Connection at 9600 bps
Connection at 7200 bps
Connection at 12,000 bps
Connection at 14,400 bps
DTE connection at 19,200 bps
DTE connection at 38,400 bps
DTE connection at 57,600 bps
1
V.23 Originate connection
1
V.23 Answer connection
Fax connection in fax mode
Data connection in fax mode
V.21 or Bell 103J carrier detected
V.23 bwd channel carrier detected
V.23 fwd channel carrier detected
V.22 or Bell 212A carrier detected
V.22bis carrier detected
V.32 or V.32bis carrier detected
V.32bis carrier detected
V.32 or V.32bis carrier detected
V.32bis carrier detected
V.32bis carrier detected
MNP5 compression enabled
V.42bis compression enabled
No data compression enabled
Standard asynchronous mode
V.21 signal received when high
speed fax expected
