AT&T DataPort PCX Modem User Manual page 66

Technical Specifications
Table D-1. DataPort PCX Technical Specifications (2 of 3)
Specifications
AC POWER
REQUIREMENTS –
External Modem Only
(Wall-Mount Transformer)
POWER CONSUMPTION
External Modem
Model 3705
Internal Modem
Model 3706
DIMENSIONS – External
Modem
Weight
Length
Width
Height
DIMENSIONS – Internal
Modem
Weight
Length
Width
Height (Board only)
ENVIRONMENT
Operating Temperature
Storage Temperature
Shock and Vibration
DTE INTERFACE –
External Modem Only
25-pin D-subminiature
connector
D-2
Issue 2
Description
INPUT:
120 Vac
230 Vac
America)
OUTPUT:
9 Vac, 1000 mA, 9VA (Model 3705)
3500 milliwatts (maximum)
2000 miliwatts (maximum)
.84 pounds (.38 kg) not including power
transformer
7.03 inches (17.85 cm)
5.02 inches (12.75 cm)
1.32 inches (3.35 cm)
.21 pounds (96 g)
5.1 inches (13.0 cm)
0.8 inches (1.9 cm)
2.9 inches (7.3 cm)
32 F (0 C) to 122 F (50 C)
– 4 F (–20 C) to 158 F (70 C)
Withstands normal shipping
EIA-232-D/CCITT V.24
July 1995
"
" 10%, 60 Hz, 15W
10%, 50 Hz (not for North
