Internal Modem Installation

This chapter describes how to install an internal DataPort PCX
modem (Model 3706).
Internal DataPort PCX
Modem Package
Your package contains the following:
G
One internal DataPort PCX modem.
G
One RJ11 modular 6-foot telephone cord.
G
QuickLink II Fax software diskette and user's guide.
G
This User's Guide and Warranty Card. A technical
information update sheet may also be included.

Required Equipment

The internal version of the DataPort PCX modem can be
installed only in an IBM-compatible personal computer. For
proper operation, you must provide the following:
G
An available 8-bit or 16-bit expansion slot within the PC.
G
An available COM port (modem supports COM ports 1– 4
and IRQs 2–5).
G
An RJ11 telephone outlet.
G
A telephone with an RJ11 modular telephone cord (if you
wish to use the same outlet for both modem and voice
calls).
G
An IBM-compatible PC. It should have 386 20 MHz or
faster processor for best results.
3
Issue 2 July 1995
3-1
