Testing Your Modem

About WinRPI

WinRPI provides data compression and error correction for
Windows communications and fax applications. Install WinRPI
by checking the Compression and Error Correction Software
Drivers box on the QuickLink II Fax installation screen, whether
or not you want to install the QuickLink II Fax application. The
setup program creates a WinRPI group containing a WinRPI
Enhancer icon on your desktop. Close the WinRPI group to
minimize its size.

Software Setup

This section shows how to set up your DataPort PCS modem for
some popular online services and communications programs.
Make sure that the COM port setting for your software
(sometimes called Connector or Port) is set to the COM port you
are using for your DataPort PCX modem.
Table 4-1 shows which modem type you should select from the
list your software provides, and a typical initialization command
string. (Spaces are shown for clarity and are optional.)
Table 4-1. Software Initialization Strings
Service or
Program
t
America Online
t
CompuServe –
WinCIM 1.4
Reuters
SM
r
PROCOMM
PLUS for Windows
t
QuickLink II Fax
t
WinFax PRO 4.0 AT&T Paradyne Corp.
Modem Type
Generic
(Hayes Compatible)
r
Hayes
Hayes or
Hayes Compatible
AT&T DataPort 14.4/FAX
(Class 1)
Class 1 Fax/Modem
DataPort 14.4
Initialization String
AT &F &C1 &D2 &K3 W2
+H11 ^M
AT &C1 &D2 &K3 W2
S0=0 S7=90 S95=44
+H11^M
AT &C1 &D2 &K3 +H11
AT &F &C1 &D2 W2
S7=90 +H11 ^M
AT &F &C1 &D2 W2
S7=90 +H11 ^M
AT &F &C1 &D2 K3
+H11 \
Issue 2 July 1995
4-5
