External Modem Installation

This chapter describes how to install an external DataPort PCX
modem (Model 3705).
External DataPort PCX
Modem Package
Your package contains the following:
G
One DataPort PCX standalone external modem.
G
One modular 6-foot RJ11 telephone cord.
G
One 110 vac power transformer.
G
QuickLink II Fax software diskette and user's guide.
G
This User's Guide and a Warranty Card. A technical
information update sheet may also be included.

Required Equipment

For normal operation, you must provide the following:
G
An RJ11 telephone outlet.
G
A 110 vac wall outlet.
G
A shielded RS-232 serial cable with a male 25-pin
(DB25P) connector to connect to the modem, and either
a 25- or 9-pin serial connector to connect to the PC.
(Check your PC serial connector.)
G
A telephone with an RJ11 modular telephone cord (if you
wish to use the same outlet for modem and voice calls).
G
An IBM-compatible PC. It should have 386 20 MHz or
faster processor for best results.
