(6) Slide the MP roller holder ASSY to the direction of 6a and pull it up to remove.
MP feed frame
(7) Turn the MP feed frame upside down.
(8) Slide the PE actuator MP B to the direction of 8b while pressing the Hook to the direction
of 8a, and pull it up to remove.
PE actuator MP
Lift arm MP
6a
Hook
Fig. 5-190
8a
MP feed frame
Fig. 5-191
5-139
6b
MP roller holder ASSY
PE actuator MP B
8c
Hook
8b
