9.2.2. 3D Phase – Offset
If the 3D image is slightly unsynchronized it can be adjusted in the menu item.
Using the control arrow keys follow the sequence (below) to invert the 3D Phase Offset
setting. Press the OK button to select and confirm selections.
Adjustable range is between -300µS and +300µS.
9.2.3. 3D Position
Depending on the model of DLP Digital Cinema Projector in use, you may have to switch
the direction for the 3D Position of the actuator.
Using the control arrow keys follow the sequence below (below), to switch the 3D
Position setting. Press the OK button to select and confirm selections.
Installation & Operation Manual | MI-WAVE3D
3D Phase Offset
These two adjustments should
ideally be carried out within the
projector 3D configuration.
The option is provided here,
when access to the projector
controls is not available.
Save the new setting.
3D Position
Save the new setting.
