Installation & Operation Manual | MI-WAVE3D
5. Detailed Component Overview
5.1.
Liquid Crystal Polarization Modulator (LCPM)
LC Panel
LC Panel Frame
Cooling Fan
Stand is used to adjust the
height and angle of the LC
Frame with respect to the
projector lens
Cooling Fan
LCPM Cable
Connector
Connector
© MASTERIMAGE 3D, Inc.
11
