SET 1.PASSWORD [OFF]*
5
PASSWORD
2.NEW PASSWORD
3.EXIT
Turn on or off system password, set new 4-digit password
KEY Value: 0 ~ 9 | Default: 0
Password Value: 0000 ~ 9999 | Default: 0000
* Current Status: 'OFF' or 'ON', Default is OFF
SET 1.IP
6
ETHERNET
2.SUBNET MASK
3.GATEWAY
4.PORT NUMBER
5.EXIT
Configure Ethernet parameters for automation
Value: [MMM] 0 ~ 233, [NNN] 0 ~ 255, [OOO] 0 ~ 254 |
IP Default: 192.168.000.101, SUBNET MASK Default: 255.255.255.000,
GATEWAY Default: 192.168.000.001
PORT NUMBER: 00001 ~ 49999 | Default: 5000
SET SET FACTORY
7
FACTORY
Factory Reset?
Reset all user entered information to the factory condition.
INFORMATION F/W V.1.03
8
Aug 20 2012
Show system information
+1
F/W Version,
EXIT OK
9
Exit the system menu
>1 >1
>2
>2
>1 >1
>2
>3
>4 >2
>3
>4
Performing
Factory Reset!
Wait a second... / Completed!
[OK] [CANCEL]
+2
FPGA Version,
© MASTERIMAGE 3D, Inc.
Installation & Operation Manual | MI-WAVE3D
SET PASSWORD
ON
OFF
[SAVE][CANCEL]
NEW PASSWORD
KEY: [o]
* * * *
[SAVE][CANCEL]
IP
[MMM].[NNN].[NNN].[OOO]
[CANCEL] [SAVE]
SUBNET MASK
[NNN].[NNN].[NNN].[NNN]
[CANCEL] [SAVE]
GATEWAY
[MMM].[NNN].[NNN].[OOO]
[CANCEL] [SAVE]
PORT NUMBER
[n][m][m][m][m]
[CANCEL] [SAVE]
+3
Date and time of building F/W
>3
CONFIRM
PASSWORD
KEY: [o]
* * * *
[SAVE][CANCEL]
