9. MI-WAVE3D Detailed Operation

9.1.

MI-WAVE3D Menu Tree

st
NO 1 Level
3D PHASE
1
3D POSITION
2
AUTOMATION
3
FAN SPEED
4
nd
2 Level
>1
1. SYNcPOLARITY
>2
2.OFFSET
3. EXIT
Adjust sync polarity and the offset of 3D phase if any 3D artifacts are seen on screen
SYNC POLARITY Value: TRUE, INVERT, Default: TRUE,
OFFSET Value: -180 ~ +180 | Default: +000
LEFT
RIGHT
[SAVE] [CANCEL]
Set a 3D position of Actuator
Default is LEFT
1. MANUAL
2. GPIO
3. SERIAL
4. ETHERNET
>1
5. SYNC PULSE
6. EXIT
Select a 3D automation I/O port
Value: MANUAL, GPIO, SERIAL, ETHERNET, SYNC PULSE | Default: MANUAL
REFERENCE Hz Value: 48 ~ 120Hz | Default: 72Hz
MAX
MID
LOW
SET cooling fan speed on LCPM
Default is MAX
