Gateway Convertible Notebook pc Service Manual page 27

6
Remove the old processor from the system board.
7
Install the new processor onto the system board making sure that Pin 1 on the
processor (indicated by the silk-screened arrow on the corner of the processor) aligns
with Pin 1 on the processor socket (indicated by the absence of a pin hole in the
processor socket), then use a flat-blade screwdriver to turn the processor lock screw
¼-turn clockwise.
8
Reassemble the notebook.
www.gateway.com
Replacing the processor
23
