Gateway Convertible Notebook pc Service Manual page 23

6
Unplug the old cooling fan.
7
Lift the cooling assembly up and away from the convertible notebook.
8
Install the new cooling assembly in the convertible notebook.
9
Plug in the new cooling fan.
10
Replace the four screws that are stamped with the numbers 1 through 4 next to them.
Make sure that you tighten the screws in numerical order.
Caution
11
Replace the other two screws that connect the cooling assembly to the system board.
12
Replace the memory bay cover, then tighten the cover screws.
When tightening the cooling assembly's screws into the numbered
holes, tighten them in numerical order.
www.gateway.com
Replacing the cooling assembly
19
