User's Guide
[POD Administrator's Reference]
im9220
For Océ and Imagistics Models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the im9220 and is the answer not in the manual?

Questions and answers

Related Manuals for Oce im9220

Summary of Contents for Oce im9220

  • Page 1 Océ User’s Guide [POD Administrator’s Reference] im9220 For Océ and Imagistics Models...
  • Page 2 This product was first introduced by Imagistics International Inc. and is now a part of the Océ product line. Please be aware that while some components may still carry the Imagistics name and markings, they are fully compatible with the Océ brand system. www.oce.com...
  • Page 3 FEDERAL OR STATE STATUTES MAY PROHIBIT THE COPYING OF CER- TAIN DOCUMENTS OR INFORMATION, RESULTING IN FINES OR IMPRIS- ONMENT FOR VIOLATORS. ACKNOWLEDGEMENTS: - Océ and the Océ Logo are registered trademarks or trademarks of Océ N.V. - Microsoft, MS, Windows and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United States and / or other countries.
  • Page 4 * Océ im9220 User’s Guide - POD Administrator’s Reference (This book) This guide provides you with detailed information about the machine man- agement and how to customize the machine according to your daily use.

  • Page 6: Table Of Contents

    Contents Paper Setting Paper Setting Outlines ..............1-2 1.1.1 Setting Items in Paper Setting ............1-2 1.1.2 Paper Type Specifications ..............1-3 1.1.3 Recommended Setting of Tray ............1-6 Change Tray Setting ................1-7 Change Size Setting ................1-12 Controller Setting Function Overview ................2-2 01 Report Type ...................2-7 02 Printer Setting ................2-8 03 Select Printer Setting ..............2-14 04 Spool ....................2-16...
  • Page 7 3.4.4 2 Each Function Setting>Fine Adjust Margin .......3-26 3.4.5 2 Each Function Setting>Print Prohibit Timer ......3-27 3.4.6 2 Each Function Setting>Offset Auto Select ........3-29 3.4.7 3 Density Setting>1 Density Shift for Original Image Type ...3-30 3.4.8 3 Density Setting>2 User Density Setting ........3-32 3.4.9 3 Density Setting>3 Photo Mode Density Setting ......3-35 3.4.10...
  • Page 8 4.3.8 3 Weekly Timer Setting>5 Password for Non-Business Hours Setting 4-25 4.3.9 4 Print Management List .............. 4-27 4.3.10 5 Prohibit User Operation ............4-32 4.3.11 6 Expert Adjustment>Non Image Area Erase Setting ....4-35 4.3.12 6 Expert Adjustment>ADF Frame Erasure Setting ....... 4-38 4.3.13 6 Expert Adjustment>Finisher Adjust ...........
  • Page 9 4.6.12 2 IP NIC Setting>10 Alert Mail ............4-136 4.6.13 2 IP NIC Setting>11 CSRC ............4-138 4.6.14 2 IP NIC Setting>12 AP I/F ............4-144 4.6.15 2 IP NIC Setting>13 PSWC ............4-146 4.6.16 2 IP NIC Setting>14 Network Setting Clear ........4-149 4.6.17 2 IP NIC Setting>15 LDAP ............4-151 4.6.18 2 IP NIC Setting>16 SNMP Trap ..........4-156...
  • Page 10 4.10.1 1 Destination Address Change/Delete ........4-190 Web Utilities Setting Web Utilities Outlines ............... 5-2 Setting Account Track Data ............5-4 5.2.1 Adding Account Track ..............5-4 5.2.2 Editing Account Track Data ............5-7 Remote Panel Setting ..............5-17 Setting Scan Transmission Function ..........5-20 Transmitting Machine Setting File ..........

  • Page 12: Paper Setting

    Paper Setting...

  • Page 13: Paper Setting Outlines

    - (blank), White, Clear, Yellow, Pink, Blue, Green - Hole-Punch Select either condition. With Punch Hole or No Punch Hole - Both Sides Adjust Specify the Vertical zoom, Horizontal zoom, Up/Down shift amount, and Right/Left shift amount for both front and back pages. Océ im9220...

  • Page 14: Paper Type Specifications

    When a paper type other than that of which can be specified on this machine is used, use this function. For the details, contact your service representa- tive. Transparent film cannot be loaded on the main body tray and Large Capacity Unit. Specify [OHP] to a Bypass tray. Océ im9220...
  • Page 15 Copying speed 1: Printing speed is 92 sheets per minute when printing A4/ 8.5×11 in the simplex print mode. Copying speed 2: Printing speed is 59 sheets per minute when printing A4/ 8.5×11 in the simplex print mode. *1: The tray setting is required by your service representative. Océ im9220...
  • Page 16 68.5 92.3 101.5 160.0 42.6 59.2 88.6 73.1 98.4 108.2 170.0 45.3 62.9 94.2 77.6 104.6 115.0 180.0 47.9 66.7 99.7 82.2 110.7 121.8 190.0 50.6 70.4 105.2 86.8 116.9 128.5 200.0 53.3 74.1 110.8 91.3 123.1 135.3 Océ im9220...

  • Page 17: Recommended Setting Of Tray

    If the changes made are considered to be a new standard, make change in setting or make it a new setting. Detail Service representative can make adjustments for all trays at the same time. Contact your service representative, if desired. Océ im9220...

  • Page 18: Change Tray Setting

    See page 1-4 for details of the paper types. PrOcédure Press the [Utility/Counter] on the control panel.The Utility Screen will be displayed. Touch [6 Administrator Setting]. The Password Input Screen will be displayed. When the Password Input Screen is not displayed, prOcéed to step 4. Océ im9220...
  • Page 19 Paper Setting Enter the eight-digit administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. Touch [8 Paper Setting]. Océ im9220...
  • Page 20 The Tray Setting Screen will be displayed. Touch a desired tray key to highlight it. Touch [Change] to change a tray setting. The Tray Setting Menu Screen will be displayed. Touch Type. The Change Paper Type Screen will be displayed. Océ im9220...
  • Page 21 Touch [Colored Paper]. The Colored Paper Setting Screen will be displayed. Select a desired paper color. Touch [OK] to complete the setting and return to the Tray Setting Menu screen. Touch [Hole-Punch]. The Hole-Punch Setting Screen will be displayed. 1-10 Océ im9220...
  • Page 22 Enter the desired adjustment value using the control panel keypad. – Touch [+/-] to adjust the value to be positive or negative. Touch [OK] to complete the setting and return to the Tray Setting Screen. Touch [Close] to return to the Paper setting screen. Océ im9220 1-11...

  • Page 23: Change Size Setting

    Press the [Utility/Counter] on the control panel. The Utility Screen will be dis- played. Touch [6 Administrator Setting]. The Password Input Screen will be displayed. When the Password Input Screen is not displayed, prOcéed to step 4. 1-12 Océ im9220...
  • Page 24 Paper Setting Enter the eight-digit administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. Touch [8 Paper Setting]. Océ im9220 1-13...
  • Page 25 Touch [Size Setting] to change a tray setting. The Size Setting Screen will be displayed. Touch the desired key to specify the detectable size. Select Standard size when loading the standard size of paper in the specified tray. 1-14 Océ im9220...
  • Page 26 140×182 mm to the maximum size of 314×445 mm can be set. – Touch [Lead Edge], [Rear Edge], or [Center] to specify the desired image position. Touch [OK] to complete the setting and return to the Size Setting Screen. Océ im9220 1-15...
  • Page 27 When using the 9265, the maximum size will be 223mm; when us- ing the 9267, the maximum size will be 460mm. – Touch [Select Size] to return to the Select Size Screen. Touch [OK] to complete the setting and return to the Size Setting Screen. 1-16 Océ im9220...
  • Page 28 140×182mm to the maximum size of 314×445mm. The value to be specified for Z will be 0 to 99mm. – Touch [Select Size] to return to the Select Size Screen. Touch [OK] to complete the setting and return to the Tray Setting Screen. Océ im9220 1-17...

  • Page 30: Controller Setting

    Controller Setting...

  • Page 31: Function Overview

    PCL Demo Page Print Print the PCL demo page. PS Demo Page Print* Print the PS demo page. PCL Font List Print the PCL font list. PS Font List* Print the PS font list. *: Available with option. Océ im9220...

  • Page 32: Printer Setting

    Select the initial setting for each function. Off, Z-fold (A3/B4/11×17/8K), Z-fold (8.5×14), Fold & Staple, Fold & Sta- ple/Trim, half fold, Letter fold IN, Let- ter fold OUT 9 Offset Select to use the offset function. On, Off Océ im9220...
  • Page 33 2 repeat-reversal(D) 20 Booklet Select to use the Booklet function. Off, On 21 Adhesive Binding Select to use the Adhesive binding mode. Off, On 22 Print Position Select the initial print position. Rear Edge Rear Edge, Center, Lead Edge Océ im9220...
  • Page 34 1 Auto Paper Select Select to use APS function. Off, On 2 Image Position Select the image position to be print- Left ed on a page. Left, Center * For the details of the symbol set, see the appendix. Océ im9220...
  • Page 35 Set the timer to terminate the interface. See page 2-17. Menu Items Description Default Parallel Timeout Set the timer to terminate the parallel port. 10 to 300 seconds Network Timeout Set the timer to terminate the network port. 10 to 300 seconds Océ im9220...

  • Page 36: Report Type

    To return to the previous screen, touch [Return]. If further changes are required, touch the desired key. Touch [Utility] to complete the setting and restore the Utility Screen. Océ im9220...

  • Page 37: Printer Setting

    - 04 TIFF Setting specifies the settings concerning TIFF image. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [Controller]. The Controller Setting Screen will be displayed. Touch [02 Printer Setting]. The Printer Setting Screen will be displayed. Specify the setting number. Océ im9220...
  • Page 38 Touch [01 Basic Setting]. The Basic Setting Screen will be dis- played. – Make the desired setting. Touch [Next] or [Previous] to scroll to the desired item. – The following settings are used unless otherwise specified by the printer driver. Océ im9220...
  • Page 39 20 Booklet: Select to use the Booklet function. 21 Adhesive Binding: Select to use the Adhesive binding mode. 22 Print Position: Select the initial print position. – Touch [Return] to complete the setting and restore the Printer Set- ting Screen. 2-10 Océ im9220...
  • Page 40 05 Font point size: Specify the font size by point. 06 Font pitch: Specify the font pitch. 07 CR/LF Mapping: Select the line feed code. – Touch [Return] to complete the setting and restore the Printer Set- ting Screen. Océ im9220 2-11...
  • Page 41 02 PDF -> PS Conversion error control: Select On to stop printing error pages resulted from the memory overflow. – Touch [OK] to complete the setting. The PS Setting Screen will be restored. – Touch [Return] to complete the setting and restore the Printer Set- ting Screen. 2-12 Océ im9220...
  • Page 42 Touch Return to complete the setting and restore the Printer Set- ting Screen. Touch [Return] on the Printer Setting Screen. The Controller Setting Screen will be restored. If further changes are required, touch the desired key. Touch [Utility] to complete the setting and restore the Utility Screen. Océ im9220 2-13...

  • Page 43: Select Printer Setting

    Touch [Next] or [Previous] to scroll to the desired item. To designate the port number, enter the number (1-6) already specified in “2 Printer Setting”, using the control panel keypad. The “Default” (9100) is the port designated for printing the list. 2-14 Océ im9220...
  • Page 44 Set, touch [Reset] to re-enter the correct number. Touch [Return]. The Controller Setting Screen will be restored. If further changes are required, touch the desired key. Touch [Utility] to complete the setting and restore the Utility Screen. Océ im9220 2-15...

  • Page 45: Spool

    Touch the desired key to select it. Touch [OK] to complete the setting. The Controller Setting Screen will be restored. If further changes are required, touch the desired key. Touch [Utility] to complete the setting and restore the Utility Screen. 2-16 Océ im9220...

  • Page 46: Interface Setting

    The available range is from 10 to 300. When the time outside this range is entered as touching Set, the time initially entered is designated. If the wrong number is entered before touching [Set], touch [Reset] to re-enter the correct number. Touch [Return]. The Controller Setting Screen will be restored. Océ im9220 2-17...
  • Page 47 Controller Setting If further changes are required, touch the desired key. Touch the [Utility] to complete the setting and restore the Utility Screen. 2-18 Océ im9220...

  • Page 48: Utility

    Utility <User Setting>...

  • Page 49: User Setting Outlines

    Utility Screen. The Utility Screen includes two types of setting items: one in which a user can set and the other in which an administrator is required to enter a pass- word. This section describes the user setting. Océ im9220...

  • Page 50: List Of The User Setting

    1 Feed Tray Auto Selection Select ATS for each tray and the priority of the detec- ATS/APS Switch (Trays 1 to tion when ATS functions. 4,Bypass Tray): Off ATS/APS Switch (Trays 1 to 4,Bypass Tray): Off, Tray Priority: Tray4/Tray3/Tray1/Tray2/Bypass Tray Océ im9220...
  • Page 51 Permit/Prohibit 3 Tandem Sub Machine Shift Data Setting Set the sub machine to use the same shift value used Master Machine Shift data on the master machine. Master Machine Shift data/Sub Machine Shift data Océ im9220...
  • Page 52 On/Off ADF AMS Set the machine to automatically select an appropri- ate ratio for copying when detecting the original size placed on the ADF. On/Off Océ im9220...
  • Page 53 Screen when the current job has completed scanning originals from the original glass and started printing. On/Off 4 Scanner Setting 1 Default Address Setting Select the default destination to be displayed when select- E-Mail ing the Scanner Screen. E-Mail/HDD/FTP/SMB 2 Each Function Setting Océ im9220...
  • Page 54 Upper Tray Search Size: A5/5.5x8.5, A4R/8.5x11R Lower Tray Search Size: Lower Tray Search Size: A5/5.5x8.5, A4R/8.5x11R, A5, A4R, 8.5x14 8.5x14/8x13/8.12x13.2/8.25x13/8.5x13 For detailed setting description of Tray Setting, See page 1-7. For detailed setting description of PI Setting, See page 4-52. Océ im9220...

  • Page 55: System Setting

    The Language Setting Screen will be displayed. Select the desired mode. Touch [OK] to complete the setting and return to the System Setting Screen. If further changes are required, touch the desired key. Touch Utility to restore the Utility Screen. Océ im9220...

  • Page 56: Buzzer Setting>1 Buzzer On/Off, Volume Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [2 Buzzer Setting]. The Buzzer Setting Screen will be displayed. Touch [1 Buzzer On/Off, Volume Setting]. The Buzzer On/Off, Volume Setting Screen will be displayed. Océ im9220...

  • Page 57: Buzzer Setting>2 Buzzer For Job Stop Setting

    Select the duration of the buzzer sound when the machine stops. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [2 Buzzer Setting]. The Buzzer Setting Screen will be displayed. 3-10 Océ im9220...
  • Page 58 The Buzzer for Job Stop Setting Screen will be displayed. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Buzzer Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-11...

  • Page 59: 1 Shot Indication Time

    Touch [3 seconds] or [5 seconds] to highlight it. Touch [OK] to complete the setting and return to the System Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-12 Océ im9220...

  • Page 60: Panel Reset Timer Setting

    The Panel Reset Timer Setting Screen will be displayed. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-13...

  • Page 61: Sub Area Display On/Off

    The System Setting Screen will be displayed. Touch [5 Sub Area Display On/Off]. The Sub Area Display On/Off Screen will be displayed. Select the desired sub screen to highlight it. Touch [OK] to complete the setting and return to the Utility Screen. 3-14 Océ im9220...

  • Page 62: Key Response Time

    The Key Response Time Screen will be displayed. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-15...

  • Page 63: Change User Password

    Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [7 Change User Password]. The User Authentication Screen will be displayed. Enter the user name. – Touch [User Name] to display the Input User Name Screen. 3-16 Océ im9220...
  • Page 64 – Touch [Password] to display the Input User Password Screen. – Enter the current password. The entered password will appear as asterisks (********) on the screen. Then touch [OK]. The Change User Password Screen will be displayed. Océ im9220 3-17...
  • Page 65 Utility <User Setting> Enter a new user password. – Touch [New Password] to display the Input New Password Screen. – Enter a new password, the touch [OK]. – Touch [Check Input] to display the Re-input New Password Screen. 3-18 Océ im9220...

  • Page 66: Warm Up Screen On/Off

    8 Warm Up Screen On/Off PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [8 Warm Up Screen On/Off]. The Warm Up Screen On/Off Screen will be displayed. Océ im9220 3-19...
  • Page 67 Select [On] when Warm Up Screen is displayed, and [Off] when Warm Up Screen is not displayed. Touch [OK] to complete the setting and return to the Utility Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-20 Océ im9220...

  • Page 68: Function Setting

    Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [1 Feed Tray Setting]. The Feed Tray Setting Screen will be displayed. Touch [1 Feed Tray Auto Selection]. The Feed Tray Auto Selection Screen will be displayed. Océ im9220 3-21...
  • Page 69 [Up] and [Down]. Touch [OK] to complete the setting and return to the Feed Tray Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-22 Océ im9220...

  • Page 70: Feed Tray Setting>2 Ats Permission

    Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [1 Feed Tray Setting]. The Feed Tray Setting Screen will be displayed. Touch [2 ATS Permission]. The ATS Permission Screen will be displayed. Océ im9220 3-23...

  • Page 71: Feed Tray Setting>3 Auto Paper Type Selection

    PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [1 Feed Tray Setting]. The Feed Tray Setting Screen will be displayed. 3-24 Océ im9220...
  • Page 72 Colored Paper, and Hole-Punch. You may choose more than one key for each item. Touch [OK] to complete the setting and return to the Feed Tray Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-25...

  • Page 73: Each Function Setting>Fine Adjust Margin

    Touch [Fine Adjust Margin] to display the selection keys. Touch [Decimal On] or [Decimal Off] to specify image shift in decimal point or not. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-26 Océ im9220...

  • Page 74: Each Function Setting>Print Prohibit Timer

    Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [2 Each Function Setting]. The Each Function Setting Screen will be displayed. Touch [Print Prohibit Timer] to display the Print Prohibit Timer Screen. Océ im9220 3-27...
  • Page 75 Select the desired interval time key to set the timer, and then touch [OK] to return to the Each Function Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-28 Océ im9220...

  • Page 76: Each Function Setting>Offset Auto Select

    Touch [Offset Auto Select] to display the selection keys. Touch [On] to select Offset automatically, or [Off] to leave it deselected. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-29...

  • Page 77: Density Setting>1 Density Shift For Original Image Type

    The Function Setting Screen will be displayed. Touch [3 Density Setting]. The Density Setting Screen will be displayed. Touch [1 Density Shift for Original Image Type]. The Density Shift for Original Image Type Screen will be displayed. 3-30 Océ im9220...
  • Page 78 Touch [Lighter] or [Darker] to specify the desired Density shift for each Original Image Type. Touch [OK] to complete the setting and return to the Density Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-31...

  • Page 79: Density Setting>2 User Density Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [3 Density Setting]. The Density Setting Screen will be displayed. Touch [2 User Density Setting]. The User Density Setting Screen Menu will be displayed. 3-32 Océ im9220...
  • Page 80 Output density level sample sheet. Select the sample sheet from each sample output level of [1-4], [5-8], [9-12], and [13-16], and touch [Copy]. Place the original on the original glass, and press the [Start] on the control panel. Océ im9220 3-33...
  • Page 81 [Start] on the control panel. Touch [OK] to complete the setting and return to the User Density Set- ting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-34 Océ im9220...

  • Page 82: Density Setting>3 Photo Mode Density Setting

    Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [3 Density Setting]. The Density Setting Screen will be displayed. Touch [3 Photo Mode Density Setting]. The Photo Mode Density Setting Screen will be displayed. Océ im9220 3-35...

  • Page 83: Density Setting>4 Image Density Selection

    PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [3 Density Setting]. The Density Setting Screen will be displayed. 3-36 Océ im9220...
  • Page 84 Touch the desired density key to highlight it. Touch [OK] to complete the setting and return to the Density Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-37...

  • Page 85: Preset Zoom

    Touch [OK] to complete the setting and return to the Function Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-38 Océ im9220...

  • Page 86: Tandem Setting>1 Tandem Sub Machine One Time Data Read

    Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [5 Tandem Setting]. The Tandem Setting Screen will be displayed. Touch [1 Tandem Sub Machine One Time Data Read]. Océ im9220 3-39...
  • Page 87 Touch [OK] to complete the setting and return to the Tandem Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-40 Océ im9220...

  • Page 88: Tandem Setting>2 Tandem Sub Machine Wait/Proof

    [Permit] cannot be selected if the setting 5 Distribution Recovery is turned PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [5 Tandem Setting]. The Tandem Setting Screen will be displayed. Océ im9220 3-41...
  • Page 89 Sub machine will receive the image data normally at the time when printing job starts. Touch [OK] to complete the setting and return to the Tandem Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-42 Océ im9220...

  • Page 90: Tandem Setting>3 Tandem Sub Machine Shift Data Setting

    PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [5 Tandem Setting]. The Tandem Setting Screen will be displayed. Océ im9220 3-43...
  • Page 91 Touch [OK] to complete the setting and return to the Tandem Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-44 Océ im9220...

  • Page 92: Tandem Setting>4 Tandem Selection After Job Completion

    Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [5 Tandem Setting]. The Tandem Setting Screen will be displayed. Touch [4 Tandem Selection after JOB completion]. The Tandem Selection after Job Completion Screen will be displayed. Océ im9220 3-45...
  • Page 93 With [Off] selected, the tandem mode will be released after comple- tion of the tandem job. Touch [OK] to complete the setting and return to the Tandem Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-46 Océ im9220...

  • Page 94: Tandem Setting>5 Distribution Recovery

    This function cannot be turned On if the setting 2 Tandem Sub Machine Wait/Proof is set to [Permit]. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [2 Function Setting]. The Function Setting Screen will be displayed. Touch [5 Tandem Setting]. The Tandem Setting Screen will be displayed. Océ im9220 3-47...
  • Page 95 With [Off] selected, each machine completes the tandem job when finishing its first distributed quantity. Touch [OK] to complete the setting and return to the Tandem Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-48 Océ im9220...

  • Page 96: Copier Setting

    - Orig. Image Type: Text/Photo - Application: OFF PrOcédure Set the desired copy condition as the initial setting. Press the [Utility/Counter] to display the Utility Screen. Touch [3 Copier Setting]. The Copier Setting Screen will be displayed. Touch [1 Reset Setting]. Océ im9220 3-49...
  • Page 97 Touch [Factory Default] to return to the full auto setting. Touch [OK] to complete the setting and return to the Reset Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-50 Océ im9220...

  • Page 98: Reset Setting>2 Reset Function Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [3 Copier Setting]. The Copier Setting Screen will be displayed. Touch [1 Reset Setting]. The Reset Setting Screen will be displayed. Touch [2 Reset Function Setting]. The Reset Function Setting Screen will be displayed. Océ im9220 3-51...
  • Page 99 Touch any key on the screen for Full Auto, and then touch [OK]. The Reset Function Setting Screen will be restored. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-52 Océ im9220...

  • Page 100: Reset Setting>3 Initial By Key Counter Insert

    Touch [3 Copier Setting]. The Copier Setting Screen will be displayed. Touch [1 Reset Setting]. The Reset Setting Screen will be displayed. Touch [3 Initial by Key Counter Insert]. The Initial by Key Counter Insert Screen will be displayed. Océ im9220 3-53...
  • Page 101 Touch [On] to reset and [Off] not to reset, when inserting the key coun- ter or the copy card. Touch [OK] to complete the setting and return to the Reset Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 3-54 Océ im9220...

  • Page 102: Each Function Setting

    Original Setting Screen and the binding position setting made on the Fin- ishing Mode Screen after completion of each copying job. - Status Hold When Auto Reset When Reset functions, select to reset the Original Glass/ADF mode to the initial setting, or save the previous setting. Océ im9220 3-55...
  • Page 103 Touch [3 Copier Setting]. The Copier Setting Screen will be displayed. Touch [2 Each Function Setting]. The Each Function Setting Screen will be displayed. Touch the desired key to display the job setting keys of each function. 3-56 Océ im9220...
  • Page 104 Touch [Choose Default Tray when APS Off] to display the selection screen. Touch the desired tray key, and then touch [OK]. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 3-57...

  • Page 105: Scanner Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [4 Scanner Setting]. The Scanner Setting Screen will be displayed. Touch [1 Default Address Setting]. The Default Address Setting Screen will be displayed. Touch the desired key for the destination. 3-58 Océ im9220...

  • Page 106: Each Function Setting

    - Default Density Setting Select the default scanning density level from 9 levels (Lighter to Darker) and Auto. - Default Special Original Setting Select the default special original type from Normal, Mixed Original, Z- Folded, and Single Feed. Océ im9220 3-59...
  • Page 107 Select the default scanning size. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [4 Scanner Setting]. The Scanner Setting Screen will be displayed. Touch [2 Each Function Setting]. The Each Function Setting Screen will be displayed. 3-60 Océ im9220...
  • Page 108 [Auto] for automatic exposure. Touch [OK] to complete the setting. Touching [Default Scan Size Setting] will display the Default Scan Size Setting Screen. Touch the desired size key, or select [Auto] to set the scanning size au- tomatically. Océ im9220 3-61...
  • Page 109 Touch [Utility] to restore the Utility Screen. Detail When transmitting simultaneously to multiple destinations, the file form setting cannot be specified individually. When transmitting simultaneously, the file form setting will be selected in the following priority: E-Mail>HDD>FTP>SMB 3-62 Océ im9220...

  • Page 110: Touch Panel Adjust

    Press the [Utility/Counter] to display the Utility Screen. Touch [5 Touch Panel Adjust]. Touch the [+] symbol at the upper right corner, then lower left corner on the screen. The present coordinates will be displayed in the mes- sage area of the screen. Océ im9220 3-63...
  • Page 111 5, repeat the adjustment prOcédure from steps 4 to 5 or contact your service representative. Press [1] of the control panel keypad to return to the Utility Screen. 3-64 Océ im9220...

  • Page 112: Utility

    Utility <Administrator Setting>...

  • Page 113: Administrator Setting Outlines

    The administrator setting can be specified with entering the administrator password. Please contact your service representative to set up your administrator pass- word. How to access the Administrator Setting Menu Press the [Utility/Counter] on the control panel. The Utility Screen will be dis- played. Océ im9220...
  • Page 114 The Password Input Screen will be displayed. When the Password Input Screen is not displayed, prOcéed to step 4. Enter the eight-digit administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Set each function items. Océ im9220...
  • Page 115 [Close], [Exit], and each directory key on the Utility Screen Touch [Close] to restore the previous screen. Touch [Exit] to return to the Basic Screen. Touch the directory key in the left side of the Utility Screen to display each screen. Océ im9220...

  • Page 116: List Of The Administrator Setting

    Output the list of service modes, account values, and ROM version of the machine. 4 Font Pattern List Output the list of font patterns used with this ma- chine. 5 Audit Log Report Output the audit log report of the security mode. Océ im9220...
  • Page 117 Erase Outside of Original/On - APS/AMS Only/Ex- Erase Mode: Auto cept Orig. Glass (1:1) Original Density: Auto Erase Mode: Oblique Erase/Rectangle Erase/Auto Original Density: Five levels/Auto ADF Frame Erasure Setting Set to erase the frame when copying in ADF mode. None/1mm/2mm/3mm/4mm/5mm Océ im9220...
  • Page 118 Original Size Detect Set the detected paper type of the original. Inch Metric/Inch/Metric A Size Paper/Full Size Orig. Glass Orig. Size Detect (Small) Set the smallest size when copying by placing the 5.5×8.5 original on the original glass. A5R/5.5×8.5/B5/A4/8.5×11 Océ im9220...
  • Page 119 Register, Change, Add or Delete the user authentication when the User Authentication is set in “01>01 Authenti- cation Setting.” User No./User Name/Password/Account Name/Useable Function (Copy, Scanner, Store/Recall, Printer) 4 Non register/Output Set Set to count the output of non-registered users and sec- tions On/Off Océ im9220...
  • Page 120 Set to use PSWC. 14 Network Setting Clear (See page 4-149.) Restore the network settings to the factory default setting. 15 LDAP (See page 4-151.) Set the LDAP settings. 16 SNMP Trap (See page 4-156.) Set the SNMP Trap settings. Océ im9220...
  • Page 121 Set the machine to output multiple reserve jobs in suc- cession On/Off Face Up/Down for 1 sheet Set the exit direction when copying one set of the origi- Face Down nal on the original glass. Face Up/Face Down Single Feed Auto Setting On/Off 4-10 Océ im9220...
  • Page 122 Change the password when accessing data stored in HDD. 3 Enhance Security Mode Set the Security Strengthen mode. On/Off 8 Scanner Destination Storage 1 Destination Address Change/Delete - - - Edit or delete the registered scanner address. Océ im9220 4-11...

  • Page 123: System Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. 4-12 Océ im9220...
  • Page 124 Sleep Mode. The initial setting is 90 minutes. Touch [OK] to complete the setting and return to the System Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-13...

  • Page 125: Date/Time Setting

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [2 Date/Time Setting]. The Date/Time Setting Screen will be displayed. 4-14 Océ im9220...
  • Page 126 “-” when the local time is later. Touch [OK] to complete the setting and return to the System Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen Océ im9220 4-15...

  • Page 127: Weekly Timer Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. 4-16 Océ im9220...
  • Page 128 The Weekly Timer On/Off Setting Screen will be displayed. Touch [Weekly Timer On] to activate Weekly Timer, or touch [Weekly Timer Off] to deactivate Weekly Timer. The default setting is Weekly Timer Off. The selected key will be highlighted. Océ im9220 4-17...

  • Page 129: Weekly Timer Setting>2 Time Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. 4-18 Océ im9220...
  • Page 130 Screen is displayed, the On-time of Monday is always highlighted. Set On-time by entering a two-digit On-hour (ex. 8 a.m. is 08) and a two-digit On-minute (ex. 7 min. is 07) using the control panel keypad, and then touch the right arrow key. Océ im9220 4-19...
  • Page 131 Touch [OK] to complete the setting and return to the Time Setting Screen. Touch [OK] to return to the Weekly Timer Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-20 Océ im9220...

  • Page 132: Weekly Timer Setting>3 Date Setting

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [3 Weekly Timer Setting]. The Weekly Timer Setting Screen will be displayed. Océ im9220 4-21...
  • Page 133 Touch [Yes] to change the timer action, or touch [No] to cancel. Touch [OK] to return to the Weekly Timer Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-22 Océ im9220...

  • Page 134: Weekly Timer Setting>4 Select Time For Power Save

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Océ im9220 4-23...
  • Page 135 The Select Time for Power Save Screen will be displayed. Touch [On]. The Power Save Start Time is highlighted. Set the start time by using the control panel keypad. Touch [Power Save End Time], and set the end time using the control panel keypad. 4-24 Océ im9220...

  • Page 136: Weekly Timer Setting>5 Password For Non-Business Hours Setting

    (a period of time to turn the ma- chine power on). PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Océ im9220 4-25...
  • Page 137 The System Setting Screen will be displayed. Touch [3 Weekly Timer Setting]. The Weekly Timer Setting Screen will be displayed. Touch [5 Password for Non-Business Hours Setting]. The Password for Non-Business Hours Setting Screen will be dis- played. 4-26 Océ im9220...

  • Page 138: Print Management List

    If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4.3.9 4 Print Management List Use this function to print out the list selected from the following items. - Mode memory list: Programmed contents of Mode memory Océ im9220 4-27...
  • Page 139 Utility <Administrator Setting> - User management list: Home position settings selected by user - Use management list: Information controlled by user authentication or division authentication - Font pattern list: Font patterns used in the machine 4-28 Océ im9220...
  • Page 140 Utility <Administrator Setting> - Audit log report: Audited log Océ im9220 4-29...
  • Page 141 The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [4 Print Management List]. The Print Management List Screen will be displayed. Touch any key to print the list. 4-30 Océ im9220...
  • Page 142 Touch [Management List] to return to the Print Management List Screen. Touch [OK] to return to the System Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-31...

  • Page 143: Prohibit User Operation

    30 Mode memory can be stored. Use [Next] or [Previous] to display the desired Mode memory. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. 4-32 Océ im9220...
  • Page 144 The System Setting Screen will be displayed. Touch [5 Prohibit User Operation]. The Prohibit User Operation Screen will be displayed. Select to lock or delete the mode memory. – Touch [Lock/Delete Mode Memory]. The Lock/Delete Mode Mem- ory Screen is displayed. Océ im9220 4-33...
  • Page 145 Touch each item key to display the popup menu on the right side of screen, then select [Allow] or [Restrict]. Touch [OK] to return to the System Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-34 Océ im9220...

  • Page 146: Expert Adjustment>Non Image Area Erase Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Océ im9220 4-35...
  • Page 147 The Expert Adjustment Screen will be displayed. Touch [Non Image Area Erase Setting]. The Non Image Area Erase Setting Screen is displayed. Select the condition for erasing a non image area. – Touch [Auto Erase]. – Select to highlight the desired condition. 4-36 Océ im9220...
  • Page 148 Touch [Lighter] or [Darker] to set the density level (five levels). Touch [Std.] to set the standard density. Touch [OK] to return to the Expert Adjustment Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-37...

  • Page 149: Expert Adjustment>Adf Frame Erasure Setting

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [6 Expert Adjustment]. The Expert Adjustment Screen will be displayed. 4-38 Océ im9220...
  • Page 150 Touch [Off] if deleting the outside area is not necessary. The setting is enabled when it is set. Touch [OK] to return to the Expert Adjustment Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-39...

  • Page 151: Expert Adjustment>Finisher Adjust

    2nd Fold Adjustment: Available range: -128 (wide) to +127 (narrow), 1 step = 0.1mm - Letter Fold Adjustment Adjust the dislocation of the three-fold position for the Finisher 9261. Available range: -128 (wide) to +127 (narrow), 1 step = 0.1mm 4-40 Océ im9220...
  • Page 152 Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [6 Expert Adjustment]. The Expert Adjustment Screen will be displayed. Océ im9220 4-41...
  • Page 153 Utility <Administrator Setting> Touch [Finisher Adjust]. The Finisher Adjust Screen is displayed. Touch any desired key of adjustment items. The adjustment screen is displayed. 4-42 Océ im9220...
  • Page 154 [Set]. Touch [Close] to return to the Finisher Adjust Screen. Touch [Close] to return to the Expert Adjustment Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-43...

  • Page 155: Expert Adjustment>Timing Adjustment

    - Scanner (ADF) Regist Loop Adjust Adjust the amount of registered loop in scanning the original with ADF. Available range: -10 (short) to +10 (long), 1 step = 0.5mm PrOcédure Press the [Utility/Counter] to display the Utility Screen. 4-44 Océ im9220...
  • Page 156 The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [6 Expert Adjustment]. The Expert Adjustment Screen will be displayed. Touch [Timing Adjustment]. The Timing Adjustment Screen is displayed. Océ im9220 4-45...
  • Page 157 [Set]. Touch [Close] to return to the Timing Adjust Screen. Touch [Close] to return to the Expert Adjustment Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-46 Océ im9220...

  • Page 158: Expert Adjustment>Centering Adjustment

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Océ im9220 4-47...
  • Page 159 Utility <Administrator Setting> Touch [6 Expert Adjustment]. The Expert Adjustment Screen will be displayed. Touch [Centering Adjustment]. The Centering Adjustment Screen is displayed. Touch any desired key of adjustment items. The adjustment screen is displayed. 4-48 Océ im9220...
  • Page 160 [Set]. Touch [Close] to return to the Centering Adjustment Screen. Touch [Close] to return to the Expert Adjustment Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-49...

  • Page 161: Size Setting

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [7 Size Setting]. The Size Setting Screen will be displayed. 4-50 Océ im9220...
  • Page 162 Select the minimum size of the original to be detected in APS mode. Touch [Orig. Glass Orig. Size Detect (Small)]. The Original Glass Original Size Detect/Small Screen is displayed. Touch the desired key to highlight it. Océ im9220 4-51...

  • Page 163: Paper Setting>1 Tray Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. 4-52 Océ im9220...
  • Page 164 The Paper Setting Screen will be displayed. Touch [2 PI Setting]. The PI Setting Screen is displayed. Set the PI upper tray search size. Touch [U-Tray Search Size]. The U-Tray Search Size Setting Screen is displayed. Touch any desired key to highlight it. Océ im9220 4-53...
  • Page 165 If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Detail Service can set the machine to display the [PI Setting] key on the Utility Screen. Contact your service representative, if desired. 4-54 Océ im9220...

  • Page 166: Lcd Backlight Setting

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [9 LCD Backlight Setting]. The LCD Backlight Setting Screen will be displayed. Océ im9220 4-55...

  • Page 167: Annotation Setting

    Annotation Number (numbering) within 9 alphanumerical char- acters in a row, and select whether to print Type In and Annotation Number. When selecting Annotation Number to be printed, also select the print form between All Digit and Effective Digit. 4-56 Océ im9220...
  • Page 168 Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [1 System Setting]. The System Setting Screen will be displayed. Touch [10 Annotation Setting]. The Annotation Setting Screen will be displayed. Océ im9220 4-57...
  • Page 169 If selected title key has already been registered, [New Register] re- mains dimmed and cannot be touched. – Specify the title of annotation. Touch [Title] to display the Input Title Screen. Enter the desired title, then touch [OK]. 4-58 Océ im9220...
  • Page 170 Touch one of the key from [Type In], [Date/Time], [Annotation No.], and [No Print] to select it. When [Type In] is selected: The Input Type In Screen will be displayed. Enter the desired words to be printed, then touch [OK]. Océ im9220 4-59...
  • Page 171 Touch [All Digit] or [Effective Digit] to select the print form of the se- rial number. Touch [OK] on the Annotation Number Setting Screen to complete the setting. When [No Print] is selected: The key will be highlighted, and the Item 1 will not be printed. 4-60 Océ im9220...
  • Page 172 Touch [3 Lines] or [1 Line] under the Combination method for items indication to select the desired print style of the annotation. Touch [OK] to complete the setting, or touch [Cancel] to clear the setting. The Annotation Setting Screen will be restored. Océ im9220 4-61...
  • Page 173 The Annotation Setting Screen will be restored. Delete an annotation. – Touch the registered title key on the Annotation Setting Screen, then touch [Delete]. A popup menu will be displayed to confirm that the selected regis- ter will be deleted. 4-62 Océ im9220...
  • Page 174 Utility <Administrator Setting> – Touch [Yes] to delete, or [No] to cancel. Touch [Return] to return to the System Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-63...

  • Page 175: Administrator/Machine Register

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [2 Administrator/Machine Setting]. The Administrator/Machine Setting Screen will be displayed. Touch [1 Administrator Registration]. The Administrator Registration Setting Screen will be displayed. 4-64 Océ im9220...
  • Page 176 Help Screen. The number which is entered will be dis- played from the last digit, and it is shifted leftward as a next number is entered. Touch [OK] to return to the Administrator Registration Setting Screen. If further changes are required, touch the desired key. Océ im9220 4-65...

  • Page 177: User Authentication/Account Track

    PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. 4-66 Océ im9220...
  • Page 178 Utility <Administrator Setting> Touch [3 User Authentication/Account Track]. The User Authentication/Account Track Screen will be displayed. Touch [1 General Settings]. The General Settings Screen will be displayed. Touch [1 User Authentication]. The User Authentication Screen is displayed. Océ im9220 4-67...
  • Page 179 Enter the number to distribute using the touch panel keypad. The setting is enabled when it is set. Touch [Close] to return to the General Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-68 Océ im9220...

  • Page 180: General Settings>2 Account Track

    PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Océ im9220 4-69...
  • Page 181 Utility <Administrator Setting> Touch [3 User Authentication/Account Track]. The User Authentication/Account Track Screen will be displayed. Touch [1 General Settings]. The General Settings Screen will be displayed. Touch [2 Account Track]. The Account Track Screen is displayed. 4-70 Océ im9220...
  • Page 182 [After Print], or [Warning Only] on the right side of Select Effect of Reaching Copy Limit. Touch [Close] to return to the General Settings Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-71...

  • Page 183: Account Track Setting

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [3 User Authentication/Account Track]. The User Authentication/Account Track Screen will be displayed. Touch [2 Account Track Setting]. The Account Track Settings Screen will be displayed. 4-72 Océ im9220...
  • Page 184 Touch [New Register] to display the New Account Register Screen. – Touch [Account No.] to display the input screen. – Enter the account number, then touch [OK]. You may enter four dig- its for the account number. Océ im9220 4-73...
  • Page 185 – Touch [Limit] to display the input screen. Enter the copy limit value and touch [OK]. You may enter eight digits for the copy limit. 4-74 Océ im9220...
  • Page 186 Follow the instructions below for changing an account setting. – Touch the up or down arrow key to display the account name to be changed and touch it to display the Individual Account Counter Screen. – Touch [Change] to display the Change Registered Account Screen. Océ im9220 4-75...
  • Page 187 [OK]. You may enter eight digit for the copy limit. – Touch [OK] to complete the setting. The message will be displayed when the changed password or ac- count name is duplicated. Enter another password or account name. 4-76 Océ im9220...
  • Page 188 Touch the up or down arrow key to display the account name to be deleted and touch it to display the Individual Account Counter Screen. – Touch [Delete] to display the Delete Confirmation popup screen. – Touch [Yes] to delete, or touch [No] to cancel. Océ im9220 4-77...
  • Page 189 Touch the up or down arrow key to display the account name to re- set the count and touch it to display the Individual Account Counter Screen. – Touch [Count Reset] to display the Reset Confirmation popup screen. – Touch any key to reset. Touch [Cancel] when not resetting. 4-78 Océ im9220...
  • Page 190 Touch [Close] to complete the setting and return to the User Authenti- cation/Account Track Screen. Touch [Close] to return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-79...

  • Page 191: User Authentication Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [3 User Authentication/Account Track]. The User Authentication/Account Track Screen will be displayed. 4-80 Océ im9220...
  • Page 192 The User Authentication Setting Screen will be displayed. Follow the instructions below for registering a new user setting. – Touch [New Register] to display the New User Registration Screen. – Touch [User Number] to display the input screen. Océ im9220 4-81...
  • Page 193 – Touch [Password] to display the input screen. Enter the password and touch [OK]. You may enter 64 digits for the password. For the details on entering texts in the input screen, see the appendix. 4-82 Océ im9220...
  • Page 194 Touch the up or down arrow key to display the desired account name, then touch [OK]. – Touch any key on the right side of [Useable Function] to select the job necessary to authenticate a newly registered user. – Touch [OK] to complete the setting. Océ im9220 4-83...
  • Page 195 Touch the up or down arrow key to display the user name to be changed and touch it to display the Individual User Counter Screen. – Touch [Change] to display the Change Registered User Screen. – Touch [User Name] to display the input screen. 4-84 Océ im9220...
  • Page 196 [OK]. You may enter 64 digits for the password. For the details on entering texts in the input screen, see the appendix. – Touch [Account Name] to display the screen to select an account belong to. Océ im9220 4-85...
  • Page 197 – Touch the up or down arrow key to display the user name to be de- leted and touch it to display the Individual User Counter Screen. – Touch [Delete] to display the Delete Confirmation popup screen. 4-86 Océ im9220...
  • Page 198 Touch the up or down arrow key to display the user name to reset the count and touch it to display the Individual User Counter Screen. – Touch [Count Reset] to display the Reset Confirmation popup screen. Océ im9220 4-87...
  • Page 199 Touch any key to reset. Touch [Cancel] when not resetting. Follow the instructions below for resetting all counters. – Touch [Reset All Counters] to display the All Count Reset Confirma- tion popup screen. – Touch any key to reset. Touch [Cancel] when not resetting. 4-88 Océ im9220...

  • Page 200: Non Register/Output Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [3 User Authentication/Account Track]. The User Authentication/Account Track Screen will be displayed. Océ im9220 4-89...
  • Page 201 Touch [OK] to complete the setting and return to the User Authentica- tion/Account Track Screen. Touch [Close] to return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-90 Océ im9220...

  • Page 202: Network Setting

    Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [1 Machine NIC Setting]. The Machine NIC Setting Screen will be displayed. Specify the following items. Enter numeric values using the control panel keypad. After entering a Océ im9220 4-91...
  • Page 203 Specify the line speed of the network. Choose from the options pro- vided. Touch [OK] to return to the Network Setting Screen. Touch [Close] to return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-92 Océ im9220...

  • Page 204: List Of Ip Nic Setting

    Max. 63 characters combining symbols and alphanumer- ics can be used. When [Enable] is selected, LPD/LPR printing becomes Enable available. Enable/Disable Line Speed Network Specify the network transfer rate. Auto Negotiation Auto Negotiation/10M Half Duplex/10M Full Duplex/100M Half Duplex/100M Full Duplex Océ im9220 4-93...
  • Page 205 If [Use] is selected, Novell NetWare (IPX/SPX) is ena- Not Use bled as the print server protocol. Use/Not Use Frame Type Select the frame type. Auto Detect Auto Detect/IEEE802.2/IEEE802.3/Ethernet2/ IEEE802.2SNAP Operating Mode Select the required operation mode. Pserver Pserver/Nprinter/Rprinter 4-94 Océ im9220...
  • Page 206 Max. 63 characters combining symbols and alphanu- merics can be used. Printer Number - - - Specify the printer number. Select between 0 and 255. File Server Name - - - Specify file server names. Max. 10 servers can be displayed. Océ im9220 4-95...
  • Page 207 Open Printer Attributes Specify to enable the function or not. On/Off IPP Printer Information Setting, Printer URI Setting Printer Name - - - Specify the printer name. Max. 127 characters combining symbols and alpha- numerics can be used. 4-96 Océ im9220...
  • Page 208 : By selecting [Not Use], Scan operations are executable, but the transmission from Océ im9220 to FTP will be disabled. : By selecting [Not Use], access to Océ im9220 (TWAIN, Visual Count) will be prohibited.It is possible to save Scan to HDD jobs, but clients can no longer obtain them.
  • Page 209 Max. 15 characters combin- private ing symbols and alphanumer- ics can be used. *1: Used when communicating with Océ im9220 using applications. Specify the SMB printing setting, and to use Scan to SMB for transmission. % page 4-123 Specific setting and Description...
  • Page 210 Specify the address of the server that is used for e- mail transmission. 0.0.0.0 Max. 255 characters combining symbols and alpha- numerics can be used. Port No. Specify the port number. 1 – 65535 Connection Timeout Specify the time out duration. 30 - 300 seconds Océ im9220 4-99...
  • Page 211 Max. 255 characters combining symbols and alpha- numerics can be used. User Name - - - Specify a user name that is used to connect to the POP server. Max. 63 characters combining symbols and alphanu- merics can be used. 4-100 Océ im9220...
  • Page 212 E-Mail Notification Specify to use e-mail transmission for alert notification. On/Off Notification Address Setting - - - Inform the e-mail address to which to send alert e-mail. Max. 250 characters combining symbols and alphanumer- ics can be used. Océ im9220 4-101...
  • Page 213 If Authentication Setting [SMTP Authentication] is set to [On], specify a user name. Max. 63 characters combining symbols and alphanu- merics can be used. Password - - - Specify a password.Max. 15 characters combining symbols and alphanumerics can be used. 4-102 Océ im9220...
  • Page 214 30 - 300 seconds Auto Check Specify to check incoming e-mail automatically. On/Off Auto Check Interval Time Specify the interval by which to check incoming e- mail automatically. 1 - 60 minutes CSRC Communication Test - - - Start Océ im9220 4-103...
  • Page 215 Specify to use the PSWC function. Use/Not Use Specify the Network Setting Clear setting. % page 4-149 Specific setting and Description Default 14 Network Setting Clear Initialize Set Restore the initial network settings specified at the time of - - - shipment. 4-104 Océ im9220...
  • Page 216 Login Name Specify a login name. - - - Max. 255 characters combining symbols and alpha- numerics can be used. Password Specify a password. - - - Max. 128 characters combining symbols and alpha- numerics can be used. Océ im9220 4-105...
  • Page 217 - - - selected.) 8 items Service Call/Jam/Paper Supply/Toner Supply/PM Call/Staple Cartridge Supply/Finisher Tray Full/Dis- pose of Trash Basket Clear All Trans IPX Setting IPX SNMP Trap Transmission Specify to transmit the IPX SNMP Trap or not. On/Off 4-106 Océ im9220...
  • Page 218 Within 15 alphanumerics/symbols Report Items Select the desired items (More than one item can be - - - selected.) 8 items Service Call/Jam/Paper Supply/Toner Supply/PM Call/Staple Cartridge Supply/Finisher Tray Full/Dis- pose of Trash Basket Clear All Océ im9220 4-107...

  • Page 219: Ip Nic Setting>1 Tcp/Ip

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. 4-108 Océ im9220...
  • Page 220 The TCP/IP Setting Screen will be displayed. For each item, select or enter a required value. Use [Next] or [Back] as required. – TCP/IP – DHCP – IP Address – Subnet Mask – Gateway Address – DNS server 1-3 Océ im9220 4-109...
  • Page 221 Utility <Administrator Setting> – DNS Host Name – DNS Domain Name – – Line Speed Setting – TCP/IP RAW port settings – TCP/IP Filter accept settings 4-110 Océ im9220...
  • Page 222 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. Océ im9220 4-111...

  • Page 223: Ip Nic Setting>2 Netware

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. 4-112 Océ im9220...
  • Page 224 Utility <Administrator Setting> Touch [2 Netware]. The Netware Setting Screen will be displayed. For each item, select or enter a required value. Use [Next] or [Back] as required. – Netware Setting Océ im9220 4-113...
  • Page 225 Touch [OK] to return to the IP NIC Setting Screen. If further changes are required, touch the desired key. After you have changed the settings, turn off the sub power, then turn off and on the main power. 4-114 Océ im9220...

  • Page 226: Ip Nic Setting>3 Ipp

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Océ im9220 4-115...
  • Page 227 Utility <Administrator Setting> Touch [3 IPP]. The IPP Setting Screen will be displayed. For each item, select or enter a required value. Use [Next] or [Back] as required. – IPP Setting – IPP Operation Support Information Setting 4-116 Océ im9220...
  • Page 228 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. Océ im9220 4-117...

  • Page 229: Ip Nic Setting>4 Ftp

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. 4-118 Océ im9220...
  • Page 230 Touch [4 FTP]. The FTP Setting Screen will be displayed. For each item, select or enter a required value. Use [Next] or [Back] as required. – Client – Proxy Server Address – Proxy Port Number – Passive Function Océ im9220 4-119...
  • Page 231 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-120 Océ im9220...

  • Page 232: Ip Nic Setting>5 Snmp

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Océ im9220 4-121...
  • Page 233 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-122 Océ im9220...

  • Page 234: Ip Nic Setting>6 Smb

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Océ im9220 4-123...
  • Page 235 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-124 Océ im9220...

  • Page 236: Ip Nic Setting>7 Appletalk

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Océ im9220 4-125...
  • Page 237 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-126 Océ im9220...

  • Page 238: Ip Nic Setting>8 E-Mail

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Océ im9220 4-127...
  • Page 239 The E-Mail Setting Screen will be displayed. Touch [1 E-Mail TX Setting]. The E-Mail TX Setting Screen will be displayed. Specify the following items, using [Next] or [Back] as required. Touch [OK] to complete the settings and return to the E-Mail Setting Screen. 4-128 Océ im9220...
  • Page 240 Utility <Administrator Setting> – E-Mail Send – SMTP Server Address – Port Number – Connection Timeout – Binary Division – Binary Division Size – E-Mail Send Maximum Size Océ im9220 4-129...
  • Page 241 Utility <Administrator Setting> – Authentication Setting – POP before SMTP – Password – Realm – Administrator Mail Address 4-130 Océ im9220...
  • Page 242 The E-Mail RX Setting Screen will be displayed. Specify the following items. Touch [OK] to complete the settings and return to the E-Mail Setting Screen. – POP Server Address – User Name – Password – APOP – Port Number – Connection Timeout Océ im9220 4-131...
  • Page 243 Select an appropriate Default Select number. – Touch [Input] to display an input screen and enter a title. – After entering the title, touch [OK]. – Touch [OK] to complete the settings and return to the E-Mail Set- ting Screen. 4-132 Océ im9220...
  • Page 244 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. Océ im9220 4-133...

  • Page 245: Ip Nic Setting>9 Hdd

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. 4-134 Océ im9220...
  • Page 246 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. Océ im9220 4-135...

  • Page 247: Ip Nic Setting>10 Alert Mail

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. 4-136 Océ im9220...
  • Page 248 Select [On] or [Off] to specify to use e-mail notification. Touch [Notification Address Setting]. The Alert E-Mail Inform Setting Screen will be displayed. Enter an address, then touch [OK]. The e-mail address can have maximum 250 characters. Océ im9220 4-137...

  • Page 249: Ip Nic Setting>11 Csrc

    CS Remote Care includes service tools, which you do not necessarily have to set. Contact your service representative for details. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. 4-138 Océ im9220...
  • Page 250 Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Touch [Next] and then touch [11 CSRC]. The CSRC Setting Screen will be displayed. Océ im9220 4-139...
  • Page 251 Specify the following items, using [Next] or [Back] as required. Touch [OK] to complete the settings and return to the CSRC Setting Screen. – CSRC Send – SMTP Server Address – Port Number – Connection Timeout – Administrator From Address 4-140 Océ im9220...
  • Page 252 – Realm Touch [2 CSRC RX Setting] to display the CSRC RX Setting Screen. Specify the following items, using [Next] or [Back] as required. Touch [OK] to complete the settings and return to the CSRC Setting Screen. Océ im9220 4-141...
  • Page 253 Utility <Administrator Setting> – CSRC Receive – POP Server Address – User Name – Password – APOP – Port Number – Connection Timeout – Auto Check – Auto Check Interval Time 4-142 Océ im9220...
  • Page 254 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. Océ im9220 4-143...

  • Page 255: Ip Nic Setting>12 Ap I/F

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. 4-144 Océ im9220...
  • Page 256 Touch [Next] and then touch [12 AP I/F]. The AP I/F Setting Screen will be displayed. For each item, select or enter a required value. – AP I/F – AP I/F Over SSL – AP I/F Authentication Océ im9220 4-145...

  • Page 257: Ip Nic Setting>13 Pswc

    4.6.15 2 IP NIC Setting>13 PSWC Specify to use Web Connection (PSWC). PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. 4-146 Océ im9220...
  • Page 258 Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Touch [Next] and then touch [13 PSWC]. The PSWC Setting Screen will be displayed. Océ im9220 4-147...
  • Page 259 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-148 Océ im9220...

  • Page 260: Ip Nic Setting>14 Network Setting Clear

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Océ im9220 4-149...
  • Page 261 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-150 Océ im9220...

  • Page 262: Ip Nic Setting>15 Ldap

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [4 Network Setting]. The Network Setting Screen will be displayed. Océ im9220 4-151...
  • Page 263 Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Touch [Next] and then touch [15 LDAP]. The LDAP Setting Screen will be displayed. Touch [1 LDAP On/Off setting] to display the LDAP On/Off Setting Screen. 4-152 Océ im9220...
  • Page 264 Setting for Search Details Screen. Touch [Condition] on the right side of Search Item to display the LDAP Search Condition Screen, select the condition for each of five items, then touch [OK] to restore the previous screen. Océ im9220 4-153...
  • Page 265 Touch [2 Setting Up LDAP] on the LDAP Setting Screen to display the Setting Up LDAP Screen. Touch up/down arrow to scroll as required, then make the following settings. – Server Address – Search Base – Enable SSL – Port Number – General Settings – Login Name – Password 4-154 Océ im9220...
  • Page 266 Touch [OK] to complete the setting and return to the LDAP Setting Screen. If further changes are required, touch the desired key. After you have changed the settings, turn off the sub power, then turn off and on the main power. Océ im9220 4-155...

  • Page 267: Ip Nic Setting>16 Snmp Trap

    Before setting the SNMP Trap, specify to use SNMP in 4 Network Set- ting> 2 IP NIC Setting> 5 SNMP. PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. 4-156 Océ im9220...
  • Page 268 Touch [4 Network Setting]. The Network Setting Screen will be displayed. Touch [2 IP NIC Setting]. The IP NIC Setting Screen will be displayed. Touch [Next] and then touch [16 SNMP Trap]. The SNMP Trap Setting Screen will be displayed. Océ im9220 4-157...
  • Page 269 SNMP Trap Trans Address Setting Screen. Specify the following items, using up/down arrow as required. Touch [OK] to complete the settings. – Address SNMP Trap Trans – SNMP Trap Trans Address – SNMP Trap Trans Port No. – Trans Community Name 4-158 Océ im9220...
  • Page 270 SNMP Trap Trans IPX Setting Screen. Specify the following items, using up/down arrow as required. Touch [OK] to complete the settings. – IPX SNMP Trap Transmission – Trans IPX Network Address – Trans IPX Node Address – Trans IPX Community Name Océ im9220 4-159...
  • Page 271 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 4-160 Océ im9220...

  • Page 272: Copier/Printer Setting

    Touch [Job Offset Mode]. Touch [On] or [Off] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-161...

  • Page 273: Continuous Print (Print)

    Touch [Continuous Print (Print)]. Touch [On] or [Off] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-162 Océ im9220...

  • Page 274: Change Page Number Print Pos (Booklet)

    Touch [On (Outside Page Print)] or [Off] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-163...

  • Page 275: Fixing Prerotation Set

    The Administrator Setting Screen will be displayed. Touch [5 Copier/Printer Setting]. The Copier/Printer Setting Screen will be displayed. Touch [Fixing Prerotation Set]. Touch [On] or [Off] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. 4-164 Océ im9220...

  • Page 276: Auto Image Rotation

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [5 Copier/Printer Setting]. The Copier/Printer Setting Screen will be displayed. Touch [Auto Image Rotation]. The select screen will be displayed. Océ im9220 4-165...

  • Page 277: Suspend Interruption

    PrOcédure Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. 4-166 Océ im9220...
  • Page 278 Touch [When Current Set Complete] or [Stop Immediately] to highlight Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-167...

  • Page 279: Reserve Copy Function

    The Copier/Printer Setting Screen will be displayed. Touch the down arrow key and touch [Reserve Copy Function]. Touch [Enabled by Operation] or [Enabled by Set Original] to highlight Touch [Close] to complete the setting and return to the Administrator Setting Screen. 4-168 Océ im9220...

  • Page 280: Suspend Scanning When Tray Is Pulled

    The Administrator Setting Screen will be displayed. Touch [5 Copier/Printer Setting]. The Copier/Printer Setting Screen will be displayed. Touch the down arrow key and touch [Suspend Scanning when Tray is pulled]. Touch [On] or [Off] to highlight it. Océ im9220 4-169...
  • Page 281 Utility <Administrator Setting> Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-170 Océ im9220...

  • Page 282: Continuous Print (Copy)

    Touch the down arrow key and touch [Continuous Print (Copy)]. Touch [On] or [Off] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-171...

  • Page 283: Face Up/Down For 1 Sheet

    Touch [Face Up] or [Face Down] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. 4-172 Océ im9220...

  • Page 284: Single Feed Auto Setting

    Touch the down arrow key and touch [Single Feed Auto Setting]. Touch [On] or [Off] to highlight it. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-173...

  • Page 285: System Connection

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [6 System Connection]. The System Connection Screen will be displayed. Touch [Call Service Center]. The Call Service Center Screen will be displayed. 4-174 Océ im9220...
  • Page 286 Touch [Return] to return to the previous screen. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-175...

  • Page 287: Security Setting

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [7 Security Setting]. The Security Setting Screen will be displayed. 4-176 Océ im9220...
  • Page 288 Touch [Input Administrator Password]. Enter the new eight-character password. Touch [OK] to complete the setting and touch [OK] to return to the Se- curity Setting Screen. Touch [Close] to complete the setting and return to the Administrator Setting Screen. Océ im9220 4-177...

  • Page 289: Hdd Manage Setting>1 Details/Delete

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [7 Security Setting]. The Security Setting Screen will be displayed. Touch [2 HDD Manage Setting]. The HDD Manage Setting Screen will be displayed. 4-178 Océ im9220...
  • Page 290 – Confirm that the name of the desired folder or box is displayed at the upper area of the screen. – Touch [Details] to display the details. The Folder Details Screen will be displayed. Océ im9220 4-179...
  • Page 291 Touch the desired folder to highlight it. – Confirm that the name of the desired folder or box is displayed at the upper area of the screen. – Touch [Delete] to display the Delete Confirmation popup screen. 4-180 Océ im9220...
  • Page 292 Touch [OK] to complete the setting and return to the HDD Manage Set- ting Screen. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-181...

  • Page 293: Hdd Manage Setting>2 Data Auto Delete

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [7 Security Setting]. The Security Setting Screen will be displayed. Touch [2 HDD Manage Setting]. The HDD Manage Setting Screen will be displayed. 4-182 Océ im9220...
  • Page 294 Touch [OK] to complete the setting and return to the HDD Manage Set- ting Screen. Touch [Close] to complete the setting and touch [Close] to return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-183...

  • Page 295: Hdd Manage Setting>3 Hdd Lock Password Changing

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [7 Security Setting]. The Security Setting Screen will be displayed. Touch [2 HDD Manage Setting]. The HDD Manage Setting Screen will be displayed. 4-184 Océ im9220...
  • Page 296 Enter current password (The first password; 9-digit alphanumeric serial number of the main body.) The enterd password will appear as aster- isks on the screen. Then, touch [OK] The Change HDD Lock Password Screen will be restored. Océ im9220 4-185...
  • Page 297 Utility <Administrator Setting> Touch [New Password] to display the Password Input Screen. Enter the new password and touch [OK]. Touch [Check Input] to re-enter the same new password. 4-186 Océ im9220...
  • Page 298 Touch [OK] to complete the setting and touch [Close] to return to the Security Setting Screen. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-187...

  • Page 299: Enhance Security Mode

    Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [7 Security Setting]. The Security Setting Screen will be displayed. Touch [3 Enhance Security Mode]. The Enhance Security Mode Screen will be displayed. 4-188 Océ im9220...
  • Page 300 Touch [No] to cancel the setting. Touch [Cancel] at the lower right side of the screen to the Security Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-189...

  • Page 301: Scanner Destination Storage

    Press the [Utility/Counter] to display the Utility Screen. Touch [6 Administrator Setting], enter the administrator password, and then touch [OK]. The Administrator Setting Screen will be displayed. Touch [8 Scanner Destination Storage]. The Scanner Destination Storage Screen will be displayed. 4-190 Océ im9220...
  • Page 302 Select the address type to change/delete the E-Mail destination ad- dress. – Touch [E-Mail]. – Display the register name of the destination address using the search key or the up and down arrow keys. – Touch a register name to highlight it. Océ im9220 4-191...
  • Page 303 Touch [OK]. – To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. Select the address type to change/delete the HDD destination address. – Touch [HDD]. 4-192 Océ im9220...
  • Page 304 To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch No. – To delete the unregistered box, touch [Non Register Box] and touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. Océ im9220 4-193...
  • Page 305 Change/Delete Screen. Select the changing item from [Profile Name], [Character for Search], [Password], [Login Name], [Host Address] and [File Path], and change it in the input screen. Touch [Common] to set it as daily use. Touch [OK]. 4-194 Océ im9220...
  • Page 306 Select the address type to change/delete the SMB destination ad- dress. – Touch [SMB]. – Display the register name of the destination address using the search key or the up and down arrow keys. – Touch the register name to highlight it. Océ im9220 4-195...
  • Page 307 Search], [Password], [Login Name], [Host Address] and [File Path], and change it in the input screen. Touch [Common] to set it as daily use. Touch [OK]. – To delete, touch [Delete]. Touch [Yes] on the Delete Confirmation popup screen. To suspend deleting, touch [No]. 4-196 Océ im9220...
  • Page 308 Touch [Return] to restore the Scanner Destination Storage Screen. Touch [Close] to complete the setting and return to the Administrator Setting Screen. If further changes are required, touch the desired key. Touch [Utility] to restore the Utility Screen. Océ im9220 4-197...

  • Page 310: Web Utilities Setting

    Web Utilities Setting...

  • Page 311: Web Utilities Outlines

    - The user name “admin” (for accessing to the Administrator Setting Menu) cannot be changed. Enter the administrator password previously specified on the machine. 00000000 is initially applied. Once entered, the user name and password are not necessary to be re- entered unless the web browser is restarted. Océ im9220...
  • Page 312 Activate the web browser, then select [Open] from the File menu. Enter the URL (http:// [IP address or host name of the machine]), then click on [OK]. The Main Page of the Web Utilities will be displayed. Detail The Web Utilities window is subject to change without notice. Océ im9220...

  • Page 313: Setting Account Track Data

    5.2.1 Adding Account Track Add a new account track data (password, name, and limit value). PrOcédure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialogue box will be displayed. Océ im9220...
  • Page 314 The Account Track Setting menu will be displayed. Click on [Account Track data add]. The Account Track Data Add window will be displayed. Enter a new account track data. Account Name: 8 characters max. Password: 8 digits max. Océ im9220...
  • Page 315 Web Utilities Setting Limit: 99,999,999 copies max. Click on [Apply]. The registered content will be displayed in the window. The new account track data will be transmitted to the machine imme- diately so that is valid for the user operations. Océ im9220...

  • Page 316: Editing Account Track Data

    Editing Account Track Data Change or delete the account track data (password, account name, or limit value, or reset the counters). PrOcédure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialogue box will be displayed. Océ im9220...
  • Page 317 [OK]. The Machine Manager Setting menu will be displayed. Click on [Account Track setting]. The Account Track Setting menu will be displayed. Click on [Account Track data list]. The Account Track List will be displayed. Océ im9220...
  • Page 318 The edited content will be displayed in the window. The edited data will be transmitted to the machine immediately so that is valid for the user operations. – Click on [Back] to return to the Account Track Data List window. Océ im9220...
  • Page 319 If all the counters are to be cleared, click on [SelectAll]. – Click on the radio button (a white circle) heading the “Copy/Printer Count reset.” or “Scan Count reset.” – Click on [Apply]. The Counter Reset Confirmation window will be displayed. 5-10 Océ im9220...
  • Page 320 Click on [Apply] to immediately reset the counters to zero. The message “Setting was changed” will be displayed. – Click on [Back] to return to the Account Track Data List or any menu item to jump to the desired window. Océ im9220 5-11...
  • Page 321 If all the data are to be cleared, click on [SelectAll]. – Click on the radio button (a white circle) heading the “Delete (Ex- cept for Another user count)”. – Click on [Apply]. The Delete Confirmation window will be displayed. 5-12 Océ im9220...
  • Page 322 Click on [Apply] to immediately delete the data. The message “Setting was deleted” will be displayed. – Click on [Back] to return to the Account Track Data List or any menu item to jump to the desired window. Océ im9220 5-13...
  • Page 323 Web Utilities Setting Save Counter. – Click on [Save this table as a file]. 5-14 Océ im9220...
  • Page 324 Web Utilities Setting – Click on [Save]. In the dialogue box, designate the folder for saving the data, then click on [Save]. Océ im9220 5-15...
  • Page 325 Account Track Data List for starting over. Example: Account track data list stored as a file The “Another user count” will be stored by the name of “UNKNOWN” in the last line. 5-16 Océ im9220...

  • Page 326: Remote Panel Setting

    - The machine should be connected with a PC over a network with TCP/IP enabled. - Set the Enhance Security mode OFF on the machine. PrOcédure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialogue box will be displayed. Océ im9220 5-17...
  • Page 327 The Administrator Setting menu will be displayed. Click on [Remote Panel setting]. The Remote Panel Setting menu will be displayed. Specify the IP address of the PC to be used for Remote Panel function. Max. 3 IP addresses can be specified. 5-18 Océ im9220...
  • Page 328 Web Utilities Setting Click on [Registration]. The IP address will be applied to the machine immediately so that is valid for the user operations. Click on [Administrator Setup Menu] to restore the Administrator Set- ting menu. Océ im9220 5-19...

  • Page 329: Setting Scan Transmission Function

    - The HDD Box No. will be registered as a 9-digit number. For example, entering [1] will be registered as [000000001]. PrOcédure Open the Web Utilities window. Click on [Machine Manager Setting]. The Enter Network Password dialogue box will be displayed. 5-20 Océ im9220...
  • Page 330 Enter “admin” in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Administrator Setting menu will be displayed. Click on [Scan transmission setting]. The Scan Transmission Setting window will be displayed. Océ im9220 5-21...
  • Page 331 Web Utilities Setting Register the E-Mail, HDD, FTP, and SMB, as required. 5-22 Océ im9220...
  • Page 332 Click on [Back] to return to the Scan Transmission Setting window. Display the Entry List. Click on [Entry List] of the desired item under the entry box to display the Entry List. Click on [Back] to return to the Scan Transmission Setting window. Océ im9220 5-23...
  • Page 333 Click on the entry name to be changed. The window for changing the selected item will be displayed. Change the contents as desired, then click on [Registration]. The registered content will be displayed. Click on [Back] to return to the Scan Transmission Setting window. 5-24 Océ im9220...
  • Page 334 The window for deleting the selected item will be displayed. Confirm the registered name to be deleted, then click on [Yes]. Click on [Back] to return to the Entry List window. Click on [Back] to return to the Scan Transmission Setting window. Océ im9220 5-25...

  • Page 335: Transmitting Machine Setting File

    (account track data) ip_email.txt (E-mail data of Scan Transmission Setting data) ip_hdd.txt (HDD data of Scan Transmission Setting data) ip_ftp.txt (FTP data of Scan Transmission Setting data) ip_smb.txt (SMB data of Scan Transmission Setting data) 5-26 Océ im9220...
  • Page 336 Enter “admin” in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Machine Manager Setting menu will be displayed. Click on [Setting data Import/Export]. The Setting Data Import/Export window will be displayed. Océ im9220 5-27...
  • Page 337 Select the desired file type from the pull-down menu, then click on [Ex- port….] The File Download dialogue box will be displayed. Click on [OK]. In the dialogue box, designate the folder for saving the machine setting file, then click on [Save]. 5-28 Océ im9220...
  • Page 338 Table Editor. A new setting file can also be created according to the specifications for each file type. See page 5-32 for details. Import the machine setting file. Click on [Browse…] to designate the machine setting file to be import- Océ im9220 5-29...
  • Page 339 Web Utilities Setting ed, then click on [Import]. The result message will be displayed when the registration is complet- 5-30 Océ im9220...
  • Page 340 - A line should be 300 bytes or less. - The file size should be 100,000 bytes or less. - The line that begins with “#” is a comment. ex. Machine setting file of an account track data Océ im9220 5-31...
  • Page 341 - A line should include NAME, ADDRESS, FILEPATH, LOGINNAME, PASSWORD, REFERENCE, or DAILY being separated by a tab. - NAME should be 24 bytes or less. - ADDRESS should be 63 bytes or less. - FILEPATH should be 96 bytes or less. 5-32 Océ im9220...
  • Page 342 - LOGINNAME should be 47 bytes or less. - PASSWORD should be 14 bytes or less. - REFERENCE should be 24 bytes or less. - Mark DAILY USE with “1” or DAILY NOT USE with “0” in each column. Océ im9220 5-33...

  • Page 343: Box Edit

    The Enter Network Password dialog box will be displayed. Enter “admin” in the User Name text box, and an 8-digit administrator password in the password text box, then click on [OK]. The Machine Manager Setting menu will be displayed. 5-34 Océ im9220...
  • Page 344 The Box Edit window will be displayed. Click on the desired user name. Selected user name will be marked with an asterisk (*) at its head.The user name marked with “L” is locked and cannot be selected. Océ im9220 5-35...
  • Page 345 Box Name area. – Enter the new name within 20 alphanumeric characters. – Click on [Change] on the right side of the text box. The new name will be registered and enabled immediately. 5-36 Océ im9220...
  • Page 346 Clicking on the desired file name (as in step 8), a text box will appear at the top of the File Name area. – Click on [Change] on the right side of the text box. The new name will be registered and enabled immediately. Océ im9220 5-37...
  • Page 347 Web Utilities Setting – Enter the new name within 30 alphanumeric characters. 5-38 Océ im9220...
  • Page 348 Only the top page of the file can be displayed as thumbnail. You cannot specify any other page. Note When changing the file name, a message may inform you that the entered name has been already used. In this case, reenter a new name or consult your service representative. Océ im9220 5-39...

  • Page 350: Web Connection Setting

    Web Connection Setting...

  • Page 351: Web Connection Outlines

    Web Connection is a device control utility program provided by the HTTP server built into the image controller of the Océ im9220. This utility can be used with a Web browser to display the status of the Océ im9220 printer, scanner, and network, and to change default and network settings.
  • Page 352 [Settings]. Check [Every visit to the page] under [Check for newer versions of stored pages:]. – Netscape Navigator Select [Preferences] under [Edit]. Click [Advanced] and then click [Cache]. Check [Every time I view the page] under [Compare the page in the cache to the page on the network:]. Océ im9220...

  • Page 353: Access

    (Example)When the IP address of the image controller is 192.168.0.10: http://192.168.0.10 The Web Connection screen appears. Operation Web Connection operation is identical to Internet Web pages. You can click a link on the Web page to jump to the link destination. Océ im9220...

  • Page 354: Screen Configuration

    Click the Web Connection logo on the About Screen to jump to the Web site. 2. Status Display Icons and text indicate the current status of the main body's printer and scanner. The message “Ready” appears when the main body's printer and scanner are operating normally. Océ im9220...

  • Page 355: Logging In Using Administrator Mode

    Detail The default value of the administrator password for Web Connection is 00000000. You can change the administrator password for Web Connection using the browser in the [System] area of Administrator Mode. See page 6-8. Océ im9220...
  • Page 356 SSL setting, see page 6-37. PrOcédures Click the [Admin Mode] button in the upper left corner of the screen. Enter the password for Administrator Mode and click the [Login] but- ton. To log out, click [Logout]. Océ im9220...

  • Page 357: Administrator Mode

    - Retype New Password: Retype the new password as entered above for confirmation. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered or selected. Océ im9220...
  • Page 358 Click [Device Information] on the [System] tab of the User Mode Screen to display this screen. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220...
  • Page 359 Enter the phone number of the support contact for the product. (Blank by default.) Maximum 127 alphanumeric characters can be used. - Product Help URL: Enter the URL of the product information Web site. (Blank by default.) Maximum 127 alphanumeric characters can be used. 6-10 Océ im9220...
  • Page 360 - [Clear] button: Click the button to clear the settings that were entered or selected. Note If the online manual URLs are not used, users must save the online help file on their PCs. In this case, the [Help] button will not function. Océ im9220 6-11...
  • Page 361 The download completion screen will appear. Click the [Close] button. A dat file will be exported from the device. (The file format must be con- firmed.) - [Clear] button: Click the button to clear the settings that were entered or selected. 6-12 Océ im9220...
  • Page 362 It may take few minutes for clearing the network settings. After clearing the settings is completed, you can access the network again. When you use the network, restart the Web browser. - Network Setting Clear: Click the [Clear] button to display the confirmation screen. Click [OK] to clear. Océ im9220 6-13...
  • Page 363 It may take few minutes for resetting the network. After resetting the net- work, you can access the network again. When you use the network, re- start the Web browser. - Reset: Click the [Reset] button to restart the network only to enable new param- eters. 6-14 Océ im9220...
  • Page 364 Enter the e-mail address to which to send alert mail. Maximum 250 char- acters can be used. - Alert:Choose notification items. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered or selected. Océ im9220 6-15...

  • Page 365: Print Tab

    - RAW port number List the RAW port numbers 1 to 6 that are set in [TCP/IP] on the [Network] tab. - Status Show enable or disable of each RAW port. 6-16 Océ im9220...
  • Page 366 Size, Orientation, Resolution, Spool Setting, Banner Option, Banner Page Tray, Convert Paper Size, 1 Page/Sheet, Booklet, Print Position. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220 6-17...
  • Page 367 Select whether or not to print the error report when an error occurs while rasterizing PostScript data. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-18 Océ im9220...
  • Page 368 Utility Screen - 2 Controller Setting - 2 Printer Settings - 4 TIFF Settings. - Enter for individual items. Auto Paper Select, Image Position. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220 6-19...

  • Page 369: Scan Tab

    - [Clear] button: Click the button to set it to the default before changes were applied. - [Delete] button: Click the button to delete a selected subject. To Enter / Edit Subjects 1. Check the number of the subject to enter or edit, and click the [Edit] but- ton. 6-20 Océ im9220...
  • Page 370 1. Check the number of the subject to delete, and click the [Delete] button. 2. Click the [OK] button on the Subject Deletion screen. 3. Click the [OK] button on the Completed screen. It will take you back to the subject list screen. Océ im9220 6-21...
  • Page 371 1. Check the number of the body text to enter or edit, and click the [Edit] button. 2. Enter the text on the Body Registration screen, and click the [Apply] but- ton. You can use maximum 256 characters. 3. Click the [OK] button on the Completed screen. 6-22 Océ im9220...
  • Page 372 1. Check the number of the body text to delete, and click the [Delete] but- ton. 2. Click the [OK] button on the Body Deletion screen. 3. Click the [OK] button on the Completed screen. It will take you back to the body text list screen. Océ im9220 6-23...

  • Page 373: Network Tab

    Gateway, RAW Port Number 1-6, Host Name, Domain Name, DNS Serv- er, LPD. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-24 Océ im9220...
  • Page 374 Access Permission Addresses and their ranges, Access Refusal Ad- dresses and their ranges. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were selected. Océ im9220 6-25...
  • Page 375 File Server, NDS, Preferred NDS Context Name, Preferred NDS Tree Name, Nprinter/Rprinter, Printer Name, Printer Number - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were selected. 6-26 Océ im9220...
  • Page 376 This screen appears when you click [IPP] on the [Network] tab. This screen is used to enter and confirm settings concerning IPP. When IPP Print is set to disable, you still need to set parameters. Make sure to enter parameters correctly. Océ im9220 6-27...
  • Page 377 FTP Client, Proxy Server Address, Proxy Server Port Number, PASV Mode, Server Timeout, Port Number. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-28 Océ im9220...
  • Page 378 FTP server. - FTP Server: Select enable or disable. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220 6-29...
  • Page 379 SNMP. - SNMP: Select enable or disable. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-30 Océ im9220...
  • Page 380 [Scan] under the [SMB] menu. The screen is used to enter and confirm set- tings concerning SMB scan. - SMB Scan: Select enable or disable. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220 6-31...
  • Page 381 - Enter for individual items. SMB Print, NetBIOS Name, Print Service Name, Work Group. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-32 Océ im9220...
  • Page 382 - Enter for individual items. Apple Talk, Printer Name, Zone Name. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220 6-33...
  • Page 383 To check LDAP Setting: 1. Enter for individual items. 2. Click the [Check LDAP Setting] button on the LDAP screen. 3. Click the [OK] button on the Completed screen. It will take you back to the LDAP screen again. 6-34 Océ im9220...
  • Page 384 Receive, Receiving Server Address, User Name, Password, APOP, Con- nection Timeout, Port Number. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. Océ im9220 6-35...
  • Page 385 POP Before SMTP, SMTP Authentication, User Name, Password, Realm, Binary Division, Division Size. - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-36 Océ im9220...
  • Page 386 Certificate] can be selected. If you click [Cancel], it will take you back to the SSL/TLS Setting screen. If a certificate is not installed Creating a self-signed certificate - Click [Setting]. The SSL/TLS Setting screen appears. Océ im9220 6-37...
  • Page 387 Following the screen indicating that the certificate is being created, an- other screen appears, saying, “The certificate has been created. SSL/ TLS can now be used.” - Click [OK]. It will take you back to the SSL/TLS Information screen of the self-signed certificate. 6-38 Océ im9220...
  • Page 388 Web Connection Setting Requesting a certificate to instal - Click [Setting]. The SSL/TLS Setting screen appears. - Check [Request a Certificate] and click [Next]. The Request a Certificate screen appears. Océ im9220 6-39...
  • Page 389 - Click [OK]. The Certificate Signing Request Data screen appears. - Click [Save]. The file will be saved. - Click [OK]. It will take you back to the SSL/TLS Information screen. - Click [Setting]. The SSL/TLS Setting screen appears. 6-40 Océ im9220...
  • Page 390 - Click [Next]. The Encryption Strength Setting and the Mode using SSL/TLS screen ap- pears. - Enter discretionary settings, and click [Create]. Creation results appear. - Click [OK]. It will take you back to the SSL/TLS Information screen. Océ im9220 6-41...
  • Page 391 If a certificate has been installed Note Initially [Request a Certificate] is checked. Remove an already installed certificate first before requesting a new one. Requesting a certificate to switch information - Click [Setting]. The SSL/TLS Setting screen appears. - Click [Next]. 6-42 Océ im9220...
  • Page 392 The Certificate Signing Request Data screen appears. - Click [Save]. The file will be saved. - Click [OK]. It will take you back to the SSL/TLS Information screen. - Check [Install a Certificate], and click [Next]. The certificate installation screen appears. Océ im9220 6-43...
  • Page 393 - Click [Next]. - The Encryption Strength Setting and the Mode using SSL/TLS screen ap- pears. - Enter discretionary settings, and click [Create]. Creation results appear. - Click [OK]. It will take you back to the SSL/TLS Information screen. 6-44 Océ im9220...
  • Page 394 Web Connection Setting Changing mode settings Changing encryption strength setting - Click [Settings]. The SSL/TLS Setting screen appears. - Check [Set a Encryption Strength], and click [Next]. The Encryption Strength Setting screen appears. - Select a discretionary value. Océ im9220 6-45...
  • Page 395 Web Connection Setting - Click [Create]. The completion screen appears. - Click [OK]. It will take you back to the SSL/TLS Information screen. Changing mode using SSL/TLS - Click [Settings]. The SSL/TLS Setting screen appears. 6-46 Océ im9220...
  • Page 396 - Check [Mode using SSL/TLS], and click [Next]. The Mode using SSL/TLS screen appears. - Select a discretionary mode, and click [Create]. The completion screen appears. - Click [OK]. It will take you back to the SSL/TLS Information screen. Océ im9220 6-47...
  • Page 397 Web Connection Setting Removing a certificate - Click [Settings]. The SSL/TLS Setting screen appears. - Check [Remove a Certificate], and click [Next]. The Remove a Certificate screen appears. 6-48 Océ im9220...
  • Page 398 It will take you back to the SSL/TLS Information screen. Authentication Auto Logout This screen appears when you click [Authentication] on the [Network] tab. The screen is used to enter and confirm settings concerning logout time.En- ter for individual items. Océ im9220 6-49...
  • Page 399 - Enter for individual items. Port Number, Use SSL/TLS, Port Number (SSL). - [Apply] button: Click the button to apply the new settings. - [Clear] button: Click the button to clear the settings that were entered. 6-50 Océ im9220...

  • Page 400: Appendix

    Appendix...

  • Page 401: How To Input Characters

    The followings describe basic steps to input characters on the character in- put screen. 1. Press the corresponding key to input the desired character. 2. Press the [OK] key. The character input screen closes. The input characters are displayed on the corresponding column. Océ im9220...

  • Page 402: Setting Data For Import/Export

    Banner Page Tray Convert Paper Size 1 Page/Sheet Booklet Print Position PCL Settings Font Name Symbol Set Line/Page Font Point Size Font Pitch CR/LF Mapping PS Settings Print To PS Error TIFF Settings Auto Paper Select Image Position Océ im9220...
  • Page 403 Preferred NDS Tree Name Nprinter/Rprinter Printer Name Printer Number IPP Print Printer Name Printer Location Printer Information Printer URI Operations Supported Print Job Accept Print Job Validate Job Cancel Job Get Job Attribute Get Jobs Get Printer Attribute Océ im9220...
  • Page 404 Password Realm Binary Division Division Size SSL/TLS SSL/TLS Information Encryption Strength Validity Period Organization Organization Unit Locality State/Province Country Authentication Auto Logout Admin Logout Time User Logout Time AP I/F AP I/F Port Number Use SSL/TLS Port Number(SSL) Océ im9220...

  • Page 405: Configuration Setting

    Appendix Configuration Setting (Print Sample) Océ im9220...
  • Page 406 Appendix (Print Sample) Océ im9220...
  • Page 407 Appendix (Print Sample) Océ im9220...
  • Page 408 Appendix (Print Sample) Océ im9220...

  • Page 409: Demo Page

    Appendix Demo Page PCL Demo Page Print (Print Sample) 7-10 Océ im9220...
  • Page 410 Appendix PS Demo Page Print (Print Sample) Océ im9220 7-11...
  • Page 411 Appendix PCL Font List (Print Sample) 7-12 Océ im9220...
  • Page 412 Appendix (Print Sample) Océ im9220 7-13...
  • Page 413 Appendix (Print Sample) 7-14 Océ im9220...
  • Page 414 Appendix PS Font List (Print Sample) Océ im9220 7-15...
  • Page 415 Appendix (Print Sample) 7-16 Océ im9220...
  • Page 416 Appendix (Print Sample) Océ im9220 7-17...

  • Page 417: Pcl Font List

    Appendix PCL Font List 7-18 Océ im9220...
  • Page 418 Appendix Océ im9220 7-19...
  • Page 419 Appendix 7-20 Océ im9220...

  • Page 420: Symbol Set

    Appendix Symbol Set Océ im9220 7-21...
  • Page 421 Appendix 7-22 Océ im9220...
  • Page 422 Appendix Océ im9220 7-23...
  • Page 423 Appendix 7-24 Océ im9220...
  • Page 424 Appendix Océ im9220 7-25...
  • Page 425 Appendix 7-26 Océ im9220...

  • Page 426: Glossary

    Abbreviation of Line Printer Request/Line Printer Daemon. A type of printing through a network of the WindowsNT system or UNIX sys- tem. Printing data from Windows or UNIX can be transmitted to a printer on a network using TCP/IP. Océ im9220 7-27...
  • Page 427 One of the file formats to save image data (extension; .tif). Various types of image information can be saved in one image data with the “tag” representing the data type. Web browser Software to access web pages. Internet Explorer, Netscape Navigator, etc. are examples. 7-28 Océ im9220...

  • Page 428: Index

    Index...
  • Page 429 Controller Setting ......2-2 Auto Image Rotation ....4-165 Controller Setting Screen ....2-2 Auto Logout ........6-49 Convert Paper Size ......2-10 Auto Paper Select ......2-13 Copier Setting ........ 3-49 Auto Paper Type Selection .... 3-24 Océ im9220...
  • Page 430 Except Orig. Glass (1:1) ....4-35 If a certificate is not installed ..6-37 Face Up/Down for 1 Sheet ..4-172 Image (Original Glass) ....4-44 Feed Tray Auto Selection ....3-21 Image Density Selection ....3-36 File Form Setting (E-Mail) ....3-59 Océ im9220...
  • Page 431 Paper Feed Tray ......2-10 Paper Setting ........1-2 Paper Size ........2-10 Machine NIC Setting ..... 4-91 Password for Non-Business Hours Maintenance ........6-13 Setting ........... 4-25 Password Input Timing ....4-66 PCL Setting ........2-8 NetWare ........4-112 Océ im9220...
  • Page 432 Sub Area Display On/Off ....3-14 Reset Function Setting ....3-51 Subnet Mask ........4-92 ROM Version ........6-10 Suspend Interruption ....4-166 Suspend Scanning when Tray is pulled 4-169 Scan Tab ........6-20 Symbol Set ........2-11 Océ im9220...
  • Page 433 User (paper) ........1-3 User Authentication ....... 4-66 User Authentication Setting ... 4-80 User Authentication/Account Track 4-66 User Density Setting ...... 3-32 User management list ....4-28 User Setting ........3-3 User/Account Auth. Connect ..4-66 Volume Setting ........ 3-9 Océ im9220...
  • Page 434 Printing for Professionals Océ 100 Oakview Drive, Trumbull, CT 06611 ©Océ 2007...

Table of Contents
