A decent stereo mix would appear as a vertically shaped cloud as shown in the example below:
Phase-Oscillo floating Window
Phase-Oscillo configuration
The Phase-Oscillo plug-in has several buttons to configure it's operation.
Oscilloscope button
This switches the oscilloscope display on and off. If set to off, only the phase meter is displayed.
Sample interpolation
When this switch is on, the samples of the signals displayed on the oscilloscope are interconnected, resulting in an
increased readability of the display.
Setup
This button opens the set-up pane with further options
Working Priority
Choose one of these switches to select the amount of CPU time of the host PC which can be consumed
by the plug-in, and therefore influences the redraw speed and accuracy of the oscilloscope. The higher
the priority, the more CPU time is assigned to the plug-in
Drop frame display
Depending on the chosen working priority of the Phase-Oscillo plug-in might not get enough CPU time to contin-
uously redraw the display. The drop counter displays the amount of frames which could not be drawn because of
lack of CPU time since the start of the actual Pyramix session.
Left and Right channel selector
If the plug-in is inserted on a bus with more than two channels (e.g. a surround bus or a multiple stereo bus), these
two selectors allow you to select the appropriate channels for the left and right input of the plug-in. On a surround
bus, you might for example select the left front and right front channels to be displayed on the Phase-Oscillo
plug-in.
