Route Page

Route brings together all routing to and from physical I/O in an intuitive matrix routing grid environment. It opens

in the Strips Input page:

Mixer Configure Page

Strips Direct Out and Masters Outputs are similar.

Making Connections

When the cursor is hovering over a destination crosspoint the column and row are highlighted for ease of viewing.

If the cursor is over a crosspoint which is part of a multichannel strip or bus the other channels in the group are

also dimly highlighted. In Strips Inputs clicking on a crosspoint routes the source in the left hand column to the

destination in the top row. In Strips Direct Out and Masters Outputs sources are horizontal and destinations ver-

tical. Clicking and dragging allow multiple assignments to be made rapidly.

Right-clicking a crosspoint pops-up a context menu with options appropriate to the destination.:
