Click and drag on the red and white balls is independent and the controls are switched between Source 1 and
Source 2 by clicking on the buttons. If a Link option is chosen from the combo box click and drag and the controls
will affect both sources depending on the chosen linking.
Strip and Bus Tools
In a multi-channel strip the clicking the show/hide Routing button displays the channel routing buttons. There
are as many routing buttons as there are channels in the strip. Strip and Bus Tools affect all channels whose rout-
ing buttons are lit blue. In Mono and Stereo strips the routing buttons are on by default. In GPS strips only chan-
nels 1 & 2 have their routing buttons on by default.
If more than one instance of Strip or Bus Tools is used in the strip this allows, for example, different settings to be
applied to Front L-R and Rear L-R.

Peak Logger

The Pyramix Mixer is equipped with a Peak Logger. This has obvious applications in Mastering.
Click on the Gain Pop-up to access the Gain options:
Surround Control Link combo box
Mixer : Peak Logger
Show/Hide Routing
Routing Buttons
10 - 193
