Rear View
EasyCoder PM4i Printer User's Guide (IPL Version)
TherearplatecontainstheOn/Offswitch,theACpowercord
socket,andvariousinterfaceconnectorsandslots.
Machine
label
Intake slot for external
media supply
Chapter 2 — Installation
Provision for EasyLAN
Wireless antenna
(option)
Provision for Easy LAN
Ethernet connection
(option)
Memory card slot
Provision for IEEE 1284
parallel interface board
On/off switch
(not used)
RS-232 serial interface
USB interface
AC power
cord socket
