NOTE
• When detaching the transceiver from the mounting bracket,
push up and hold the release lever, then pull the transceiver
in the direction of the arrow.
• The mounting bracket can be attached even if upside down.
When detaching the transceiver from the bracket in this case,
push down and hold the release lever, then pull the trans-
ceiver to the front.
D Microphone connection
Connect the supplied microphone as illustrated below.
Release lever
CONVENIENT! The supplied OPC-647
available to extend the microphone cable.
D Microphone hanger attachment
Attach the supplied microphone hanger (with the microphone
hanger attachment plate) as illustrated below.
Put double-faced tape* on the
back side of the attachment plate.
*Not supplied.
ACCESSORIES AND CONNECTION
Microphone hanger
attachment plate
Microphone hanger
1
1
is
MICROPHONE CABLE
Microphone
hanger
HM-182
3
