Icom IC-440 Instruction Manual page 13

y PRIO/SET•P KEY
PRIO
SET P
N (PRIO/PRIO Set)
➥ Push to select the priority channel. (p. 17)
➥ Push and hold for 2 sec. to set the displayed channel
as the priority channel. (p. 17)
F (S-Ring/PRIO Clear)
➥ Push to transmit the Smart-Ring signal. (p. 34)
• When RX channel is selected, "N/A" appears.
➥ Push and hold for 2 sec. to cancel the priority channel
setting. (p. 17)
u SCAN/TAG KEY
SCAN
TAG
N (Scan/Scan Tag)
➥ Push to start or stop the scan. (pgs. 23, 24)
➥ Push and hold for 2 sec. to set or clear the displayed
channel as a TAG (scanned) channel. (p. 22)
• " " appears when the selected channel is tagged.
F (TX Code CH/Call)
➥ Push to enter the SelCall TX code channel selection
mode, then push or
eration only) (p. 29)
➥ Push and hold for 2 sec. to transmit to the SelCall TX
code channel. (CB channel operation only) (p. 31)
i FUNCTION DISPLAY (p. 10)
Displays a variety of information such as an operating
channel number/name, SelCall code, selected function,
etc.
o POWER KEY (p. 14)
Push and hold for 2 sec. to turn the power ON and OFF.
to select. (CB channel op-
PANEL DESCRIPTION
!0 FUNCTION/SET KEY
F
SET
N (Function/Set Mode)
➥ Push to turn Function mode ON.
• "F" appears when Function mode is turned ON.
➥ Push and hold for 2 sec. to enter Set mode. (pgs. 19,
40)
F (Function/RX VFO)
➥ Push to turn the Function mode OFF.
• "F" disappears when Function mode is turned OFF.
➥ Push and hold for 2 sec. to enter RX VFO mode.
('RX-XX' displays while RX channel is selected) (p. 35)
NOTE: Returns to the Normal mode automatically
after 30 sec. when no key operation is performed in
Function or Set mode.
!1 MONI/T SQL KEY
MONI
T SQL
N (Monitor/TSQL)
➥ Push to toggle the monitor function ON or OFF. (p. 18)
➥ Push and hold for 2 sec. to activate the following func-
tions in order.
• Subaudible tone encoder and Tone squelch/DTCS
squelch ("TSQL" appears). (p. 27)
• Pocket beep ("TSQL ë" appears). (p. 28)
• No tone operation ("TSQL ë" disappears).
F (SQL/ATS)
➥ Push to enter the squelch level setting mode, then
push or to set the squelch level. (p. 18)
➥ Push and hold for 2 sec. to turn the ATS (automatic
transponder system) function ON or OFF. (p. 34)
2
2
9
