Using the Web Device Manager
Options include:
•
Default Port VID: Sets the PVID to be assigned to untagged traffic
on a given port. For example, if port 7's default PVID is 100, all
untagged packets on port 7 belong to VLAN 100. The default setting
for all ports is VID 1.
•
GVRP: Allows automatic VLAN configuration between the switch
and nodes.
•
Ingress Filtering: Allows frames belonging to a specific VLAN to
be forwarded if the port belongs to the same VLAN. Disabling this
setting will cause all frames to be forwarded, regardless of the port's
VLAN membership.
4 When you finish changing the settings, click Submit.
39
