- Page 1 ® Intel ™ NetStructure 6000 Switch Quick Start...
- Page 2 Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
-
Page 3: Quick Start
Quick Start Set up the switch Front Panel Screws For complete installation requirements, see the User Guide. 1 Remove the switch and parts from the box. 2 If you plan to install the switch in a 19- inch rack, remove the four front panel screws on each side of the unit, then use the screws included in the accessory kit to fasten the rack-mount brackets. -
Page 4: Network Modules
Install additional power supplies If you purchased an additional power sup- ply, place it in one of the empty power supply bays at the top of the chassis. 1 Loosen and remove the capture panel screws on the face plate of the power supply bay. - Page 5 Plug in the switch After you’ve installed all modules, plug power cords into each installed power sup- ply at the back of the chassis. Back Panel Connect to devices After you have powered on the switch, plug in the network cables. Use the network module LEDs to verify link status and activity.
-
Page 6: Management Options
Management Options Configure and manage the switch Option 1: Local Management 1 Connect your PC directly to the Console port on the Control Processor module using the included null modem cable. 2 Set a VT-100-compatible terminal emulation program (such as HyperTerminal*) to these parameters: - 9600 baud - 8 data bits... -
Page 7: Option 2: Intel® Device View
Web: After installing on a PC with a Web server, (see table above for requirements) Assign an IP address to the Intel NetStructure 6000 Switch 1. IP address (partly filled out by the wizard) double-click the Intel Device View icon to 2. -
Page 8: Option 3: Web Device Manager
Option 3: Web Device Manager Before you can use the Web Device Manager, you must configure the switch’s IP settings. See the Local Management or Intel Device View sections for more information. 1 Open your Web browser. The Web Device Man- ager supports Internet Explorer* 4.0x or later or...
