If the option you selected allows you to configure or monitor a specific port,
you can change to another port by clicking it on the faceplate graphic.
Port color on the faceplate graphic indicates the status of the port.
Port Color
Blue
Green
Magenta outline
Orange
Gray
Buttons
Each configuration screen includes four buttons on the bottom of the screen.
Button
Submit
Reset
Default
Help
Meaning
Port has a link at 1000Mbps.
Port has a link at 100Mbps.
Ports are in a link aggregation.
Port is disabled.
No link.
Function
Applies the configuration settings on the current screen.
Note: If you do not save the settings to the switch's flash
memory your changes are lost when the switch is rebooted.
Clears any changes you made on the current screen and
restores the currently applied settings.
Applies factory defaults for this screen's settings. When
you log out, you can permanently save the new settings to
the switch. Otherwise, they are lost upon the next reboot.
Displays Help for the current screen.
