Bit positions 16 through 31 of register R are treated as a
signed integer, with negative integers in two's complement
form (i. e., a fixed-point halfword). The modifier is alge-
braically added to the top-of-stack address, subtracted
from the space count, and added to the word count in the
stack pointer doubleword. If, as a result of MSP, either
the space count or the word count would be decreased be-
low 0 or increased above 2 15 _1, the instruction is aborted.
Then, the basic processor either traps to location X'42' or
sets the condition code to reflect the reason for aborting,
depending on the stack limit trap inhibits.
If the modification of the stack pointer doubleword can be
successfully performed, MSP operates as follows:
1.
The modifier in register R is algebraica"y added to the
current top-of-stack address (SPD15-31)t, to point to
a new top-of-stack location. (If the modifier is neg-
ative, it is extended to 17 bits by appending a high-
order 1.)
2. The modifier is algebraica"y subtracted from the cur-
rent space count (SPD33-47) and the result becomes
the new space count.
3. The modifier is algebraically added to the current
word count (SPD49-63) and the result becomes the new
word count.
4. The condition code is set to reflect the new status of
the new space count and new word count.
Affected: (SPD), CC Trap: Push-down stack limit
(SPD)15_31 + (R)16_31SE- SPD 15_31
t
(SPD)33_47 - (R)16-31 - SPD 33 _ 47
(SPD)49_63 + (R)16-31- SPD 49-63
Condition code settings:
2 3 4 Result of MSP
o
0 0 0 Space count> 0,
word count>
O.
0 0 0 Space count> 0,
word count
=
O.
o
o
o
0 Space count
=
0,
word count> O.
o
Space count
=
0,
word count = 0,
__ ...1:&:
~~
- ()
I.'VU" I
~I
-
v.
Instruction completed
t For real extended mode of addressing this is a 20-bit
field (12-31); for real and virtual addressing modes it is a
17-bit field (15-31).
84 Push- Down Instructions (Privi leged)
If
CC 1, or CC3, or both CC 1 and CC3 are l's after
execution of MSP, the instruction was aborted but the push-
down stack limit trap was inhibited by the trap-on-space
inhibit (SPD32), by the trap-on-word inhibit (SPD4S), or
both. The condition code is set to reflect the reason for
aborting as follows:
2 3 4 Status of space and word counts
o
Word count>
O.
Word count
=
O.
- - 0 - 0
~
word count
+
modifier
~
2
15
_1.
- Word count
+
modifier < 0, and TW = 1 or
word count
+
modi fi er > 2 15 _1, and TW
=
1.
- 0 - - Space count>
O.
- - Space count
=
O.
o - - - 0~spacecount-modifier<215_1.
- Space count - modifier < 0, and TS
=
1 or
space count - modifier> 2 15 _1, and TS
=
1.
PUSH-DOWN INSTRUCTIONS (PRIVILEGED)
The computer has two privi leged push-down instructions:
PUSH STATUS (PSS) and PULL STATUS (PLS). These two in-
structions and a Status Stack Pointer Doubleword foci litate
the storing (pushing) or loading (pulling) of a particular
environment (contents of 16 general registers and Program
Status Words) into or out of a memory stack.
STATUS STACK POINTER DOUBLEWORD
The Status Stack Pointer Doubleword (SSPD) always resides
:r.
rce! rn6iiiCi}l
locations 0 and 1 and is dedicated
for
PSS
and PLS instructions. The format of parameters contained
within the Status Stack Pointer Doubleword are as follows:
Real Memory Location 0:
Real Memory Location 1:
TOP OF STACK ADDRESS
The Top of Stack Address (TSA) is always a 20-bit real mem-
ory word address and is never mapped. Depending upon
