/ Recording on/off: shows the status of recording video
/ MIC on /off: shows the status of MIC volume.
/ MD on/off: shows the status of Motion Detection
Camera Control Panel - There are two slider bars and eight control buttons on the
remote controller. They are describe as below:
Brightness and Mic volume adjustment - Drag the slider bar to adjust the image
brightness level and Mic volume. Click "Default" for default brightness setting and
"Mute" for no sound. For more Audio setting, please refer to the Audio configuration
on page 33.
Speaker –The build-in speaker plays the sound of an audio clip from computer MIC
when it is enabled.
Play or Stop - Click this button to play or stop the video.
Recording - Click this button to record video to your computer.
Snapshot - Click this button to capture and save still images.
Digital Zoom - Click this button to enable the zoom operation.
Mirror - horizontally reflect the display of the live video.
Flip - vertically reflect the display of the live video.
Real Size - click this button to view the object in real size. Press this button
again to switch back to normal mode.
Full Screen - Click this button to switch to full screen mode. Press "Esc" key
to switch back to normal mode.
Motion Detection Alert: Click this button to enable motion detection alert
function.
